PORTswitch 900FP
Installation and Configuration
Order Number: EK-DEFMM-IN. C01
August 1995
This manual describes how to install and configure the PORTswitch
900FP module.
Revision/Update Information:
This is a revised manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PORTswitch 900FP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEC PORTswitch 900FP

Summary of Contents for DEC PORTswitch 900FP

  • Page 1 PORTswitch 900FP Installation and Configuration Order Number: EK-DEFMM-IN. C01 August 1995 This manual describes how to install and configure the PORTswitch 900FP module. Revision/Update Information: This is a revised manual.
  • Page 2 Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that may appear in this document. The following are trademarks of Digital Equipment Corporation: DEC, DECconnect, DEChub, DECrepeater, Digital, HUBwatch, MultiSwitch, ThinWire, and the DIGITAL logo.

  • Page 3: Table Of Contents

    Configuring the Ports ..................... 2–6 3 Configuring the Module Overview ......................... 3–1 Setup Port Description.................... 3–2 Accessing the Setup Port ..................3–5 DEChub 900 MultiSwitch Installation Menu............3–6 PORTswitch 900FP Installation Menu (DEChub 900 Options)......3–8 PORTswitch 900FP Installation Menu (DEChub ONE Options)......3–9...
  • Page 4 Description of Menu Options ................3–10 4 Removing the Module Overview ......................... 4–1 How to Remove the Module ..................4–2 5 Problem Solving Overview ......................... 5–1 LED Descriptions ....................5–2 Problem Solving Using the LEDs ................5–6 A Redundant-Link Configuration Overview ........................
  • Page 5 D Remote Monitor Alarms and Events Overview ........................ D–1 Alarms and Events Description ................D–2 Configured Alarms and Events................D–3 E Product Specifications Overview .........................E–1 Operating Environment Specifications ..............E–2 Connector and Physical Specifications ..............E–3 Acoustical Specifications..................E–5...
  • Page 6 Figures Figure 1-1 PORTswitch 900FP Front Panel............1–5 Figure 1-2 PORTswitch 900 FP Back Panel ............1–7 Figure 2-1 Installing the module ................2–3 Figure 2-2 Initial LED Operation ................. 2–4 Figure 2-3 Redundant-Link Pairs................. 2–8 Figure 2-4 Separate Independent Ports..............2–9 Figure 3-1 Setup Port Cabling ................
  • Page 7 Table B-1: 10BaseFL Worst-Case Loss Budget (0ºC to 50ºC, End of Life) ...B–3 Table B-2: FOIRL Worst-Case Loss Budget (0ºC to 50ºC, End of Life) ....B–5 Table B-3: PORTswitch 900FP Best-Case Maximum Launch Power ....B–6 Table D-1: Configured RMON Alarms and Events ..........D–3...
  • Page 8 Table E-1: PORTswitch 900FP Operating Specifications........E–2 Table E-2: Connectors ..................E–3 Table E-3: PORTswitch 900FP Physical Specifications........E–4 Table E-4: Acoustical Specifications..............E–5 viii...

  • Page 9: Preface

    Preface About this Manual Manual Contents This manual describes how to install and configure the PORTswitch 900FP. Intended Audience This manual is intended for use by personnel who will install and set parameters for the PORTswitch 900FP.
  • Page 10 (RLP) of Ethernet 10BaseT links. Appendix B Describes the fiber-optic loss budget. Appendix C Contains illustrations of the connectors, cables, and adapters used on the PORTswitch 900FP. Appendix D Remote Monitor Alarms and Events Appendix E Lists operating environment, physical and...
  • Page 11 Conventions Used in this Manual The following conventions are used in this manual: Convention Meaning Indicates a literal example of system output. Monospaced type Boldface type In examples, indicates user input. Italics In examples, indicates a variable. In text, indicates emphasis or a book title. Contain default responses to the installation menu prompts.
  • Page 12 Associated Documents The following documents provide related information about the module. To order any of these documents use the directions provided in the following page. Title and Order Number Description DEChub 900 MultiSwitch Provides installation, use, security, and Owner's Manual troubleshooting information for the EK-DH2MS-OM DEChub 900 MultiSwitch.
  • Page 13 Alaska or Hawaii (1-800-344-4825) call 1-603-884-6660 ELECTRONIC ORDERS (U.S. ONLY) Dial 1-800-dec-demo with any VT100 or VT200 compatible terminal and a 1200 baud modem. If you need assistance, call 1-800-DIGITAL (1-800-344-4825) DIRECT MAIL ORDERS (U.S. and Puerto Rico*) DIGITAL EQUIPMENT CORPORATION P.O.
  • Page 14 • Contact your local Digital reseller or your local Digital sales office. • Read the README file found in the /pub/DEC/hub900 directory at ftp.digital.com. Firmware updates are customer installable. To register for automatic notification of new firmware releases, return the Business Reply Card supplied with this product, or send your name, title, and mailing address to dechub_notice@lkg.dec.com.

