OPERATING INSTRUCTIONS
Please read the operating instructions before using the AllevaRed Light
Therapy Belt. Keep this manual for reference.
POWERING THE ALLEVARED WITH THE WALL ADAPTER
1. Connect the male end of the remote control cable to the DC power port
exiting the AllevaRed belt.
2. Connect the wall power adapter to the female end of the remote
control cable.
3. Plug the power adapter into a standard wall outlet.
POWERING THE ALLEVARED WITH THE USB ADAPTER
1. Connect the male end of the remote control cable to the DC power port
exiting the AllevaRed belt.
2. Connect the USB adapter to the female end of the remote control
cable.
3. Insert the other end of the USB adapter into a USB device, such as a
laptop or computer. Alternately, you may insert the USB connector into
a standard mobile phone 5V–1A or 5V–2A USB charging adapter and
then plug the adapter into a wall outlet.
WARNING: The AllevaRed cannot be used with a 12V USB charging
adapter.
POWERING THE ALLEVARED WITH AN EXTERNAL BATTERY
The AllevaRed supports the use of a 5V external battery, also called a
power bank. The external battery is not included and must be purchased
separately from other retailers. To power the AllevaRed with an external
battery:
1. Connect the male end of the remote control cable to the DC power port
exiting the AllevaRed belt.
2. Connect the external battery pack to the female end of the remote
control cable, via the cable included with the battery pack.
3. Place the battery in the pocket at the front of the belt.
10 AllevaRed User Manual Lifepro
USING THE CONTROL PANEL
1. Display Window: Shows the current working
time, intensity, or mode.
2. Intensity Button: Press to adjust the light
intensity level from L0–L4.
3. Time Button: Press to set the time duration
from 5–30 minutes, in 5-minute increments.
The default time is 5 minutes.
4. On/Pulse/Off Button: Press the button
once to turn on the device, press a second
time to turn on 10 Hz pulsed light therapy,
press a third time to turn off the device.
5. Mode Button: Press to toggle through
the three modes: red mode (660nm),
near-infrared mode (850nm), and red +
near-infrared mode (660+850nm).
MODES
Red mode (660nm) is best for skin health and has anti-aging properties.
Near-infrared mode (850nm) is stronger and is best for decreasing
inflammation and repairing deeper tissues, such as muscles and joints.
Red + near-infrared mode (660nm + 850nm) combines the benefits of the
first two modes.
INTENSITY OPTIONS
Five different intensity settings allow you to
choose the right setting for your particular
need. Each of the five settings offers a
different power (in Watts) to help reduce
inflammation, increase blood flow, relieve
pain, and lose fat.
1
2
+ / -
R
3 + 5
I
4
INTENSITY POWER
LEVEL (IN WATTS)
L0 0.9W
L1 4.9W
L2 8.5W
L3 12.3W
L4 16.0W
Wellness Recovery Collection 11
