Summary of Contents for Akko PC75

Page 1 Plus Multi-modes 用户手册 User Manual...
Page 2 目录规格参数组合键功能系统功能(Windows) 系统功能(Mac) 背光调节蓝牙使用指南蓝牙使用步骤1 蓝牙使用步骤2 按键 / 灯光自定义说明和调用说明 Akko售后服务规范...
Page 3: Table Of Contents
Menu Technical Speciﬁcations HotKeys System Commands (Windows) System Commands (Mac) Backlight Settings Bluetooth Feature Overview Bluetooth Setup Instruction 1 Bluetooth Setup Instruction 2 Key/Lighting Effects Customization Instruction Akko Warranty and Service Statement...
Page 4 规格参数尺寸重量产地类型机械键盘约331*115*46mm 约1kg 中国连接方式连接线电池容量键帽蓝牙 / 无线 / 有线 Type-C To USB 3000mAh PBT材质按键/灯光自定义多媒体键全键无冲支持支持键盘需在有线模式下配合驱动进行自定义...
Page 5: Bluetooth Setup Instruction
组合键功能 Insert 我的电脑播放 / 暂停静音电子邮件上一首 < 音量减小 Windows搜索下一首 > 音量增加浏览器主页 Insert 将 W A S D 与 ↑↓ ← → 键多媒体播放器计算器对调...
Page 6 系统功能(Windows) ～ Ctrl 锁Win键恢复出厂设置将Ctrl变成Menu （App）键按下切换音量/ 灯光亮度 Fn + 左Win 长按 Fn + ~ 5秒长按Fn + 右Ctrl 3秒旋钮功能...
Page 7 系统功能(Mac) F9 F10 F11 F12 ～降低显示屏亮度向后跳(音频) 调低音量右Alt Command 增加显示屏亮度暂停/播放(音频) 调高音量开放任务控制向前跳过(音频) 左Win Option Fn + （F1 ～ F12）呼出Siri 静音左Alt Command F1 ～ F12...
Page 8 背光调节 Caps Lock 电量指示灯锁Win Home PgUp PgDn ↑ Ctrl 常亮、涟漪、如影随形、川流不息、流星 “↑” 灯光变亮 Home Fn+Z 繁星点点、霓虹、光波、层出不穷、彩泉涌动侧边灯光亮度切换灯光变暗 “↓” PgUp 斜风细雨、踏雪无痕、聚合、一石二鸟、百花争艳灯光方向向左 PgDn “←” Fn+X 呼吸、极光、正弦波、雨滴、峰回路转侧边灯光速度切换...
Page 9 蓝牙使用指南 2.4G 蓝牙设备1 短按回连蓝灯慢闪；背面开关示意长按配对蓝灯快闪蓝牙设备2 左： Windows 蓝牙设备3 中：关电源，切换为USB模式短按回连绿灯慢闪； 2.4G无线设备（默认Windows）右: Mac 完成匹配后恢复灯效有线模式...
Page 10 Fn + E / R / T便可进行蓝牙匹配， E / R/ T按键上蓝灯快闪，即可进入蓝牙匹配模式。 2.选择蓝牙设备记忆组为便于记忆对应设备名称，本机蓝牙有5.0和3.0两组架构，蓝牙5.0为Akko PC75B-1 / Akko PC75B-2 / Akko PC75B-3；蓝牙3.0为AKK0 PC75B BT3.0；您通过Fn + E / R /T，完成匹配设定后，系统会默认记忆您关闭蓝牙模式前最后一次连接的设备。 3.设备匹配使用您的PC、 PAD、手机等设备，开启蓝牙进行匹配，第一次匹配过程中您所使用的设备会搜索出...
Page 11 蓝牙使用步骤2 4.设备切换完成了3组蓝牙设备的匹配后，系统会自动记忆；通过短按Fn+E / Fn+R / Fn+T ，可快速切换3个蓝牙设备使用。 5.设备关闭键盘在不使用的时候，关闭背面开关电源，可节省电量；键盘空闲15分钟之后，进入休眠模式，可按任意键唤醒。注：使用Windows系统，开启省电模式会影响蓝牙设备的休眠唤醒时间。 6.设备匹配如忘记设备，或者蓝牙连接出现混乱的情况，如需重新连接蓝牙设备时，需要删除电脑中原有的PC75蓝牙设备记忆。...
Page 12 按键 / 灯光自定义说明和调用说明 1. 键盘按键/灯光自定义需在有线模式下配合驱动进行。 2. 键盘有线模式下灯光可搭配驱动实现音乐律动。 3. 按键/灯光自定义及调用说明；请在我司官网下载 “Akko Cloud” 驱动。 4. 驱动下载地址www.akkogear.com...
