• Operating Instructions • Warning Information
S P E C I F I C A T I O N S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 LBS.
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.9"
Sound Pressure Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 dBA
Max. Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18,000 RPM
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
Mim. Air Hose Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" ID
Recommended Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 PSI
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 CFM
• MAxiMuM rpM of 18,000
• M Ax Air pressure:
90 psig, 6.2 bAr
• rAted rpM of the
ACCessory used Must
exCeed the MAxiMuM tooL
rpM shown
ALwAys reAd
instruCtions
before using
power tooLs
ALwAys weAr
sAfety goggLes
weAr heAring
proteCtion
Avoid
proLonged
exposure to
vibrAtion
MT1872L
• Parts Breakdown
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
MT1872L
Copyright © Professional Tool Products, 2009
1
MT1872L
6" Extended
Cut Off Tool
All rights reserved.
rev. 08/17/09
Advertisement
Table of Contents
Related Manuals for Matco Tools MT1872L
Summary of Contents for Matco Tools MT1872L
- Page 1 S P E C I F I C A T I O N S MT1872L ............
- Page 2 MT1872L 6" Extended Cut Off Tool faiLure To oBserVe These Warnings couLd resuLT in inJury This insTrucTion ManuaL conTains • Place the tool on the work before starting the tool. iMporTanT safeTy inforMaTion. • Slipping, tripping and/or falling while operating air read This insTrucTion ManuaL carefuLLy tools can be a major cause of serious injury or and undersTand aLL inforMaTion Before death. Be aware of excess hose left on the walking...
- Page 3 MT1872L 6" Extended Cut Off Tool feaTures • Narrow profile for easy access during use. • Full 1/2HP motor provides great power for heavy duty cutting. • 180 degree head rotation to direct sparks away from work. • Safety lever and composite grip make this tool comfortable during use. TrouBLeshooTing air suppLy Other factors outside the tool may cause loss of power or erratic Tools of this class operate on a wide range of air pressures. It is action.
- Page 4 MT1872L 6" Extended Cut Off Tool REF. NO. PaRT NO. DEscRiPTiON QTy. REF. NO. PaRT NO. DEscRiPTiON QTy. 36 RS1872L36 Screw (M5x13L) RS288301 Regulator 37 RS1872L37 Nut (M5) 2 RS288302 O-Ring 38 RS1872L38 Spindle 3 RS288303 O-Ring 39 RS288734 Bearing RS288304 Snap Ring...
