SMARTCONNECT DOOR
Operation manual
Thank you for choosing SmartConnect door. With the SmartConnect door you can operate your FUHR motor lock
and many other devices via your smartphone. In conjunction with the SmartConnect app, your home will easily
become a smart home.
SmartConnect door controls and communicates via Wi-Fi. With the intuitive SmartConnect app, you can operate
the FUHR multi-point lock and query the state of your door. In addition, lighting, garage door, roller shutters and
much more, can be operated anywhere via the app. As an administrator, you authorise and block users, doors and
terminal devices, and keep track of all applications in the Logfile, also optionally on the Internet, at any time and in
any location. With SmartConnect door you always have your property in view.
Installing the SmartConnect door is quick and easy and can be retrofitted at no extra cost. In this operation
manual, all topics are explained step by step. In an overview, you will find compatible products that you can use for
a wide variety of applications. Further application examples can be found on
www.smart-door.net <
http://www.smart-door.net>
.
For your safety, all data is stored securely on your SmartConnect door – not on the Internet!
SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM
1/116

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartConnect door and is the answer not in the manual?

Questions and answers

Related Manuals for FUHR SmartConnect door

Summary of Contents for FUHR SmartConnect door

  • Page 1 With SmartConnect door you always have your property in view. Installing the SmartConnect door is quick and easy and can be retrofitted at no extra cost. In this operation manual, all topics are explained step by step. In an overview, you will find compatible products that you can use for a wide variety of applications.

  • Page 2: Table Of Contents

    13. Authorisations for applications 14. Add user 15. Logfile 16. Settings 17. User settings 18. Administrator settings 19. User administration 20. Schedules 21. LED signals 22. Reset (Factory Settings) 23. Technical data 24. FAQ SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 2/116...

  • Page 3: Smartconnect Door

    1. SMARTCONNECT DOOR SmartConnect door is the modern, smart video door intercom system that opens up new possibilities for you. Via tablet or smartphone, you can connect with your visitors anytime, anywhere, even when you are away from home. Furthermore, a SmartHome server is integrated in...

  • Page 4: General Information

    Please make sure that in the case of a data interruption, for example due to a power failure, relevant applications such as door locks can be operated differently (e.g. mechanically with a cylinder key). SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 4/116...

  • Page 5: Smartconnect Ecosystem

    SmartConnect and the individual components, such as the radio socket, is done using 868MHz radio. For use, connect the SmartConnect to a suitable power supply (SmartConnect easy: 110 – 230V AC (Schuko socket) / SmartConnect door: 12 – 24V DC) and install the corresponding SmartConnect app on your smartphone (see chapter Set up the SmartConnect <...
  • Page 6 To open the door by smartphone, you need a motorised FUHR multi-point locking system autotronic 834/834P or multitronic 881, which is usually equipped with a control or a radio reception module. If you also need the feedback on your smartphone, a smart radio module is needed to see if your door is open or closed.
  • Page 7 With additional transmitters or actuators, many other possibilities of SmartHome control are available. For example, you can monitor the condition of your casement windows (open or closed) via the app or open your garage door with your smartphone. Roller shutters can also be opened and closed. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 7/116...
  • Page 8 SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 8/116...
  • Page 9 To operate up to 4 applications with only one radio key, for example front door, side entrance and radio key garage door, the SmartConnect allows you to manage both channels and assign a time profile. FUHR art. no. VNZ80319 (4-channel radio key) Radio For a convenient, biometric door opening of 2 applications, via the SmartConnect, you can fingerprint manage both channels and assign a time profile.
  • Page 10 To open the door, the signal from the SmartConnect is received and fed to the motor lock, the control radio receiver is integrated in the control. FUHR art. no. depending on the version Radio To open the door, it receives the signal from the SmartConnect and directs it to the motor lock, receiver the radio reception module is plugged onto the motor.
  • Page 11 WeMo Switch Box: EAN 0722868905814 and WeMo Switch Insight Box: EAN 0722868992975 Philips HUE Lamp To turn Philips Hue lamps on and off via the SmartConnect app. Philips art. no. depending on the version SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 11/116...

