Eurosep Instruments IL 2050 Quick Start Manual

Spotlight IL 2050 Range
Fiber Optic LED Light Source
The LED IL2050 light sources have been developed to
meet the applications using optic light guides, including the
museum and architecture lightings.
Ideal to replace filament light sources, this range of light
sources is using high intensity LED's with a color
temperature from 3000 to 6500 °K, over mounted by a
specific optical reflector to obtain a slightly diverging light
beam.
The light intensity from the LED is factory adjustable
from 10W to 21W, the emitted intensity is comparable to a
halogen bulb light source greater than 100W.
The LED IL2050 light sources are equipped with a 30mm
diameter fiber optic adapter (effective optical diameter
25mm max).
1. Important Points
Before undertaking any manipulation or commissioning the device, it is
highly important to note the following points:
1.1. The unit must be placed on a flat and stable surface or securely attached using the 4 holes
of the mounting plate (see paragraph 3.1.), away from any heat source and all intense magnetic
fields.
1.2. Never switch on the unit while the embedding instructions are not carefully red and
followed (see paragraph 4).
1.3. Never disassemble the optical module or the power supply module.
1.4. Never touch the LED or the reflector with fingers.
1.5. Warning: This source is a A Class. In a residential environment, this product may cause
radio interferences. In this case, it may be asked the user to take the appropriated actions to
reduce these potential interferences.
1.6. Cleaning: The external parts of the generator can be cleaned with a non‐corrosive
conventional cleaning product (no spray) in using a soft cloth. Cleaning should be done with the
light source off and not undertaken before complete cooling.