Page 13 Akko 售后服务规范 1.Akko机械键盘享受非人为损坏1年保修服务，即从购买日起， 1年以内免费维修。 2.如超过条款1的保修期限， Akko官方将收取不超过市场平均价格的费用提供维修服务。 3.用户自行拆开键盘视为放弃免费维修服务，即使1年内损坏，也按照售后服务条款2执行。 4.不同销售平台的特殊服务条款，以购买平台规则为准。注意人为损坏不局限于键盘进水、高处坠落、过度用力拉扯线材等，键盘为电子产品，请按照电子产品事项保护方式爱惜使用。售后电话： 0755-27728007 售后QQ： 981572876 *官方售后服务时间为每周一至周五上午10： 00至下午18： 00，节假日以国家法定节日休息为准。 *因受维修时间，物流时间，零件采购时间等不可控因素，售后时间会有不同，以实际损坏情况评估为准，请用户耐心等待。...
Page 14: Technical Specifications
Technical Speciﬁcations Dimensions Weight Type Country of Origin Approximately Approximately Mechanical Keyboard China 331*115*46mm Connection Interface Keycap Battery Capacity Type-C To USB 3000mAh PBT Material Bluetooth/USB/2.4Ghz Key/Lighting Effects Customization Multimedia Keys N-Key Rollover The keyboard can only be customized with driver in wired mode...
Page 15: Hotkeys
HotKeys Insert File Explorer Pause /Playback Mute E-mail Previous Song < Decrease Volume Windows Search Next Song > Increase Volume Browser Homepage Insert Swap W A S D with ↑↓ ← → Calculator Media...
Page 16: System Commands (Windows)
System Commands (Windows) ～ Ctrl Lock Windows Key Press Fn and left Win key Hold down Fn and press ～ key for 5S Restore Factory Settings Press Revert Ctrl into Menu (APP) key Hold down Fn and press right Ctrl for 3S Adjust volume / light brightness...
Page 17: System Commands(Mac)
System Commands(Mac) F9 F10 F11 F12 Decrease display brightness Skip back (Audio) Volume down Right Alt Command Increases display brightness Pause/Play (Audio) Volume up Fn + （F1 ～ F12） Open mission control Skip forward (audio) Left Win Option F1 ～ F12 Activate Siri Mute Left Alt...
Page 18: Backlight Settings
Backlight Settings Caps Lock Home Battery Level Indicator Lock Win PgUp PgDn ↑ Ctrl “↑” Fn+Z Bright Home Effect 1、 Effect 2、 Effect 3、 Effect 4、 Effect 5 PC Case Light PgUp Effect 6、 Effect 7、 Effect 8、 Effect 9、 Effect 10 “↓”...
Page 19: Bluetooth Feature Overview
Bluetooth Feature Overview 2.4G Short press to connect with slow Bluetooth device 1 ﬂashing blue LED; Back Switch Indicator Press and hold to pair device with Bluetooth device 2 fast ﬂashing blue LED. Left : Windows Bluetooth device 3 Middle: Switch to USB mode and Short press to connect with slow 2.4G wireless device stop charging.
Page 20: Bluetooth Setup Instruction 1
To help user recognize individual Bluetooth device, the keyboard is equipped with both Bluetooth 5.0 and 3.0 frameworks. The device name under the Bluetooth 5.0 framework is Akko PC75 BT-1 / Akko PC75 BT-2 / Akko PC75 BT-3 while the device name under Bluetooth 3.0 is AKK0 PC75 BT3.0.
Page 21 The keyboard can be paired with PC, Pad, smartphone and other devices with Bluetooth turned on. When you ﬁrst try to search Bluetooth devices, two groups of device names shall appear with Akko PC75 BT3.0 (Bluetooth 3.0) and Akko PC75-1 (Bluetooth 5.0). Select a Bluetooth group based on your preferences (Note: some devices can only search for the Bluetooth 5.0 group).
Page 22: Key/Lighting Effects Customization Instruction
Key/Lighting Effects Customization Instruction 1.The key/lighting effects customization can be programmed by Akko driver. 2. In wired mode, the lighting effects can also achieve audio visualizer effects with Akko driver. 3. Please download the Akko Cloud driver on our website.
Page 23: Akko Warranty And Service Statement
1. Akko provides 1-yr warranty for customers in mainland China. For other regions, please contact your seller (Akko distributor) for speciﬁc warranty policy. 2. If the warranty window expires, customers need to pay for repairs. Akko will also provide instructions if users prefer to repair the keyboard by themselves.
Page 24 www.akkogear.com 扫描关注官方微信扫描关注官方微博 @akkogear...