  • Page 12: Set Up The Smartconnect

    (SSID+password) < https://apps.apple.com/us/app/fuhr-smartconnect/id900377387?itsct=apps_box&itscg=30200> < https://play.google.com/store/apps/details? id=de.smartwireless.smartconnect&pcampaignid=pcampaignidMKT-Other-global-all-co-prtnr-py- PartBadge-Mar2515-1> Integration The SmartConnect can be used in different ways: Wi-Fi Integration: Integration into existing Wi-Fi network (recommended for SmartConnect door and SmartConnect easy) SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 12/116...
  • Page 13 Connection via network cable: Direct connection to SmartConnect door via network cable (Only SmartConnect door). To do this, a network cable must be connected to the SmartConnect door and led out of the door. This network cable must then be connected to the router. (Recommended for SmartConnect door).
  • Page 14 2 You are now informed that the SmartConnect requires location authorisation to enable connection from different networks. Confirm the message by tapping OK . 3 Confirm the system pop-up by tapping Allow while using the app . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 14/116...
  • Page 15 4 Choose whether you want to use a SmartConnect easy or a SmartConnect door. 5 If you have not yet connected your SmartConnect to a power supply, connect it to a suitable power source. SmartConnect easy: Schuko socket SmartConnect door: 12 - 24V DC...
  • Page 16 8 The SmartConnect is now displayed in the overview under Available SmartConnects. Tap on your SmartConnect . Please follow the steps described in the next section. 2. Network configuration Option 1: Wi-Fi integration Recommended for SmartConnect easy. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 16/116...
  • Page 17 1 Tap on your desired Wi-Fi network . 2 Enter the password of your Wi-Fi network and tap Connect . 3 Confirm the system pop-up by tapping Connect . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 17/116...
  • Page 18 SmartConnect. Confirm your entry by tapping Save . Option 2: Connection via network cable (Only SmartConnect door) Recommended for SmartConnect door. Choose how to connect the SmartConnect to the network. In this case, select Connected by cable .
  • Page 19 2 Make sure the SmartConnect door is connected to the router via cable. Tap Connect . 3 Make sure your smartphone is connected to your home network. You may need to change to the network settings of the system. Option 3: Access point mode If a home network is not available, a direct connection can be established between the smartphone and SmartConnect.
  • Page 20 Note that the first user is also an administrator of the SmartConnect. Confirm your entry by tapping Save . A system pop-up may appear asking if your password should be saved in the keychain. Make a choice. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 20/116...
  • Page 21 2 Log in with your previously defined access data and tap Login . Activate the option Auto Login or Sign in with FaceID/TouchID to log in automatically and conveniently the next time you log in without entering your access data. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 21/116...
  • Page 22 As soon as the smartphone is connected to the Wi-Fi of the SmartConnect, LED 2 (SmartConnect easy) or LED 1 (SmartConnect door) lights up blue. LED 1 LED 2 LED 1 SmartConnect easy LED 2 SmartConnect door SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 22/116...

  • Page 23: Structure Of The App

    The app is divided into two areas: the content area and the menu bar. The menu contains the following menu items: Door: Shows the video image and enables its operation (only SmartConnect door). Go to chapter < https://docs.smartwireless.de/en/door-video/?type=scd> Home: The home area is the start page of the SmartConnect app. All configured applications are displayed and operated here.