  • Page 15: Safety

    Safety The cautions that must be observed for the hardware described in this manual are listed below in English, German, French, and Spanish. WARNING Contains information to prevent personal injury. CAUTION Contains information to prevent damage to equipment. VORSICHT Enthält Informationen, die beachtet werden müssen, um den Benutzer vor Schaden zu bewahren.
  • Page 16 Some fiber optic equipment can emit laser or infrared light that can WARNING injure your eyes. Never look into an optical fiber or connector port. Always assume the cable is connected to a light source. [Pages 2-5 and 4-2.] VORSICHT Bestimmte Lichtleitergeräte können für die Augen gefährliches Laser- oder Infrarotlicht abstrahlen.
  • Page 17 CAUTION If power is interrupted during Stage 3 of the DLU process, the firmware image can become corrupted. Do not turn off power to the unit or perform any action that can cause the unit to lose power during Stage 3 of the DLU process. [Pages 3-27 and 3-35.] ACHTUNG Sollte während der Phase 3 des DLU-Prozesses eine Unterbrechung der Stromversorgung eintreten, kann das...
  • Page 18 CAUTION You must configure the links using HUBwatch before connecting the cables. Failure to do so can seriously impair performance on that segment of the LAN. [Page 2-7 and A-1.] ACHTUNG Sie müssen die afgebauten Verbindungen zuerst mit HUBwatch konfigurieren, bevor Sie die Kabel anschließen. Andernfalls ist die volle Leistungsfähigkrit dieses LAN-Segments nicht gewährleistet.

  • Page 19: Portswitch 900Fp Description

    Introduction This chapter describes the features and components of the PORTswitch 900FP. The PORTswitch 900FP (also referred to in this manual as the module) is a 12-port, 10BaseFL, fiber-optic, Ethernet repeater. In This Chapter This chapter includes the following topics:...

  • Page 20: Module Features

    DEChub 900 MultiSwitch (also referred to in this manual as the DEChub 900). You can install one or more PORTswitch 900FP modules (up to 8) into the DEChub 900. The module can also serve as a standalone unit when configured with a DEChub docking station (see the DEChub ONE Installation manual).
  • Page 21 Module Features List of Features Your PORTswitch 900FP module includes the following features: • Automatic module self-test at powerup. • Port-level packet address security. • In-band Simple Network Management Protocol (SNMP). • Backplane access to multiple LANs through one of six flexible channels in the DEChub 900.

  • Page 22: Module Components

    Fiber-optic RX Connect fiber-optic cables to the port ST-type transmit ports of the remote fiber-optic connectors device. _____________________________Note ________________________ For more information about LED operation, refer to Chapter 5, Problem Solving. _______________________________________________________________ 1–4 PORTswitch 900FP Description...

  • Page 23: Figure 1-1 Portswitch 900Fp Front Panel

    Module Components Front Panel Figure 1-1 PORTswitch 900FP Front Panel PORTswitch 900FP Description 1–5...

  • Page 24: Table 1-2: Back Panel Components

    DEChub 900 or DEChub ONE docking station. Grounding fingers Provides additional chassis grounding between the module and a DEChub 900 or DEChub ONE docking station. Address label Contains the module's 48-bit Ethernet hardware address. 1–6 PORTswitch 900FP Description...

  • Page 25: Figure 1-2 Portswitch 900 Fp Back Panel

    Module Components Figure 1-2 PORTswitch 900 FP Back Panel PORTswitch 900FP Description 1–7...

  • Page 27: Installing The Module

    This chapter describes the tasks necessary to install the module. What do I Need to Know? The PORTswitch 900FP hot-swap feature allows you to install the module into the DEChub 900 or DEChub ONE docking station without turning off power. Seating the module initiates the powerup sequence if enough power is available.
  • Page 28 Installing the Module Installing the Module Task 1: Compare the power requirements Compare your module's power requirements with the values shown in the Hub Manager status display (see examples). If any of the module’s power requirements exceed the values shown in the status display, add another power supply (see the DEChub 900 MultiSwitch Owner’s Manual).

  • Page 29: Figure 2-1 Installing The Module

    Installing the Module Task 2: Install the module into the DEChub 900. To install the module, complete the following steps: Step Action Place the module's mounting tab into a mounting slot (1) on the DEChub 900. Pull up on the release lever (2) to its unlocked position. Pivot the module on the mounting tab and align the connectors.

