GE Appliances
JBP35WBWW—GE Spectra
Dimensions (in inches)
Acceptable electrical
outlet area
29-7/8
*Dimension from wall to front of closed door handle is 27-3/4".
Specification Created 2/00
™
30" Free-Standing QuickClean
30
2-1/2
25
2-1/2
7-1/2
44-7/16
Preferred electrical
outlet area
Roughed-in dimensions
25-3/8*
47-5/8
™
Electric Range
KW Rating
240V
11.7
208V
8.8
A properly grounded branch circuit with a 3 prong grounding type receptacle is required for
GE ranges.
Receptacle Locations
Locally approved flexible service cord or conduit must be used because terminals are not
accessible after range installation. See shaded area in drawing for location of electrical outlet box.
Recommended outlet locations allow range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent walls below
countertops. To reduce possibility of scorching of walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat, no-load heating element operation.
Installation Information: Before installing, consult installation instructions packed with product
for current dimensional data.
For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile
™
or GE appliance questions, call
GE Answer Center
®
service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Listed by
Underwriters
Laboratories
R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GE Spectra JBP35ED
Summary of Contents for GE Spectra JBP35ED
- Page 1 Locally approved flexible service cord or conduit must be used because terminals are not accessible after range installation. See shaded area in drawing for location of electrical outlet box. Recommended outlet locations allow range to be installed directly against wall.
- Page 2 GE Appliances JBP35WBWW—GE Spectra ™ 30" Free-Standing QuickClean ™ Electric Range Features and Benefits • Super Large 5.0 Cu. Ft. Oven Capacity • Self-Cleaning Oven • Clean-Well™ Cooktop System • Lift-Up Upswept Porcelain-Enameled Cooktop with Dual Support Rods • Two 6" and Two 8" Deluxe Plug-in Calrod™ Heating Elements •...
Need help?
Do you have a question about the Spectra JBP35ED and is the answer not in the manual?
Questions and answers
spectra electric range -- oven door will not unlock --forced the left side open but right side will not unlock. locking lever does not unlock right side. what do i do ????
To unlock the oven door on a GE JBP35ED Spectra electric range when the locking lever does not work, allow the oven to cool to room temperature. Once cooled, make sure the door latch handle is moved all the way to the right. If the door is still stuck, check that the oven is not in self-clean mode or too hot, as high temperature can prevent unlocking.
This answer is automatically generated
How to clean oven
To clean a GE JBP35ED oven using the self-cleaning feature:
1. Remove items: Take out the broiler pan, broiler grid, all cookware, and any aluminum foil.
2. Oven shelves:
- If silver-colored, remove them before self-cleaning.
- If gray porcelain-coated, they can stay in the oven.
3. Clean manually:
- Wipe up heavy soil or spillovers from the oven bottom.
- Clean around the door gasket using hot water and a soap-filled pad or cleanser like Soft Scrub®. Do not scrub the gasket itself.
4. Prepare for self-cleaning:
- Make sure the oven light cover is in place and the light is off.
- Slide the latch handle fully left and open the door.
- Touch the Self Clean pad.
- Use the + or – pads to set clean time (between 3 and 5 hours, default is 4 hours 20 minutes).
- Close the door and latch it.
- Touch Start/On.
5. During and after cleaning:
- Door remains latched until the oven cools below lock temperature.
- If white spots remain, use a soap-filled scouring pad and rinse with a vinegar-water mix.
- If not clean after one cycle, repeat the self-cleaning.
Do not use spray lubricants like Pam®. Apply a small amount of vegetable oil to a paper towel and wipe oven shelf edges if needed.
This answer is automatically generated
