Summary of Contents for Creative XP GlassOwl
-
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS Introduction ....................4 Product Overview ..................6-7 Power Supply ....................8 Changing the Modes ................9-11 Download files to the PC ...............12 Functions ....................13-16 Tips & Warnings ...................17-19 Warranty ....................20-21 Complete Hunter Kit ...............22-30... -
Page 4: Introduction
READ the instructions carefully before using your night vision binoculars. Use the GlassOwl to view your surroundings in low light conditions or even in complete darkness with the built-in infrared light. You can even take pictures and video which will be stored on an included 32 GB micro SD card. - Page 5 AMERICAN OF ADVENTURE...
-
Page 6: Product Overview
Product Overview 1 2 3 4 1 - Infrared illuminator 2 - IR LED focus wheel 3 - Objective lens 4 - Objective focus wheel 5 - Operating zone 6 - TF card socket /USB 2.0 socket 7 - Eyecup 8 - Ocular lens 9 - Battery compartment... - Page 7 Product Overview 11 12 14 15 11 - Menu Switch for auxiliary light and adjustment of the screen brightness 12 - UP 13 - Power/Function Check 14 - Functions(for photo shooting, video shooting, videoing, playback, and video output) 15 - DOWN...
-
Page 8: Power Supply
Long press button #13 for 3 seconds, look through Eyecup #10. The GlassOwl works well if the screen lightens us and the icons are as in Picture 1. In any mode, long press #13 for 2 seconds to turn the GlassOwl o . Auto Power O Th GlassOwl will turn o if there is no operation within 3 minutes. -
Page 9: Changing The Modes
Changing the Modes Scenery Observation In the observing (photo shooting) mode, aim the objects which need to be observed, look at the screen from Eyecup #8. And adjust the objective focus wheel #4 to get the sharpest image. Automatic fine-tuning control is operated by the viewer according to the average brightness of scenery centrally. - Page 10 Changing the Modes Changing the Modes The GlassOwl has 3 modes and you can switch between them by pressing the MODE (#14) button. Photo Mode For taking photos Video Mode For taking videos Playback Mode For viewing recorded files Announcements In any mode, the menu will disappear if there is no action within 3 seconds.
- Page 11 Changing the Modes Video Mode In the observing mode, press#14 shortly to get into the video shooting mode. Press "OK" #13 to start shooting (shown as "START"); the time displayed on the left corner turns into timekeeping, and the viewer record the video automatically.
-
Page 12: Download Files To The Pc
Download Files to the PC How to download files to the PC? The GlassOwl ELITE features a USB 2.0 interface. Connect the viewer to the computer equipment by USB cable. The battery is charging when the Binocular connects with PCs. -
Page 13: Functions
Functions Brightness Adjustment In the observing(photo shooting and videoing) mode, press #11 for two seconds to enter the brightness adjustment menu (as Picture 2), the number after "SCREEN:" means the current brightness of the screen. The brightness ranges from 1 to 10 by pressing #12 and #15. After the desired brightness is selected, the brightness adjustment mode will automatically switch o in 3 seconds. - Page 14 Functions Time Setting Long press #14 to start the menu. By pressing #12 and #15 to select the "Time Setting" option, short press #13 (OK) to enter. You can switch between the year/month/day/hour/minute/second -> press“UP” and “DOWN” to adjust -> press#13 (OK) again to save. Menu Setting Long press #14 to enter the menu.
- Page 15 Functions Basic Parameters Type Items Index Magnification Dimension of Objectives φ35mm Optical 8.5° Performance Ocular Adjustable Range ±0.5 Observing Distance (Low Light Environment) 2m~∞ Observing Distance (Full Dark Environment) 2m~500m Sensor Low Illumination HD 1 / 3 COMS Photo 3200X1800 Digital Video 720P...
- Page 16 Functions Configuration Standard Basic Parameters Power Operating Voltage 3.7V DC Replaceable Battery 3200X1800 Charging Source Rechargeable lithium-ion battery, 18650 Model Other Measurement(L*W*H) 210mm X 145mm X 75mm Weight 550g Configuration Standard Items Amount Objective Lens Shelter External Power Adapter USB Cable NV600 PRO Binocular Pouch Shoulder Strap...
-
Page 17: Tips & Warnings
Wipe any dust from the lenses before cleaning them. Wipe it gently with a soft cleaning cloth. If you don't use the GlassOwl for a long time, please keep charging the battery occasionally to avoid battery life damage. 2. Focusing the image Target the object you would like to view and turn the object-focusing knob until the image on the screen comes sharp and clear. - Page 18 The runtime is up to 12 hours with the infrared illuminator (auxiliary light) OFF and up to 3 hours with the IR illuminator ON. 6. Can the GlassOwl work through windows? Whether or not the infrared light (IR) is turned ON, the device cannot observe...
- Page 19 Tips & Warnings 7. Do not use the GlassOwl binoculars in water as it will damage the device and the damage will not be covered by the warranty. 8. One can use the GlassOwl ELITE in 100% darkness, low light, daytime.
-
Page 20: Warranty
Warranty Your CREATIVE XP product is warranted to be free of defects in materials and workmanship for one (1) year after the date of purchase. These warranties do not cover consumer caused damages such as misuse, abuse or repairs attempted by the consumer. - Page 21 CREATIVE XP product must be delivered in either its original carton or a similar package a ording an equal degree of protection. CREATIVE XP will not be responsible for any loss or damage incurred in connection with the return of this product. If defective, the product will be repaired or replaced at CREATIVE XP’s option, at no...
-
Page 22: Complete Hunter Kit
THE COMPLETE HUNTER KIT...