  • Page 30: Figure 2-2 Initial Led Operation

    After the module completes the self-test, the Module OK LED lights within 1 minute and remains lit. The Hub Manager status display shows: PORTswitch 900FP Figure 2-2 Initial LED Operation _____________________________Note ________________________ If the LEDs do not operate as described, refer to the Chapter 5, Problem Solving.

  • Page 31: Before Connecting The Cables

    What Type of Cables Should I Use? Digital recommends that you use 62.5/125-micron multimode graded index fiber-optic cable with the PORTswitch 900FP. If the fiber-optic cables that you are using are not the recommended size, refer to the Appendix B, Fiber-Optic Loss Budget for more information.

  • Page 32: Configuring The Ports

    Configuring the Ports Configuring the Ports Determine the Configuration Before you connect the fiber-optic cables, determine whether you are configuring the ports as redundant-link pairs or separate independent ports (default configuration). If you are configuring the ports Then go to this section as...
  • Page 33 Configuring the Ports Connecting Redundant-Link Pairs _________________________CAUTION ________________________ You must configure the links using HUBwatch before connecting the cables. Failure to do so can seriously impair performance on that segment of the LAN. _______________________________________________________________ After you have configured the ports using HUBwatch, complete the following (refer to Figure 2-3 on the next page) steps to connect redundant-link pairs: Step...

  • Page 34: Figure 2-3 Redundant-Link Pairs

    Configuring the Ports Connecting Redundant-Link Pairs (Cont.) Item Description Primary and secondary master port pair Primary link Secondary link Responder or non-responder port Figure 2-3 Redundant-Link Pairs Primary and secondary master port pair must be on the same module. Responder ports and non-responder ports can be on the same module as each other or on separate modules.

  • Page 35: Figure 2-4 Separate Independent Ports

    Configuring the Ports Connecting Separate Independent Ports Complete the following steps to connect the cables: Step Action Remove any dust caps from the ST-type connectors on the ports that you are connecting. Align the tab and slot (1) of the transmit cable plug with the slot and tab (2) of the transmit port connector.

  • Page 37: Configuring The Module

    This chapter includes the following topics: Topic See Page Setup Port Description Accessing the Setup Port DEChub 900 MultiSwitch Installation Menu PORTswitch 900FP Installation Menu (DEChub 900 Options) PORTswitch 900FP Installation 3-10 Menu (DEChub One Options) Description of Menu Options 3-11...

  • Page 38: Setup Port Description

    Setup Port Description Introduction The setup port (on the DEChub 900 or the DEChub ONE) allows you to access and set PORTswitch 900FP parameters. This section describes how to access the module from either port and how to set those parameters.
  • Page 39 Setup Port Description Setup Port Cabling The setup port on the DEChub 900 or the DEChub ONE can be connected to a setup port device (a terminal or personal computer), using the following cables and adapters. If the setup port Then use this cable...

  • Page 40: Figure 3-1 Setup Port Cabling

    Setup Port Description Figure 3-1 Setup Port Cabling Item Description OBM port Setup port Setup port device 3–4 Configuring the Module...

  • Page 41: Accessing The Setup Port

    Accessing the Setup Port Accessing the Setup Port Steps to Access the Setup Port To access the setup port on the PORTswitch 900FP module, complete the following steps: Step Action Ensure that the transmit and receive baud rates on the setup port device are set to 9600 baud.

  • Page 42: Dechub 900 Multiswitch Installation Menu

    DEChub 900 MultiSwitch Installation Menu DEChub 900 MultiSwitch Installation Menu Example of Menu The following example shows the DEChub 900 MultiSwitch INSTALLATION MENU: DEChub 900 MultiSwitch ============================================ DEChub 900 MultiSwitch INSTALLATION MENU Reset with Factory Defaults Reset with Current Settings Show Current Settings Configure IP Dump Error Log...
  • Page 43 The example shows how to select a slot number: Enter selection: 9 ============================================= Enter the slot number for redirection (1-8): [ n ] <Return> Console redirected to 3: PORTswitch 900FP Attempting to connect [Ctrl/C to abort]... ============================================= Connection successful! After you press <Return>, the console redirects to the PORTswitch 900FP INSTALLATION MENU.

  • Page 44: Portswitch 900Fp Installation Menu (Dechub 900 Options)

    PORTswitch 900FP Installation Menu (DEChub 900 Options) Introduction This section shows the options available from the PORTswitch 900FP INSTALLATION MENU when the module is installed into the DEChub 900. The indication at the top of the screen, slot 3, refers to the DEChub 900 slot number where the module is installed.