  • Page 24: Connection Of A Doorbell

    "rings". To do this, it is necessary to pair the radio gong VNZ80122 with the SmartConnect door and link it as an action with the touch bell. To connect a radio gong, connect it to a suitable power supply (110 - 230V AC (Schuko socket) and follow the steps below.
  • Page 25 Then determine the product (Plug socket radio gong) which you want to use for the application. Tap Device . 3 Select the appropriate product (Plug socket radio gong) from the list and tap Select . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 25/116...
  • Page 26 SmartConnect. To do this, tap Pair now in the pop-up. 6 Now please follow the instructions described in the SmartConnect app exactly and complete the process by tapping Application paired . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 26/116...
  • Page 27 8 Press and hold the button of the touch bell of the SmartConnect door and then release it. A dialog window will now open. Tap Edit . 9 Tap Actions.
  • Page 28 11 Tap Save to save your changes. 2. Control of a bell that is not connected to an on-site doorbell button SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 28/116...
  • Page 29 SmartTouch UNIVERSAL radio module. You can ring either the touch bell of the SmartConnect door or an on-site doorbell button connected to the SmartConnect door. If the touch bell is not used, it can be deactivated in the settings of the touch bell, which also switches off the blue LED ring.
  • Page 30 Tap Device . 3 Select the appropriate product (SmartTouch radio receiver module) from the list and tap Select . 4 Now save the application. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 30/116...
  • Page 31 6 Now please follow the instructions described in the SmartConnect app exactly and complete the process by tapping Application paired . 7 The application has now been successfully paired and must be connected to the touch bell as an action. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 31/116...
  • Page 32 8 Press and hold the button of the touch bell of the SmartConnect door and then release it. A dialog window will now open. Tap Edit . 9 Tap Actions . 10 Tap on the previously created application (doorbell/radio gong) to link it to the touch bell as an action.
  • Page 33 Then tap the arrow in the upper left corner to return a level. 12 Tap Save to save your changes. 3. Control of a bell that is connected to an on-site doorbell button SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 33/116...
  • Page 34 The wireless pushbutton can be paired via the SmartConnect app and the action "Snapshot" can be assigned to it. As a result, the on-site bell button behaves like the integrated touch bell of the SmartConnect door and performs the same action when it is pressed (photo and push notification).
  • Page 35 Then determine the product (Wireless pushbutton) which you want to use for the application. Tap Device . 3 Select the appropriate product (Wireless pushbutton) from the list and tap Select . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 35/116...
  • Page 36 5 To use the application you need to pair your device with the SmartConnect. To do this, tap Pair now in the pop-up. 6 Now please follow the instructions described in the SmartConnect app exactly. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 36/116...
  • Page 37 In order for the on-site doorbell button to behave the same way as the integrated touch bell of the SmartConnect door (photo and push notification), the action “Snapshot” must be assigned to it. 8 Press and hold the button of previously created application (doorbell) and then release it.
  • Page 38 11 Tap Save to save your changes. In this scenario it usually makes sense to "lock" the touch bell, as this also deactivates the blue LED of the SmartConnect door. How the touch bell is locked is described below. Lock the touch bell...
  • Page 39 1 Press and hold the button of the touch bell of the SmartConnect door and then release it. A dialog window will now open. Tap Edit . 2 Activate the switch next to the Blocked menu item and then tap Save to save the change made.

  • Page 40: Administrators And Users

    To log in as an administrator, please follow the steps below. 1 Tap Settings in the main menu and then tap Administration . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 40/116...
  • Page 41 Individual users are authorised with name and password, and no devices (smartphone, tablet). You can access the SmartConnect from various devices via your login data. The following icons can be displayed to users: SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 41/116...
  • Page 42 The user is locked for the application The user is authorised to access the logfile The user receives push notifications The user has access to the camera The user is allowed to use Alexa to control doors SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 42/116...

