Page 13
3084 Technical Specifications Dimensions 315x126x38mm Weight Approximately 0.85KG Country of Origin China Type Mechanical Keyboard Keycap PBT Material Interface Type-C To USB Multimedia Keys N-Key Rollover Custom Keys YES (use Akko Marco V1.0)
Page 14
3084 HotKeys Insert < > Ctrl File Explorer Pause/Playback Mute E-mail Previous Song < Decrease Volume Windows Search Next Song > Increase Volume Browser Homepage Calculator Swap W A S D with ↑↓ ← → Media Insert Hold down FN and press right Ctrl Revert Ctrl into Menu (APP) key...
Page 15
3084 System Commands ~ Press Fn and left Win key Lock Windows Key Hold down Fn and press~key Restore Factory Settings...
Page 16
3084S Single-Color Backlight *Backlight function is only available on the backlight version of 3084s. ↑ The adjustments on the left is Fn+Del “↑” Bright for generic lighting effects. “↓” Lighting effects cycles among Some lighting effects cannot Set animation direction to left “←”...
Page 17
3084S Custom Backlight ↑ 1. The keyboard provides 4 groups of Fn + (F9 ~ F12) customizable lighting effects. The system has 4 groups of default pre-loaded lighting effects that can be triggered. 2. Press Fn + (F9 ~ F12) to trigger custom lighting effects. 3.
Page 18
Macro mode will be exited. You need to switch to the Macro mode again to use programmed keys. 4. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the two keys in the order of A followed by B.
Page 19
Akko Macro V1.0 Macro Setup Instruction 2 Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key Fn + Custom Key Fn+Esc Long Press Fn +Left Win (Press Keys to Store) (End Recording) Record the next Key Long Press Fn +...
Page 20
Akko Macro V1.0 Macro Setup Instruction 3 Macro Recording Example: Define “A” as “AKKOGEAR” Step 1: Press Fn + left Win for 3 seconds to enter the Macro mode. Step 2: Press Fn + ESC to launch Macro editor. Step 3: Press Fn + A. This means we choose key “A” to record.
Page 21
(Akko distributor) for specific warranty policy. 2. If the warranty window expires, customers need to pay for repairs. Akko will also provide instructions if users prefer to repair the keyboard by themselves. However, users shall take full responsibility for any loss happened during self-repair.