  • Page 45: Portswitch 900Fp Installation Menu (Dechub One Options)

    PORTswitch 900FP Installation Menu (DEChub ONE Options) PORTswitch 900FP Installation Menu (DEChub ONE Options) Introduction This section shows the options available from the PORTswitch 900FP INSTALLATION MENU when the module is installed standalone into the DEChub ONE. Example of Menu...

  • Page 46: Description Of Menu Options

    Description of Menu Options Introduction This section describes the options that are available from the PORTswitch 900FP INSTALLATION MENU. Note that the out-of-band menu options apply to the module only when it is in standalone mode (configured in a DEChub ONE).

  • Page 47: Table 3-1: Effects Of Reset With Factory Defaults

    Description of Menu Options [1] Reset with Factory Defaults (Cont.) Table 3-1: Effects of Reset with Factory Defaults Parameter Effect SNMP read/write community Name reset to PUBLIC SNMP trap addresses Deleted In-band interface IP address Deleted In-band interface default gateway Deleted address Out-of-band interface IP address...
  • Page 48 The following example shows the dialog associated with this option (user response is shown in boldface type): Enter selection : 1 PORTswitch 900FP - slot 3 ====================================================== RESET WITH FACTORY DEFAULTS * * * * * * * * * * * * * * * * * * * * * * * * * * * * *...
  • Page 49 _______________________________________________________________ Example of Dialog The following example shows the dialog associated with this option: Enter selection : 2 PORTswitch 900FP - slot 3 ======================================================== RESET WITH CURRENT SETTINGS This selection will reset your system with the current configuration settings ========================================================= Press Y to confirm [N] : <Return>...
  • Page 50 Description of Menu Options [3] Show Current Settings This option shows the module's current settings. If your hardware revision is v 2.0 or less, PORTswitch 900FP is replaced with DECrepeater 900FP. _____________________________Note ________________________ If the module is being configured for the first time, some fields are blank.
  • Page 51 DEChub 900 Configure IP Options Menu The following example displays the options available when the module is installed into a DEChub 900. ========================================================= Enter selection : 4 PORTswitch 900FP - slot 3 ========================================================= IP CONFIGURATION Set SNMP Read/Write Community Add SNMP Trap Addresses...
  • Page 52 DEChub ONE standalone configuration. Note that option [7] is available only when the module is in the standalone configuration ========================================================= Enter selection : 4 PORTswitch 900FP ========================================================= IP CONFIGURATION Set SNMP Read/Write Community Add SNMP Trap Addresses...
  • Page 53 Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection : 1 PORTswitch 900FP - slot 3 ========================================================= SET SNMP READ/WRITE COMMUNITY Format: The format for a community name is a string,...
  • Page 54 The factory default of this menu option deletes all SNMP trap addresses. Example of Dialog The following example shows the dialog associated with this option: Enter selection : 2 PORTswitch 900FP - slot 3 ========================================================= ADD SNMP TRAP ADDRESSES Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a '.' character.
  • Page 55 Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection : 3 PORTswitch 900FP - slot 3 ========================================================= DELETE SNMP TRAP ADDRESSES Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a '.' character.
  • Page 56 Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection : 4 PORTswitch 900FP - slot 3 ========================================================= IN-BAND INTERFACE IP ADDRESS CONFIGURATION Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a '.'...
  • Page 57 Description of Menu Options [4] Configure IP (Cont.) [5] Set Out-of-Band Interface IP Address This option prompts you to enter an out-of-band IP address and a subnet mask. _____________________________ Note ________________________ This selection is operational only when the module is in standalone mode (when it is installed into a DEChub ONE).
  • Page 58 Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection :5 PORTswitch 900FP ========================================================= IP ADDRESS CONFIGURATION Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a '.'...
  • Page 59 [5] Set Out-of-Band Interface IP Address (Cont.) _____________________________ Note ________________________ To enable out-of-band management, you must also select an out- of-band management (OBM) port speed from PORTswitch 900FP INSTALLATION MENU Option [7] Configure Out-of-Band Port Submenu option [1] Set Port Speed _______________________________________________________________...
  • Page 60 Description of Menu Options [4] Configure IP (Cont.) [6] Enable/Disable BootP This option prompts you to enable or disable Bootstrap Protocol (BootP) requests from the module. _____________________________Note ________________________ This selection appears as submenu option [5] when the module is installed into a DEChub 900. _______________________________________________________________ The factory default setting is DISABLED.
  • Page 61 [6] Enable/Disable BootP (Cont.) Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection : 6 PORTswitch 900FP ========================================================= ENABLE/DISABLE BOOTP BOOTP is the IP bootstrap protocol. BOOTP may be used to obtain the module's IP address, subnet mask, and default gateway.
  • Page 62 When the firmware has been upgraded to a new version, the version number is entered into the error log. Example of Display The following example shows the display associated with this option: Enter selection : 5 PORTswitch 900FP - slot 3 ========================================================= DUMP ERROR LOG CURRENT RESET COUNT: 14 =========================================================...
  • Page 63 Description of Menu Options [6] Downline Upgrade This option allows you to upgrade the module firmware (in nonvolatile Flash memory). It prompts you to enter the firmware image load filename and the IP address of your Trivial File Transfer Protocol (TFTP) load host.

