Quick Start Guide
Impinj R700 Antenna Hub
OVERVIEW
This guide provides basic instructions to configure an RFID system using the Impinj R700
Antenna Hub with an Impinj R700 RAIN RFID Reader. Additional details can be found in
the Impinj R700 Installation and Operations guide available at support.impinj.com.
Box Contents
Required Accessories Sold Separately
www.impinj.com/patents for
Connections and Ports
© 2021, Impinj, Inc. Version 2.0
•
1 x Impinj R700 Antenna Hub
•
Impinj R700 RAIN RFID Reader IPJ-R700
•
SMA to R-TNC cable IPJ-A3002-000
•
Antennas and additional RF Cable
•
1 SMA port to connect to Impinj R700 Reader port
•
8 SMA ports to connect to RFID Antennas