  • Page 43: Door (Video)

    8. DOOR (VIDEO) The camera of the SmartConnect door enables you to see your visitors, speak to them and open the door directly via the SmartConnect app. Layout of the door area After opening the door area, you can start the video transmission immediately by tapping the play button.
  • Page 44 Logfile < https://docs.smartwireless.de/en/logfile/? type=scd> Depending on the type of installation (power supply of the SmartConnect door), the video image can be interrupted when the door is opened! SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 44/116...
  • Page 45 It rings When a visitor rings at your SmartConnect door and the SmartConnect app is open, a pop-up with a preview image appears. You now have the option to perform the following actions: Ignore - Ignores the ringing and closes the pop-up.
  • Page 46 For the assigned applications, all events are automatically stored in the logfile. Show logfile. You can decide whether you want to preview the logfile in Live image mode. Activate the corresponding switch. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 46/116...

  • Page 47: Home

    All devices connected to the SmartConnect are called applications. These can be, for example, the door with a FUHR multi-point lock multitronic 881 or autotronic 834, a radio-controlled socket or a radio gong.

  • Page 48: Set Up And Pair An Application

    Not every product is able to send feedback. The choice of the product decides whether it can be displayed, for example, whether the door lock is locked or not. If, for example, the FUHR radio receiver NB506NR is installed in the door, the status of the lock can be queried in the app. Your dealer will be happy to help you choose the right product.
  • Page 49 To operate an application with the app, it must be paired with the SmartConnect. Option 1: Pair immediately after creating After the successful creation of the application in the step before, a dialogue window appears. You now have the option to pair the application immediately. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 49/116...
  • Page 50 Option 2: Pair later If you have not paired an application immediately after creating it, you can also do so at a later time. Please follow the steps below. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 50/116...
  • Page 51 A dialog window will now open. Tap Edit . 2 Tap Pair . 3 Now please follow the instructions described in the SmartConnect app exactly and complete the process by tapping Application paired . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 51/116...
  • Page 52 After creating applications, only administrators are authorised to use them. See chapter Authorisations for Applications < https://docs.smartwireless.de/en/authorisations-for-applications/> User administration < https://docs.smartwireless.de/en/user-administration/?type=scd> for instructions on how to activate users for operations. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 52/116...

  • Page 53: Un-Pair And Delete An Application

    1 Press and hold the button of the application you want to un-pair and then release it. A dialog window will now open. Tap Edit . 2 Tap Un-pair . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 53/116...
  • Page 54 3 Now please follow the instructions described in the SmartConnect app exactly and complete the process by tapping Application un-paired . 4 Tap Delete . 5 Confirm the pop-up by tapping Delete . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 54/116...
  • Page 55 You can also tap Delete directly on the first step. This will open a pop-up indicating that the application has to be un-paired before deleting it. Tap Un-pair now and then follow the steps described above. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 55/116...

  • Page 56: Application Settings

    Detailed information on the different settings can be found in the explanations below. To change the arrangement of the applications, press and hold the button of an application until it enlarges. Now move the button to the desired position and release it again. Edit SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 56/116...
  • Page 57 Depending on the application, you may have more or less settings. Delete How to delete or un-pair applications is described in detail in the chapter Un-pair and delete an Application < https://docs.smartwireless.de/en/un-pair-and-delete-an-application/?type=scd> Push-settings SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 57/116...
  • Page 58 (see widgets on your iPhone and iPod touch < https://support.apple.com/en- gb/HT207122> The editing of iOS widgets can also be done by users without administrator rights. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 58/116...

  • Page 59: Authorisations For Applications

    1 Tap Home in the main menu to display your applications. 2 Press and hold the button of the application for which you want to assign or edit authorisations and then release it. A dialog window will now open. Tap Edit . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 59/116...
  • Page 60 Now select the user for whom you want to manage the authorisations. 5 To grant the user permanent access to an application, activate the switch Access right granted and confirm your selection by tapping Save . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 60/116...
  • Page 61 2 Press and hold the button of the application for which you want to assign or edit a time- restricted authorisation and then release it. A dialog window will now open. Tap Edit . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 61/116...
  • Page 62 4 An overview of the existing users and their authorisations appears. Now select the user for whom you want to assign or edit the time- restricted authorisation. 5 Tap Add access right . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 62/116...
  • Page 63 Make sure that the Authorised button at the top is always active. If this switch is disabled, the time- restricted rights are also inactive and the user cannot switch applications. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 63/116...
  • Page 64 To give a user access to multiple applications, you can also manage authorisations via Settings. To do this, follow the instructions described in the chapter User administration < https://docs.smartwireless.de/en/user-administration/?type=scd> SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 64/116...