  • Page 64: Table 3-2: Dlu Process Description

    LED display – the Power LED and the Module OK LED remain on. All other LEDs remain in the state they were in before the DLU process began • HUB Manager display – PORTswitch 900FP (continued on next page) 3–28 Configuring the Module...
  • Page 65 LED display –The Power LED and the Module OK LED remain on. All other LEDs remain in the state they were in before the DLU process began. • HUB Manager display – PORTswitch 900FP (continued on next page) Configuring the Module 3–29...
  • Page 66 LED remain on. The #3 Port State LED turns off. The #4 Port State LED lights. • HUB Manager display – PORTswitch 900FP unknown After the transfer is complete, the #5 port state LED lights for up to 22 seconds while the module awaits a reset.
  • Page 67 The module OK LED and the #5 port state LED turn off. The LEDs display the self-test sequence. • HUB Manager display – PORTswitch 900FP unknown After the successful completion of self-test, the module OK turns on and the module becomes fully operational and manageable.
  • Page 68 IP address, select the Set In-Band Interface IP Address option (Option [4], Submenu option [4]) from the PORTswitch 900FP Installation Menu to set an IP address. Do not use the DEChub 900 MultiSwitch Hub Manager’s IP address to upgrade the PORTswitch 900FP.
  • Page 69 Description of Menu Options [6] Downline Upgrade (Cont.) Example of Display Enter selection : 6 PORTswitch 900FP slot - 3 ========================================================= DOWNLINE UPGRADE This process upgrades the device's firmware (in nonvolatile Flash memory). Enter the IP address of your TFTP (Trivial File Transfer Protocol) load host and the image file name when prompted.
  • Page 70 Description of Menu Options [6] Downline Upgrade (Cont.) The format of the firmware image file name is specified according to the conventions used by your TFTP load host. The following example shows the dialog associated with this option for a file that is located in the default directory: Enter the Load Filename [] defmm20.bin <Return>...
  • Page 71 _____________________________ Note ________________________ The PORTswitch 900FP is nonfunctional only during reset and self-test (about 1 minute of Stage 4) of the DLU process. During the first three stages of the process, the module continues to function as a repeater.
  • Page 72 This message is normal. Hub Manager Status Display The Hub Manager status display shows the following message: 3: PORTswitch 900FP unknown This message is normal. The Hub Manager status display continues to display this message until the DLU process is complete.
  • Page 73 PORTswitch 900FP Installation menu. If the module is installed into a DEChub 900, the Hub Manager status display shows the following message: 3: PORTswitch 900FP When you press <Return>, the screen displays the PORTswitch 900FP Installation menu. Configuring the Module 3–37...
  • Page 74 (when it is installed into a DEChub ONE). _______________________________________________________________ Example of Dialog The following example shows the dialog associated with this option: Enter selection : 7 PORTswitch 900FP ========================================================= SET OUT-OF-BAND PORT CONFIGURATION Set Port Speed Enable/Disable RTS Return to Main Menu ========================================================= Enter selection number : [ n ] <Return>...
  • Page 75 The factory default for this option is 9600. Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection : 1 PORTswitch 900FP ========================================================= SET OUT-OF-BAND MANAGEMENT INTERFACE PORT SPEED [1] 2400 baud [2] 9600 baud...
  • Page 76 Description of Menu Options [7] Configure Out-of-Band Port (Cont.) [2] Enable/Disable RTS This option prompts you to enable or disable the request-to-send (RTS) signal line on the OBM port. _____________________________Note ________________________ This option is operational only when the module is in standalone mode (when it is installed into a DEChub ONE).
  • Page 77 [7] Configure Out-of-Band Port (Cont.) Example of Dialog The following example shows the dialog associated with this option: ========================================================= Enter selection : 2 PORTswitch 900FP ========================================================= ENABLE/DISABLE RTS Enable/Disable Request To Send (RTS) allows additional control to modem communications. When the RTS option is Disabled the RTS signal on the OBM port is asserted after self-test is completed and left asserted.

