- Page 1 META Smart Plug Presa intelligente Smart plug Smart plug Prise intelligente Enchufe inteligente ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN INSTRUCTIONS - INSTRUCCIONES...
-
Page 3: Table Of Contents
Supported command classes ................. p. 22 EU declaration of conformity CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it. -
Page 4: Device Description
DEVICE DESCRIPTION META Smart Plug is able to detect overvoltage and/or overcurrent events and indicate them through a multicolor LED. Furthermore, it protects appliances from eventual overload. A very innovative design, which integrates a complex system that allows a precise energy consumption monitoring. The integration of these features in its very small size product, make it unique on the market. -
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS Power Supply 230 VAC ± 10% 50/60 Hz Maximum Load on Relay 2800 VA – 230 VAC – 12A Temperature limitation 105 °C Work Temperature From -10° to 40° C Power consumption < 0.4 Watt Radio frequency 868.4 MHz Protection system S0 and S2 Security Maximum distance... -
Page 6: Led Status Indicator
INCLUDING (ADD) THE DEVICE INTO AN EXISTING Z-WAVE NETWORK META Smart Plug is compatible with all Z-Wave/Z-Wave Plus certified controllers. The device supports both the Network Wide Inclusion mechanism (which offers the ability to be included in a network, even if the device is not directly connected to the controller) and Normal Inclusion. -
Page 7: Controlling The Device
A single click or two clicks on the Push Button can turn ON/OFF the load (Parameter No. 1). Controlling the device through Z-Wave network META Smart Plug can be controlled by any Z-Wave / Z-Wave Plus certified controller available in the market. All Z-Wave controllers can control the device by using the Basic Set command. -
Page 8: Associations
5-Control 2 Clicks: Nodes belonging to this groups will be controlled by a basic set if the button receives two clicks. TIP: META Smart Plug can control up to 8 devices for every group. In order to prevent the network from slowing down it is advisable to limit the associated... -
Page 9: Configurations
CONFIGURATIONS Parameter No. 1: Local load control (1 Byte) Defines which sequences of clicks control the local load. Configuration Result ONE_CLICK 1 click turn ON/OFF the local load TWO_CLICKS 2 clicks turn ON/OFF the local load ONE_CLICK or TWO_CLICKS (Default Value) 1 click or 2 clicks turn ON/OFF the local load Controlling the associated devices Parameter No. - Page 10 Overvoltage Alarm Parameter No. 4: Overvoltage level (2 Byte). Defines the voltage level (in Volts) beyond which an overvoltage event is identified and the overvoltage timer is activated. The timer is reset when the event ceases, i.e. when the voltage returns below the overvoltage level. As soon as an overvoltage event occurs, the LED starts a BLUE blinking.
- Page 11 Overcurrent Alarm Parameter No. 8: Overcurrent level (1 Byte). Defines the current level (in Amps) beyond which an overcurrent event is identified and the overcurrent timer is activated. The timer is reset when the event ceases, i.e. when the current returns below the overcurrent level. As soon as an overcurrent event occurs, the LED starts a GREEN blinking.
-
Page 12: Supported Command Classes
Parameter No. 11: Level used to control the devices associated to group 2 (1 Byte). Defines how to control the devices associated to the overcurrent alarm. Configuration Result SWITCH_OFF (Default Value) The associated devices are switched OFF SWITCH_ON The associated devices are switched ON LEVEL 1 - 99 The associated devices are set to the indicated level... - Page 14 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