  • Page 65: Add User

    Only an administrator is authorised to create users. Therefore, log in with your administrator access data (see chapter Administrators and Users < https://docs.smartwireless.de/en/administrators-and-users/?type=scd> and follow the steps below. 1 Tap the Plus icon in the top right of the header. 2 Tap Add user . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 65/116...
  • Page 66 As an administrator, you can edit the rights of users at any time. To do this, follow the instructions described in the chapter User administration < https://docs.smartwireless.de/en/user- administration/?type=scd> Save the new user by tapping Create or Send Invitation . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 66/116...
  • Page 67 Push: Activate this switch if the user is allowed to receive push notifications. Alexa access: Activate this switch if the user is allowed to use Alexa. Door: Activate this switch if the user is allowed to access the camera. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 67/116...

  • Page 68: Logfile

    < https://docs.smartwireless.de/en/user- administration/?type=scd> Events to which a photo has been assigned (SmartConnect door only) are marked with a small camera icon. By tapping the event, you can view details or the associated images. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM...

  • Page 69: Settings

    Administrator https://docs.smartwireless.de/en/user-settings/? settings < type=scd> https://docs.smartwireless.de/en/administrator- settings/?type=scd> Learn how to edit user lists or administer schedules in the chapter User administration < https://docs.smartwireless.de/en/user- administration/?type=scd> schedules < https://docs.smartwireless.de/en/schedules/? type=scd> SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 69/116...

  • Page 70: User Settings

    Select your preferred language. The check mark indicates which language is currently selected. After changing the language, the SmartConnect app switches back to the settings overview. The language was changed successfully. Manage Widgets SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 70/116...
  • Page 71 If you change a user or want to log in to another SmartConnect, you must log out first. With the log out step, you will also deactivate the Auto Login switch for this SmartConnect. You must therefore log in manually when you reconnect to the SmartConnect and you can activate the Auto Login switch again. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 71/116...
  • Page 72 1. Tap Settings in the main menu. 2. Tap User settings . 3. Make the desired changes and confirm your settings by tapping Save . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 72/116...
  • Page 73 The demo mode shows the basic functions of the SmartConnect app even without accessing a SmartConnect. Privacy Policy Here you can find the privacy policy < https://www.smartwireless.de/en/privacy-policy-smartconnect-app/> of the SmartConnect app. About Here you will find basic information about the SmartConnect app and the SmartConnect. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 73/116...
  • Page 74 The following information will be displayed: SmartConnect app Version SmartConnect software version SmartConnect basis system version Date/Time of the SmartConnect RF modul software version Serial number UUID SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 74/116...