  • Page 79: Removing The Module

    Chapter Removing the Module Overview Introduction This chapter describes the tasks necessary to disconnect the cables and remove the module. In This Chapter This chapter includes the following topic: Topic See Page How to Disconnect the Fiber Optic Cables How to Remove the Module Removing the Module 4–1...

  • Page 80: How To Remove The Module

    How to Remove the Module How to Remove the Module Task 1: Disconnect all the cables from the module. ________________________ WARNING ________________________ Some fiber-optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical-fiber or connector port.

  • Page 81: Figure 4-2 Remove The Module

    How to Remove the Module Task 2: Remove the module from the DEChub 900 Figure 4-2 Remove the Module Step Action Lift the release lever (1) located on the top of the DEChub 900 slot. Pivot the module back (2) on its bottom mounting tab, and disengage the module (3) from the backplane.

  • Page 83: Problem Solving

    Chapter Problem Solving Overview Introduction This chapter describes the module LED states and provides troubleshooting information. The module LEDs provide dynamic indications of module status. Topic See Page LED Descriptions Problem Solving Using the LEDs Problem Solving 5–1...

  • Page 84: Led Descriptions

    LED Descriptions LED Descriptions Static States for Module LEDs Table 5-1 shows the static states that are possible for four of the module LEDs: • Power • Module OK • Network OK • Network Activity Table 5–1: Module LED States LED Name Icon Flashing...

  • Page 85: Table 5-2: Port Leds

    LED Descriptions Table 5-1: Module LED States (Cont.) LED Name Icon Flashing Network No network Network has Flashes more Activity activity. rapidly and heavy traffic appears brighter as network traffic increases. Static States for Port LEDs Table 5-2 shows the static states that are possible for the combination of two Port LEDs: •...
  • Page 86 LED Descriptions Table 5-2: Port LEDs (Cont.) Port State Port Link Condition Flashing Associated port is auto-partitioned. The link is good. There is traffic on the network to which the associated port is connected, but traffic is not being received on that port. The Link LED flashes more rapidly and appears brighter as network traffic increases.
  • Page 87 LED Descriptions Normal Powerup When power to the module is initially turned on, the following events occur: Stage What Happens The Power LED lights and remains lit. All other LEDs light for a few seconds and then turn off. This event verifies that the individual LEDs are operational (defective LEDs do not light).

  • Page 88: Problem Solving Using The Leds

    Problem Solving Using the LEDs Problem Solving Using the LEDs When diagnosing a problem with the module, note that the problem is often indicated by the states of the module LEDs. Table 5-3 lists the states of the LED for various error conditions and suggests corrective actions.
  • Page 89 Problem Solving Using the LEDs Table 5–3: Problem Solving Using the LEDs (Cont.) Symptom Icon Probable Cause Corrective Action Power LED Faulty power LED. Replace the module. is flashing. Faulty DEChub 900 Reinstall the module into slot connection. another slot. DEChub 900 or Replace the DEChub 900 DEChub ONE...
  • Page 90 Problem Solving Using the LEDs Table 5–3: Problem Solving Using the LEDs (Cont.) Symptom Icon Probable Cause Corrective Action Port State Associated port is Properly connect the LED is off. not properly associated port to network or connected to station. another operational Reseat the cable.

  • Page 91: A Redundant-Link Configuration Overview

    Appendix Redundant-Link Configuration Overview Introduction This appendix describes the configuration and implementation of the redundant-link pair (RLP) of links. Redundant-link configuration refers to two links that are configured on a single LAN to provide greater fault tolerance than a single port-to-port configuration provides.

  • Page 92: Major Components

    Major Components Major Components Redundant links consist of the following major components: • Master port pair • Responder ports • Nonresponder ports • Master control algorithm (MCA) • Primary link • Secondary link Basic Configuration The basic redundant-link configuration consists of a pair of master ports on the same module and two remote ports on one module or on separate modules.

  • Page 93: Redundant-Link Components

    Redundant-Link Components Redundant-Link Components Introduction This section describes the components that make up a redundant-link configuration. Redundant-Link Pair The redundant-link pair (RLP) is a pair of links that provide fault- tolerant communication in the event of transmitter, receiver, or cable failures.
  • Page 94 Redundant-Link Components The responder and nonresponder ports can reside on the same module as each other or on separate modules. Master Control Algorithm The master control algorithm (MCA) resides within the module that is assigned as the master and contains the master port pair. The MCA does the following tasks: •...

