  • Page 1 Version 1.7 OXY5361A 3.5" SBC with Intel® Skylake-U SoC www.perfectron.com...
  • Page 2: Safety Information

    OXY5361A 3.5" SBC User’s Manual V1.7 Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.
  • Page 3: Revision History

    OXY5361A 3.5" SBC User’s Manual V1.7 Revision History Revision Date (dd.mm.yyyy) Changes V 0.9 01.06.2017 Draft V 1.0 13.06.2017 Initial Release Update latest product photo V 1.1 15.06.2017 Change JP13.JP14,JP15 default setting Change LVDS and CN18 pin define. V 1.2 20.06.2017...
  • Page 4: Table Of Contents

    OXY5361A 3.5" SBC User’s Manual V1.7 Table of Contents Safety Information ..............................1 Electrical safety ................................1 Operation safety ................................. 1 Statement ..................................1 Revision History ................................2 Packing list ..................................2 Chapter 1: Product Information ........................... 4 1.1 Block Diagram ..............................
  • Page 5: Chapter 1: Product Information

    OXY5361A 3.5" SBC User’s Manual V1.7 Chapter 1: Product Information 1.1 Block Diagram SATA www.perfectron.com...
  • Page 6: Key Features

    OXY5361A 3.5" SBC User’s Manual V1.7 1.2 Key Features System ® Intel Skylake-U series, BGA type ® ™ Intel Core i3-6100U (3M Cache, 2.3 GHz) (15W) CPU Type ® ™ Intel Core i5-6300U (3M Cache, 2.4 GHz) (15W) ® ™...
  • Page 7: Board Placement

    OXY5361A 3.5" SBC User’s Manual V1.7 1.3 Board Placement CN11 www.perfectron.com...
  • Page 8: Chapter 2: Jumpers And Connectors

    OXY5361A 3.5" SBC User’s Manual V1.7 Chapter 2: Jumpers and Connectors 2.1 Onboard connector and jumper list Label Function COM1 (Rear) RS232, DB9 connector DP1 (Rear) DisplayPort DP2 (Rear) DisplayPort LAN1 (Rear) RJ45 connector LAN2 (Rear) RJ45 connector USB1/2 (Rear) 2 x USB3.0...
  • Page 9: Connector And Jumper Pin Definition

    OXY5361A 3.5" SBC User’s Manual V1.7 JP24 LVDS Signal Power 2.2 Connector and jumper pin definition 2.2.1 Jumper JP1: Clear CMOS Jumper Function description Setting Normal Clear CMOS Default setting: 1-2 JP2: COM1 RI/+5V/+12V Jumper Function description Setting Ring Default setting: 1-2...
  • Page 10 OXY5361A 3.5" SBC User’s Manual V1.7 JP14: mPCIe1 signal select Jumper Function description Setting SATA PCIe Default setting: 2-3 JP15: mPCIe2 signal select Jumper Function description Setting SATA PCIe Default setting: 2-3 JP24 LVDS Signal Power SW1: LVDS Resolution Setting...
  • Page 11 OXY5361A 3.5" SBC User’s Manual V1.7 2.2.2 Connector AMP1 Pin Definition SP_OUTL- SP_OUTL+ SP_OUTR+ SP_OUTR- LVDS Pin Definition Pin Definition LVDS_CLK+ LVDS_CLK- LVDSA3+ LVDSA3- LVDSB3+ LVDSB3- LVDSA_CLK+ 11 LVDSB2+ LVDSA_CLK- 13 LVDSB2- 15 LVDSB1+ LVDSA2+ 17 LVDSB1- LVDSA2- 19 LVDSB0+...
  • Page 12 OXY5361A 3.5" SBC User’s Manual V1.7 CN18: LVDS Control connector PIN DEFINITION +12V +12V +12V Backlight Enable Backlight control 10 GND J1: DIO PIN DEFINITION 1 DIO0 2 DIO1 3 DIO2 4 DIO3 5 DIO4 6 DIO5 7 DIO6 8 DIO7 9 3.3V...
  • Page 13 OXY5361A 3.5" SBC User’s Manual V1.7 J10: LPC PIN DEFINITION +3.3VSB LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME# PLTRST#_BUF1 10 LPC_CLK_1 J11: Audio PIN DEFINITION 1 GND 2 MIC1_JD 3 MIC1_R 4 MIC1_L 5 FRONT_JD 6 FRONT_R 7 FRONT_L 8 LINE1_JD 9 LINE1_R...
  • Page 14 OXY5361A 3.5" SBC User’s Manual V1.7 J12: COM2 RS232/422/485 Note: RS232/422/485 can be set by BIOS. Pin RS232 mode (Default) RS422 mode RS485 mode DATA- DATA+ J14: USB2.0 x2 PIN DEFINITION 1 +5V 2 USB5- 3 USB5+ 4 GND 5 GND...
  • Page 15: Chapter 3: Quick Installation Guide

    OXY5361A 3.5" SBC User’s Manual V1.7 Chapter 3: Quick Installation Guide A default screw for usage of Half size mSATA www.perfectron.com...
  • Page 16: Chapter 4: Ami Bios Utility

    OXY5361A 3.5" SBC User’s Manual V1.7 Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: ...
  • Page 17: Main Menu

    OXY5361A 3.5" SBC User’s Manual V1.7 4.3 Main Menu The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. www.perfectron.com...
  • Page 18: Advanced Menu

    OXY5361A 3.5" SBC User’s Manual V1.7 4.4 Advanced Menu The Advanced Menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.
  • Page 19 OXY5361A 3.5" SBC User’s Manual V1.7 4.4.1 Trust Computing 4.4.2 IT8786 Super IO Configuration www.perfectron.com...
  • Page 20 OXY5361A 3.5" SBC User’s Manual V1.7 4.4.2.1 Serial Port 1 Configuration 4.4.2.2 Serial Port 2 Configuration www.perfectron.com...
  • Page 21 OXY5361A 3.5" SBC User’s Manual V1.7 4.4.3 Hardware Monitor www.perfectron.com...
  • Page 22 OXY5361A 3.5" SBC User’s Manual V1.7 4.4.4 CPU Configuration 4.4.5 SATA Configuration www.perfectron.com...
  • Page 23 OXY5361A 3.5" SBC User’s Manual V1.7 4.4.6 CMS Configuration www.perfectron.com...
  • Page 24 OXY5361A 3.5" SBC User’s Manual V1.7 4.4.7 USB Configuration www.perfectron.com...
  • Page 25: Chipset

    OXY5361A 3.5" SBC User’s Manual V1.7 4.5 Chipset 4.5.1 System Agent (SA) Configuration www.perfectron.com...
  • Page 26 OXY5361A 3.5" SBC User’s Manual V1.7 4.5.1.1 Graphic Configuration 4.5.1.1.1 LCD Control www.perfectron.com...
  • Page 27 OXY5361A 3.5" SBC User’s Manual V1.7 4.5.1.2 Memory Configuration 4.5.2 PCH-IO Configuration www.perfectron.com...
  • Page 28: Security

    OXY5361A 3.5" SBC User’s Manual V1.7 4.6 Security Administrator Password Set administrator password. User Password Set user Password. www.perfectron.com...
  • Page 29: Boot Menu

    OXY5361A 3.5" SBC User’s Manual V1.7 4.7 Boot Menu This section is used to configure the boot features. 4.8 Save & Exit www.perfectron.com...
