  • Page 1 LS 1200d Pro Product Manual English...

  • Page 2: Important Safety Instructions

    Thank you for purchasing the Aputure® "Light Storm" series of LED light fixture - LS 1200d Pro. Aputure LS 1200d Pro is the latest high-power LED lamp with high light energy conversion rate, which can easily meet the illumination requirements of the studio. The ultra-high color rendering index can perfectly restore the skin color of the characters.
  • Page 3 10. To reduce the risk of fire or electric shock, do not disassemble this fixture. Contact cs@aputure.com or take the lighting fixture to qualified service personnel when service or repair is required. Incorrect reassembly may cause electric shock when the lighting fixture is in use.

  • Page 4: Fcc Compliance Statement

    unauthorized accessories are not covered by the warranty. The user may pay for maintenance. 21. This product is certified by RoHS, CE, KC, PSE, and FCC. Please operate the product in full compliance with relevant country's standards. Any malfunctions caused by incorrect use are not covered by warranty.

  • Page 5: Components List

    Components List Please make sure all accessories listed below are completed before using. If not, please contact with your sellers immediately. Protection Cover(1 pc) Lightning LS 1200d Pro Clamp(1 pc) Control Box(1 pc) LS 1200d Pro LS 1200 Series 7-Pin Neutrik®...

