- Page 1 ATS Laboratories A CIRS Company 900 Asbury Ave Norfolk, VA 23513 Model 527 Directional Discrimination Doppler Flow Phantom Revised February 2015 Made in USA...
-
Page 2: Product Description
INTRODUCTION The Doppler Flow phantoms provide a reliable means of evaluating a Doppler Flow Imaging System's ability to detect the location and direction of flow, flow velocity and sensitivity. The phantoms are constructed of a rubber-based tissue mimicking material. This material extends the useful life of the phantom by avoiding problems due to melting, freezing, dehydration and breakage from dropping, which are commonly associated with hydrogel (water-based) phantoms. - Page 3 TEST PERFORMED • Directional Discrimination • Flow Velocity • Sensitivity at varying depths • Maximum Penetration • Location of Flow SPECIFICATIONS GENERAL Overall Dimensions: 32.0 x 13.5 x 16.0cm* Weight: 15.2 lbs - 6.9 Kg* Housing Material: Wall Thickness: 1.0 cm* Scan Surfaces: Dimensions: 25.5 x 11.5cm @ 18°...
-
Page 4: Setup Procedure
Figure 1 SET-UP PROCEDURE NOTE: THE SET-UP OF THE MODEL 527 IS UNIQUE PLEASE FOLLOW THE DIRECTIONS GIVEN BELOW CAREFULLY. The Model 527 is designed to be used in conjunction with ATS Model 707 Doppler Test Fluid and the ATS Model 700 ATS Doppler Flow Controller and Pumping System. Equipment and Materials Required The Model 527 is supplied with various parts, please check to make sure you have received the following items:... - Page 5 4. Connect the Model 527 phantom to the pumping system as shown on the above diagram. 5. All of the flow channels need to be filled with test fluid to avoid an air-phantom interface. 6. When you are now ready to prime the pumping system and fill the flow channels, turn the "Speed Dial"...
-
Page 7: Statement Of Warranty
CARE AND HANDLING OF QUALITY ASSURANCE RUBBER-BASED PHANTOMS For best results the phantom should be kept clean at all times. In particular a build-up of dried coupling gel on the scan surface should be avoided. The phantom may be cleaned with warm water using a lint free cloth.
