Description and Specifications
Hardware
Specifications
Page 1-4
Modem
• 56K internal modem
• V.42 MNP (2-4) error correction
• V.42 BIS MNP5 data compression
• Group 3 Fax
Microprocessor
• Motorola 860T
• 16 MB FLASH Memory
• 64 MB S DRAM
Dimensions
• Height 2.0 inches
• Width 9.7 inches
• Depth10.5 inches
Weight
• Approximately 12 lb.
Environmental Requirements
• 50° to 110° F operating temperature (10° to 43° C)
• 20° to 140° F non-operating temperature (-29° to 60° C)
• 20% to 80% relative humidity, nonconducting
Power Requirements
Input power Voltage
AC 110/220 volts
DC -48 volts
Host System Interface
The NET-PATHm has two EIA RS-232-C serial ports. Connectors for the NET-
PATHm (labeled Host 1 and Host 2) are configured as Data Terminal Equipment
(DTE), using RJ45 male connectors. Transmission rates can vary from 110 BPS to up
to 115 KBPS.
Telephone Line Interface
The telephone connection is a modular RJ11C interface. Pulse dialing or tone
signaling (DTMF) is a software option.
Physical Sensor Inputs
Depending on the model you choose, the NET-PATHm provides multiple RJ45
connections to connect to external physical sensors. The terminals connect to circuits
supplying approximately one milliampere when the terminals are shorted. You can set
each pair of terminals individually, via software, to detect normally open or normally
closed contacts.
Current Watts BTU/hr
98 mA 10.78 36.78
240 mA 11.52 39.31