  • Page 95: Redundant-Link Operation

    Redundant-Link Operation Redundant-Link Operation How does it work? The MCA controls the redundant-link operation by: • Enabling the primary link at initialization time (assuming that there are no failures on that link). • Monitoring the primary link status for failures. •...

  • Page 96: Configurations

    Configurations Configurations Simple Redundant-link Configuration In its simplest form, a redundant link consists of a pair of master ports that reside on one module, and a pair of responder or nonresponder ports on a remote module. See Figure A-1. Figure A-1 Simple Redundant-Link Configuration Example Item Description Master port pair.

  • Page 97: Figure A-2 Complex Redundant-Link Configuration Example

    Configurations Complex Redundant-link Configuration A complex redundant-link configuration consists of a master port pair and responder ports, nonresponder ports, or a combination of the two. The responder or nonresponder ports reside on separate modules, as shown in Figure A-2. Figure A-2 Complex Redundant-Link Configuration Example Item Description Master port pair.

  • Page 98: Fault Detection

    Fault Detection Fault Detection Partial Fault Detection Partial fault detection allows the PORTswitch 900FP to achieve limited fault tolerance with connections to nonresponder repeaters such as the DECrepeater 90FA or any 10BaseFL repeater. See Figure A-3. When the link is configured for partial fault tolerance, the MCA disables the...

  • Page 99: Figure A-3 Partial Fault Detection Configuration Example

    Fault Detection Figure A-3 Partial Fault Detection Configuration Example Item Description Master port pair. Primary link (initially active). The master can detect a link failure here. Secondary link (initially standby and disabled). The master cannot detect a link failure here. Single nonresponder port (always enabled).

  • Page 100: Figure A-4 Full Fault Detection Configuration

    Full Fault Detection The PORTswitch 900FP supports full fault detection. When the PORTswitch 900FP ports are connected to the ports of another repeater that supports this feature, such as a DECrepeater 90FS, failures are detected at either end of the receive or transmit link. See Figure A-4.

  • Page 101: Table A-5: Comparison Of Partial Fault Detection To Full Fault Detection

    RX Link Detects the failure Detects the failure Recommendations for Redundant-Link Configuration Consider the following recommendations when configuring the PORTswitch 900FP as redundant links: • Use responder ports (rather than nonresponder ports) whenever possible. • If you use a combination of responder ports and nonresponder ports, assign the responder ports to the primary link and the nonresponder ports to the secondary link.

  • Page 103: B Fiber-Optic Loss Budget Overview

    This appendix describes the calculated fiber-optic loss budget for the PORTswitch 900FP. Note the labeling on the fiber-optic cable that is being installed with the PORTswitch 900FP. Cables are tagged according to fiber type. Some examples of micron fiber types are: •...

  • Page 104: 10Basefl Loss Budget

    Calculated Loss Budget Table B-1 shows the calculated loss budget for 10BaseFL fiber-optic segments used to interconnect the PORTswitch 900FP with the cable plant. These measurements account for the connectors at either end of the segment. They are calculated using the transmit and receive optical power levels in decibels of optical power referenced to one milliwatt (dBm).

  • Page 105: Table B-1: 10Basefl Worst-Case Loss Budget (0ºc To 50ºc, End Of Life

    10BaseFL Loss Budget Table B-1: 10BaseFL Worst-Case Loss Budget (0ºC to 50ºC, End of Life Multimode, Graded Index Fiber Size (Microns) Unit of Measurement Measure 50/125 62.5/125 85/125 100/140 Numerical 0.275 0.26 aperture Minimum -22.8 -19.0 -16.8 -13.5 average transmit power T(avg) Minimum -32.5...

  • Page 106: Foirl Compatibility

    FOIRL Compatibility FOIRL Compatibility Introduction This section discusses the IEEE 802.3 standard for fiber-optic interrepeater link (FOIRL) devices that specifies peak power levels. The standard specifies a -27.0 dBm minimum peak receive power = -30.0 dBm). This power level represents a 2.5 dB lower receive R(avg) sensitivity.

  • Page 107: Table B-2: Foirl Worst-Case Loss Budget (0ºc To 50ºc, End Of Life

    When calculating the loss budget for fiber-optic devices, ensure that the higher output from the PORTswitch 900FP, in conjunction with the increased launch power into the two largest fiber sizes (85/125 and 100/140 microns), does not overload the receivers.