  • Page 75: Administrator Settings

    The Administration area is reserved for administrators only. Once you log in as an administrator, you will be able to manage user lists and schedules and edit the advanced settings of the SmartConnect in this area. Login as administrator 1 Tap Settings in the main menu and then tap Administration . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 75/116...
  • Page 76 You can learn how to edit user-lists or manage users in the chapter User administration < https://docs.smartwireless.de/en/user-administration/?type=scd> Schedules You can learn how to create or edit schedules in the chapter Schedules < https://docs.smartwireless.de/en/schedules/?type=scd> Advanced settings Network configuration SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 76/116...
  • Page 77 Option 1: Wi-Fi integration Recommended operation of the SmartConnect easy. 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 77/116...
  • Page 78 Confirm your details by tapping Apply . 5 Connect your smartphone to the previously defined Wi-Fi and then select the appropriate SmartConnect in the SmartConnect app. Option 2: Network cable (only SmartConnect door) Recommended operation of the SmartConnect door. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 78/116...
  • Page 79 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . 3 Tap Network configuration . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 79/116...
  • Page 80 SmartConnect in the SmartConnect app. Option 3: Access point mode If a home network is not available, a direct connection can be established between the smartphone and SmartConnect. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 80/116...
  • Page 81 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . 3 Tap Network configuration . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 81/116...
  • Page 82 . Check the time of the SmartConnect regularly. This is the only way to correctly track which user has used an application and when in the logfile. 5. Confirm your entries by tapping Save . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 82/116...
  • Page 83 If your SmartConnect does not have an Internet connection, updates can also be performed offline. To do this, make sure that the SmartConnect app is not connected to a SmartConnect. You can find out how to log out of your SmartConnect in the chapter User settings < https://docs.smartwireless.de/en/user-settings/?type=scd> SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 83/116...
  • Page 84 Software update . 2 Select whether you want to download an update for a SmartConnect easy or a SmartConnect door. Then tap Download Update . 3 When the update is finished (100%) click on SmartConnects in the main menu at the bottom to connect to the appropriate SmartConnect.
  • Page 85 4 Select the SmartConnect on which you want to install the update. You are now connected to the SmartConnect. 5 Tap Settings in the main menu and then tap Administration . 6 Enter your administrator password and tap Login . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 85/116...
  • Page 86 You can change the name of your SmartConnect in the Settings. When using multiple devices, it makes sense to use as accurate a description as possible to differentiate the SmartConnect, for example SmartConnect Home or SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 86/116...
  • Page 87 4. By tapping Send system info , the e-mail client of your smartphone opens and generates an Email - if this has been set up. Check your details and send the e-mail with the attached log file to the address already entered. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 87/116...
  • Page 88 3. Tap Reset SmartConnect . 4. Confirm the pop-up by tapping Reset . This action cannot be undone! How to reset the SmartConnect without the app can be found in chapter Reset (Factory Settings) < https://docs.smartwireless.de/zuruecksetzen- reset-scd/> SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 88/116...

  • Page 89: User Administration

    Administrators can grant or revoke rights to users at any time. To manage the general rights of users, please follow the steps below. Rights include access to the camera of the SmartConnect door or the use of Alexa to operate applications.
  • Page 90 4 Select the user whose rights you want to edit. 5 Set the rights of the user by activating the corresponding switch . A list with explanations of the respective rights can be found below. Confirm your selection by tapping Save . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 90/116...
  • Page 91 In addition to the general rights, administrators can grant users permission to access specific applications at any time. This can be, for example, opening the front door or the possibility to switch a radio socket. To manage authorisations on user applications, please follow the steps below. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 91/116...
  • Page 92 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . 3 Tap User-list . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 92/116...
  • Page 93 4 Select the user whose rights you want to edit. 5 Tap Access rights . 6 Select the application for which you want to authorise the user. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 93/116...
  • Page 94 8 Enter the conditions Name, Beginning, End and Frequency in the window and confirm your entries by tapping Save . Further information on the different terms and conditions is provided below. 9 Tap Save again. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 94/116...
  • Page 95 Frequency: Interval of how often the user is authorised to use this application: once in the set time window, repeated weekly, monthly or annually. You can also assign authorisations through the application itself. To do this, follow the instructions described in the chapter Authorisations for Applications < https://docs.smartwireless.de/en/authorisations-for-applications/> SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 95/116...

