Gold Medal 1661 Quick Start Manual

10700 Medallion Drive, Cincinnati, Ohio 45241-4807, USA
The Gallon Wall Mount is intended for use with
a one gallon jug with dispensing pump. Securely
mount unit to wall for stability, see instructions below.
Follow the product manufacturer's instructions
for product handling and use.
(not included with unit)
• Philips Head Screwdriver

Items Needed

• Drill (use a bit smaller than the screw size to
make pilot holes for the lag screws)
• (2) 1/4" x 3" Hex Head Lag Screws and Washers
• Gallon Wall Mount Bracket (PN 116590)

Items Included

• (1) 14" Stainless Lanyard (PN 114690)
• (1) 8-32 X 1/4" Screw (PN 74142)

Mounting Instructions

1. Locate the center of a wall stud suitable for
mounting the unit.
Tip: Measure desired height for consistency
when mounting multiple units.
2. Hold unit in place (along wall stud center)
and mark the holes needed for the lag
screws—make sure unit sits level.
Note: Bracket has optional mounting
holes on left and right of center
for mounting flexibility.
3. Drill a pilot hole for each lag screw.
© 2020 Gold Medal Products Co.
Gallon Wall Mount
Model No: 1661
Mark the 2 mounting
Page 1 of 2
1-800-543-0862
Gallon jug with pump shown for reference
only (not included with unit).
Find center location
of wall stud.
holes needed.
gmpopcorn.com
Part No. 110276