  • Page 6: Product Details

    Product Details 1. Lamp Head Bowens Mount Bowens Mount Release button 1200W Daylight COB chipset Bowens Mount Ratcheting Disk Hyper Reflector Brake Handle (LS 1200 Series) Cable Relief Hook 7-Pin Male Weatherproof Head Cable Connector Lamp support column 28mm | 1.125in (Junior Pin) 2.Control Box 7-Pin Female Head Cable Connector...
  • Page 7 Setting Up the Light 1. Attaching/detaching the Protection Cover Press the release button following the arrow and rotate the cover clockwise to detach the cover. To reattach the cover, insert it into the Bowens mount and rotate counter clockwise. Notice: Always remove the protection cover prior when turning on the light. Always re-install the cover when packing it away.
  • Page 8 Setting up the Lamp Head Put the Junior Pin of the lamp head into the hole of the lamp stand, and use the fastening knob of the lamp holder to lock it. The angle of the lamp head can be adjusted by rotating the handle on the side of the lamp head.
  • Page 9 5. Connect the Lamp Head to the Control Box Connect the Lamp Head to the control box using the LS 1200 Series 7-Pin Weatherproof Head Cable. * You can use the Cable relief hook to manage the connection line. *Disconnect the Head Cable by pulling up the collar on the connector. This will disengage its locking structure.
  • Page 10 2) Powering by DC Single-way DC power supply 720W 48V supports half power output, dual-way DC power supply 720W 48V supports full power output. If the A/B two-way power supply is not balanced, please promptly turn down the brightness of the lamp head, such as not turn down the brightness, in order to avoid damage, the control box will pop up to remind the interface and suspend the output of the lamp head after the 30-second countdown.
  • Page 11 2. Control 1) Rotate the Select Wheel to adjust the intensity of the light from 0-100% in 0.1% increments. The speed with which you turn the knob will change the rate of increase or decrease. 2) Press the MENU button to enter the Menu Interface. In the Menu Interface, you will find DMX Mode, Lead-follow Mode, Dimming Curve, Fan Mode, Studio Mode, Frequency Selection, Control System, Language, Factory Reset, Update, Product Information, Custom FX.
  • Page 12 *The fade-out time decreases as the percentage of brightness decreases. When the brightness output is 100%, the fade-out time is 60 seconds, which decreases in sequence. **If the signal is reconnected, the DMX console will continue to maintain the signal output as same as before.
  • Page 13 2.2) Lead-Follow Mode Lead-follow Mode: In the Lead-follow Mode, the user can set the device as the lead light and the follow light. When adjusting the functions and parameters of the lead lamp, the follow lamp will automatically adjust to the same state as the lead lamp. Set the Lead light: Connect the light fixtures through the DMX cable, select a Light fixture and press the MENU button to enter the menu interface.
  • Page 14 2.4) Fan Mode Press the MENU button to enter the menu interface, rotate the Select wheel and press to enter the Fan Mode. Turn the Select wheel to choose from smart/ high/ medium/ silent mode, and then press the Select wheel to confirm the selection. *Silent: Deactivate All Fans, Limit Output to 100W.
  • Page 15 2.7) Control System LS 1200d Pro has three remote control methods: Bluetooth, LumenRadio and Ethernet. Only one control mode can be used at one time. 2.7.1) Bluetooth (1) In the control interface, rotate the Select wheel to select and press to enter the Bluetooth mode interface.
  • Page 16 2.7.2) Lumenradio In the control interface, rotate the Select wheel to select and press to enter the Lumenradio interface. By rotating and pressing the Select wheel, you can switch the Lumenradio on or off, and pairing status. 2.7.3) Ethernet In the control interface, rotate the Select wheel to select and press to enter the Ethernet interface.
  • Page 17 2.9) Factory Reset Press the MENU button to enter the menu interface, rotate the Select wheel to select and press to enter the Factory Reset interface. The factory settings are: fan is in smart mode, light effect brightness value is 50%, normal mode brightness is 50%, Bluetooth mode is turned on, studio mode is turned off, dimming curve-linear, DMX channel number 001, English, fireworks light effect, frequency 5.
  • Page 18 2.11) Product Information Press the MENU button to enter the menu interface, rotate the Select wheel to select and press to enter product information, including the hardware version number and UID of the product. 2.12) Custom FX Press the MENU button to enter the menu interface, rotate the Select wheel to select and press to enter the Custom FX.
  • Page 19 3. Effects Press the Effects button to enter the Effects Mode. rotate the Select wheel to select and press to enter the Effects interface. You can choose from Paparazzi, Firework, Faulty Bulb, Lightning, TV , Pulsing, Strobe and Explosion effect. Paparazzi Effect Firework Effect Firework...
  • Page 20 Strobe Effect Explosion Effect Strobe Explosion *In the Explosion FX mode, the light effect needs to be triggered by the Effect button, and the light effect is triggered once by pressing the Effect button once. 1) Short press the select wheel to select brightness adjustment. Rotate the Select wheel to change the brightness of the lamp between 0%~100%.
  • Page 21 4. Connecting to DMX 1) Connect DMX controller and LS 1200d Pro OUTPUT DMX512 Connecting DMX to only one LS 1200d Pro OUTPUT DMX512 Daisy chaining multiple lights using DMX *The DMX interface schematic is shown in the pictures below: Signal Common Signal Common Data 2+ (Optional...
  • Page 22 5.Controlling Device Via DMX 1) Connect the DMX controller's OUTPUT to the 1200d Pro's controller INPUT as shown in the figure below. OUTPUT DMX512 2) DMX Chart Mode 8-bit 16-bit Function INT: 0-100% DMX Profile ： Lighting INT: 0-100% DMX Profile ： Paparazzi Fireworks Fault Bulb Lightning Pulsing Strobe Explosion...

  • Page 23: Specifications

    You can download the Sidus Link app from the iOS App Store or Google Play Store for enhancing the functionality of the light. Please visit sidus.link/app/help for more details regarding how to use the app to control your Aputure lights. Get Sidus Link Sidus.link/app/help...
  • Page 24 33.23*23.16*21.63 cm / Lamp Head w/o Y oke 13.08*9.11*8.51 in Dimensions 33.23*33.12*54.35 cm / Lamp Head w/ Y oke (L * W * H) 13.08*13.03*21.40 in 19.99*16.10*33.60 cm / Control Box 7.87* 6.33*13.22 in Lamp Head 8.95 kg / 19.73 lbs Weight Control Box 5.80 kg /...
  • Page 25 Photometrics LS 1200 LS 1200 LS 1200 Series Series Hy per Series Hy per Distance Bare Bulb Hy per Ref lector Ref lector Ref lector (Medium) (Narrow) (Wide) 6,380 lux / 83,100 lux / 22,400 lux / 13,010 lux / 598 f c 7,788 f c 2099 f c...