  • Page 96: Schedules

    In the following steps you will learn how to set up and edit schedules. Create a new schedule 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 96/116...
  • Page 97 3 Tap Schedules . 4 Tap the plus icon below the schedule list. 5 Enter a name for the schedule and then tap the plus icon to set the rules. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 97/116...
  • Page 98 You can also activate multiple applications. Return to the overview of the rules by tapping the arrow in the top left corner. 8 Check your rules again and confirm your selection by tapping Save . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 98/116...
  • Page 99 If you set the validity up to a date or based on the repetitions, the schedule is disabled after the date or the defined number of repetitions expires. Edit schedules SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 99/116...
  • Page 100 To edit already created schedules, please follow the steps below. 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . 3 Tap Schedules . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 100/116...
  • Page 101 Active switch , or edit the rules. When you are finished editing, confirm your changes by tapping Save . To permanently remove the schedule, tap Delete . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 101/116...

  • Page 102: Led Signals

    21. LED SIGNALS You will find two LEDs on your SmartConnect door, which signal a specific device status depending on the colour and flashing status: LED 1 LED 2 Network State LED 1 Network display inactive Local network is set up...
  • Page 103 Not ready for operation flashes blue evenly Ready for operation lights up blue Bell status State LED 2 Bell push button deactivated Bell push button ready lights up blue Bell pressed flashes blue evenly SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 103/116...

  • Page 104: Reset (Factory Settings)

    The settings of the smartphone, such as the language of the app, are not reset. 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 104/116...
  • Page 105 3 Scroll down and tap Factory settings . 4 Tap Reset SmartConnect . 5 Confirm the pop-up by tapping Reset . This action cannot be undone! SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 105/116...
  • Page 106 SmartConnect app is not connected to a SmartConnect. You can find out how to log out of your SmartConnect in the chapter User settings < https://docs.smartwireless.de/en/user-settings/?type=scd> 1 Tap Settings in the main menu and then tap Reset SmartConnect via Bluetooth . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 106/116...
  • Page 107 2 The SmartConnect app now searches for available SmartConnects in your environment. Select the desired SmartConnect . 3 Confirm the pop-up by tapping OK . 4 Scan the enclosed QR code to continue. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 107/116...
  • Page 108 6 The SmartConnect app will ask you again if you really want to reset, as this action cannot be undone. Confirm the pop-up by tapping OK . 7 Confirm the pop-up that the reset is now executed by tapping OK . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 108/116...
  • Page 109 SmartConnect app is connected to your SmartConnect. You can find out how to log in to your SmartConnect in the chapter User Settings < https://docs.smartwireless.de/en/user-settings/?type=scd> 1 Tap Settings in the main menu and then tap Administration . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 109/116...
  • Page 110 Print the PDF document from your computer or directly from your smartphone and follow the steps described in the Reset via Bluetooth section to reset your SmartConnect. Keep the SmartConnect Master QR code in a safe place. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 110/116...
  • Page 111 Master QR code via the SmartConnect app. 1 Tap Settings in the main menu and then tap Administration . 2 Enter your administrator password and tap Login . SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 111/116...
  • Page 112 3 Scroll down and tap Factory settings . 4 Tap Regenerate master code . 5 Confirm the pop-up by tapping OK . Please note that the existing Master QR code loses its validity as a result of this action. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 112/116...
  • Page 113 Print the PDF document from your computer or directly from your smartphone and follow the steps described in the Reset via Bluetooth section to reset your SmartConnect. Keep the SmartConnect Master QR code in a safe place. SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 113/116...

  • Page 114: Technical Data

    WPA 2 after assigning the Wi-Fi password Connection encryption: SSL with RSA Certificate Conformity: EN 301 489, EN 62 311 EN 300 328, EN 60 950 EN 300 220 Declaration of conformity under: www.smart-door.net SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 114/116...

  • Page 115: Faq

    What settings can a user without administrator rights change? A user without administrator rights is only allowed to set and change his password. The administrator can unlock his applications and extend his rights (see chapter Authorisations for applications < SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 115/116...
  • Page 116 Wi-Fi router of your home network at the start of setup, LED 2 does not light up. As soon as your SmartConnect easy is connected to the network, LED 2 flashes green (= connection) or lights up orange (= connection successful). SmartConnect door Bedienungsanleitung 12/3/21, 3:56 PM 116/116...
