- Page 1 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 U S E R M A N U A L BLAST CHILLERS AND FREEZERS Models: A5A12 et A5A20 A10A35 et A10A45 A13A60 et A13A80 FORM049C2/3...
-
Page 2: Important Recommendations
IMPORTANT RECOMMENDATIONS This cabinet is designed for use in restaurants, catering facilities, etc... It is not intended for industrial use. It should be installed by a specialised installer. Avoid installing the cabinet near a major source of heat or in direct exposure to sunlight. - Page 3 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 TABLE OF CONTENTS BLAST CHILLERS AND FREEZERS Models: A5A12 et A5A20 A10A35 et A10A45 A13A60 et A13A80 1. Energy efficiencies 2. Control panel 2.1 Description of control panel 2.2 Operating temperature cycle 2.3 Quick refrigeration cycle in "Probe"...
- Page 4 Capacity (Kg) : Capacity : Temperature of start of cycle : Temperature of end of cycle : min. Time of the cycle : 0,038 0,075 kWh / kg Energy consumption: A5A12 S/G Model: R404A Refrigerant: 3922 G.W.P. : Cooling Freezing Remote Type:...
- Page 5 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 A5A20 Model: R290 Refrigerant: G.W.P. : Cooling Freezing Integral Type: 0,12 Capacity (Kg) : Capacity : Temperature of start of cycle : Temperature of end of cycle : min. Time of the cycle : 0,031 0,049 kWh / kg...
- Page 6 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 A10A35 Model: R290 Refrigerant: G.W.P. : Cooling Freezing Integral Type: 2×0.14 Capacity (Kg) : Capacity : Temperature of start of cycle : Temperature of end of cycle : min. Time of the cycle : 0,033 0,073 kWh / kg...
- Page 7 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 A10A45 Model: R404A Refrigerant: 3922 G.W.P. : Cooling Freezing Integral Type: 1,40 Capacity (Kg) : Capacity : Temperature of start of cycle : Temperature of end of cycle : min. Time of the cycle : 0,037 0,056 kWh / kg...
- Page 8 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 A13A60 Model: R404A Refrigerant: 3922 G.W.P. : Cooling Freezing Integral Type: 1,80 Capacity (Kg) : Capacity : Temperature of start of cycle : Temperature of end of cycle : min. Time of the cycle : 0,034 0,082 kWh / kg...
- Page 9 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 A13A80 Model: R404A Refrigerant: 3922 G.W.P. : Cooling Freezing Integral Type: 3,50 Capacity (Kg) : Capacity : Temperature of start of cycle : Temperature of end of cycle : min. Time of the cycle : 0,038 0,077 kWh / kg...
-
Page 10: Description Of The Control Panel
BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 2. CONTROL PANEL IMPORTANT Regulation does not switch off general supply to the appliance. If the unit is not going to be used for a prolonged period switch off at unplug or turn off at the isolator to protect the refrigeration equipment. - Page 11 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 When a cycle is in progress, the turning leds (Led 4) are activated. It is possible to interrupt a cycle in progress at any time by depressing the "launch cycle" key (key 3) for several seconds. "rEG"...
-
Page 12: Defrost Cycle
BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 2.6 DEFROST CYCLE Before starting a cycle, check the amount of frost on the evaporator. If there is a great deal of frost it will block the evaporator and defrosting will be necessary. 2.6.1 NATURAL DEFROST The cabinet being switched off and stopped, leave the cabinet door open. -
Page 13: General Requirements
BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 3. UTILISATION OF THE CABINET 3.1 GENERAL REQUIREMENTS Position the load so that il will not hinder good ventilation which ensures distribution and circulation of cold air in the cabinet. If the cabinet is operated with the timer, check that the skewer probe is properly positioned on its support in order to measure temperature inside the cabinet properly. - Page 14 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 3.3 LOADING The unit should be loaded so that there is at least 15mm between items to allow air to flow around them. The refrigeration or freezing time depends on the load, its nature, and thickness of the foodstuffs.
-
Page 15: Stainless Steel Surfaces
BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 4. CLEANING WARNING Before all cleaning operations the cabinet should be SWITCHED OFF. THE USE OF CLEANING PRODUCTS AT A TEMPERATURE OF OVER 60°C IS STRICTLY PROHIBITED. Using a high pressure jet or lance is also prohibited on external and technical parts of the equipment. -
Page 16: Maintenance
BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 5. MAINTENANCE 5.1 FOREWORD RELATING TO STAINLESS STEELS Stainless steel is a type of steel designed to allow a thin protective layer to form on the metal surface to protect it against corrosion (Oxide film resulting from the chemical reaction of oxygen on the metal surface). - Page 17 BLAST CHILLERS AND FREEZERS USER MANUAL n° 6CE648137NU–0818 5.2 THE COMMONEST CASES OF CORROSION Floor cleaning Cleaning floor tiles (after building work or during normal service) is often carried out with very aggressive products. If such products are sprayed under pressure without caution, the splashes beneath appliances cause corrosion of bases and panels.