  • Page 108: Maximum Launch Power

    Introduction The loss budget for fiber-optic devices should include the maximum launch power amounts as shown in Table B-3 Maximum Launch Power Table B-3: PORTswitch 900FP Best-Case Maximum Launch Power Multimode, Graded Index Fiber Size (Microns) Unit of Measurement Measure 50/125 62.5/125...
  • Page 109 Maximum Launch Power Additional Attenuation When the PORTswitch 900FP is connected to short lengths of 85/125- micron or 100/140-micron fiber-optic cable, the connection might require additional attenuation to prevent exceeding the -9.0 dBm peak (-12 dBm average) received power level. To make that determination, complete the...

  • Page 111: C Connector Pin Assignments Overview

    Appendix Connector Pin Assignments Overview Introduction This appendix shows detailed illustrations of the connectors, cables, and adapters used on the PORTswitch 900FP. Connector Pin Assignments C–1...

  • Page 112: Adapters

    Adapters Adapters H8571-J Adapter The following illustration shows the H8571-J adapter (6-pin MMJ to 9- pin D-Sub connector) and its pin assignments: Figure C-1 H8571-J Adapter (6-pin MMJ to 9-pin D-Sub connector) C–2 Connector Pin Assignments...

  • Page 113: Figure C-2 H8575-A Adapter (6-Pin Mmj To 25-Pin D-Sub Connector

    Adapters H8575-A Adapter The following illustration shows the H8575-A adapter (6-pin MMJ connector to 25-pin D-Sub connector) and its pin assignments: Figure C-2 H8575-A adapter (6-pin MMJ to 25-pin D-Sub connector) _____________________________ Note ________________________ EOS/ESD protection devices are not shown on diagram _______________________________________________________________ Connector Pin Assignments C–3...

  • Page 115: D Remote Monitor Alarms And Events

    (MIB) groups based on the IETF draft standard MIB specified by RFC1757, where the primary purpose is to function within the PORTswitch 900FP, and not operate as an RMON probe. The RMON MIB groups include RMON Alarms and RMON Events.

  • Page 116: Alarms And Events Description

    RMON EventsGroup The RMON events group controls the generation and notification of events of the PORTswitch 900FP. Each entry in the eventTable describes parameters of the event that can be activated. Events are activated by alarms configured in the alarms group. You can specify, at your option, that a log entry is created for each eventEntry whenever the event occurs.

  • Page 117: Configured Alarms And Events

    Configured Alarms and Events Configured Alarms and Events Default Alarms and Events The PORTswitch 900FP RMON alarms and events MIB is configured with nine alarms and events. Table D-1 describes the PORTswitch 900FP configured alarms and events. Table D-1: Configured RMON Alarms and Events This Alarm Message...
  • Page 118 Configured Alarms and Events User-defined Alarms and Events In addition to the nine default alarms and events, you can also configure RMON alarms and events on any integer-like object supported by the module. D–4 Remote Monitor Alarms and Events...

  • Page 119: E Product Specifications

    Appendix Product Specifications Overview Introduction This appendix lists PORTswitch 900FP operating environment, connector, physical, and acoustical specifications. Product Specifications E–1...

  • Page 120: Operating Environment Specifications

    Operating Environment Specifications Operating Environment Specifications Table E-1 lists the PORTswitch 900FP operating environment specifications. Table E-1: PORTswitch 900FP Operating Specifications Parameter Specification Operating Environment 5°C to 50°C (41°F to 122°F) Operating Temperature Relative Humidity 10% to 95% noncondensing Altitude...

  • Page 121: Connector And Physical Specifications

    Connector and Physical Specifications Connector and Physical Specifications Table E-2 lists the PORTswitch 900FP connectors. Table E-2: Connectors Connectors Fiber-optic ST-type (DEChub ONE-MX has: one 8-pin MJ, one 6-pin MJ (OBR), one DB-9, one 15- pin D-sub, and one redundant power connector (D-Sub).)

  • Page 122: Table E-3: Portswitch 900Fp Physical Specifications

    Connector and Physical Specifications Physical Specifications Table E-3 lists the PORTswitch 900FP physical and certification specifications. Table E-3: PORTswitch 900FP Physical Specifications Parameter Specification Physical Height 44.45 cm (17.5 in) Width 4.45 cm (1.75 in) Depth 15.25 cm (6 in) 25.40 cm (10.0 in) with a DEChub...

  • Page 123: Acoustical Specifications

    Acoustical Specifications Acoustical Specifications Table E-4 lists the PORTswitch 900FP acoustical specifications. Table E-4: Acoustical Specifications Acoustics - Declared values per ISO 9296 and ISO 7779 Product Sound Power Level Sound Pressure Level WAd, pAm, (bystander positions) Idle/Operate DEFMM DEFMM + DEHUA...
