Summary of Contents for Creative XP GlassCondor ELITE

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS Introduction ....................4 Product Overview ..................6-7 Power Supply ....................8 Changing the Modes ................9-11 Download files to the PC ...............12 Functions ....................13-16 Tips & Warnings ...................17-19 Warranty ....................20-21 Complete Hunter Kit ...............22-34...
  • Page 4: Introduction

    Introduction Thank you for purchasing the Creative XP® GlassCondor Night Vision Binoculars Elite. This manual will help you optimize your viewing experience by explaining how to utilize the binoculars’ controls and features, and how to care for them. READ the instructions carefully before using your night vision binoculars.
  • Page 5 AMERICAN OF ADVENTURE...
  • Page 6: Product Overview

    Product Overview 1 2 3 4 1 - Infrared illuminator 2 - IR LED focus wheel 3 - Objective lens 4 - Objective focus wheel 5 - Operating zone 6 - TF card socket /USB 2.0 socket 7 - Eyecup 8 - Ocular lens 9 - Battery compartment...
  • Page 7 Product Overview 11 12 14 15 11 - Menu Switch for auxiliary light and adjustment of the screen brightness 12 - UP 13 - Power/Function Check 14 - Functions(for photo shooting, video shooting, videoing, playback, and video output) 15 - DOWN...
  • Page 8: Power Supply

    Power Supply Battery Installation This night vision Binocular requires an 18650 Model lithium-ion battery (3.7V). Turn the battery cover counter-clockwise to unscrew the battery cover, insert the battery with negative electrodes bottomed, and then tighten the battery cover clockwise. Please ensure the battery would be charged for at least 10 hours at the first time to make it works best.
  • Page 9: Changing The Modes

    Changing the Modes Scenery Observation In the observing (photo shooting) mode, aim the objects which need to be observed, look at the screen from Eyecup #8. And adjust the objective focus wheel #4 to get the sharpest image. Automatic fine-tuning control is operated by the viewer according to the average brightness of scenery centrally.
  • Page 10 Changing the Modes Changing the Modes The GlassCondor has 3 modes and you can switch between them by pressing the MODE (#14) button. Photo Mode For taking photos Video Mode For taking videos Playback Mode For viewing recorded files Announcements In any mode, the menu will disappear if there is no action within 3 seconds.
  • Page 11 Changing the Modes Video Mode In the observing mode, press#14 shortly to get into the video shooting mode. Press "OK" #13 to start shooting (shown as "START"); the time displayed on the left corner turns into timekeeping, and the viewer record the video automatically.
  • Page 12: Download Files To The Pc

    Download Files to the PC How to download files to the PC? The GlassCondor ELITE features a USB 2.0 interface. Connect the viewer to the computer equipment by USB cable. The battery is charging when the Binocular connects with PCs.
  • Page 13: Functions

    Functions Brightness Adjustment In the observing(photo shooting and videoing) mode, press #11 for two seconds to enter the brightness adjustment menu (as Picture 2), the number after "SCREEN:" means the current brightness of the screen. The brightness ranges from 1 to 10 by pressing #12 and #15. After the desired brightness is selected, the brightness adjustment mode will automatically switch o in 3 seconds.
  • Page 14 Functions Time Setting Long press #14 to start the menu. By pressing #12 and #15 to select the "Time Setting" option, short press #13 (OK) to enter. You can switch between the year/month/day/hour/minute/second -> press“UP” and “DOWN” to adjust -> press#13 (OK) again to save. Menu Setting Long press #14 to enter the menu.
  • Page 15 Functions Basic Parameters Type Items Index Magnification Dimension of Objectives φ35mm Optical 8.5° Performance Ocular Adjustable Range ±0.5 Observing Distance (Low Light Environment) 2m~∞ Observing Distance (Full Dark Environment) 2m~500m Sensor Low Illumination HD 1 / 3 COMS Photo 3200X1800 Digital Video 720P...
  • Page 16 Functions Configuration Standard Basic Parameters Power Operating Voltage 3.7V DC Replaceable Battery 3200X1800 Charging Source Rechargeable lithium-ion battery, 18650 Model Other Measurement(L*W*H) 210mm X 145mm X 75mm Weight 550g Configuration Standard Items Amount Objective Lens Shelter External Power Adapter USB Cable NV600 PRO Binocular Pouch Shoulder Strap...
  • Page 17: Tips & Warnings

    Tips & Warnings 1. Basic maintenance Keep the GlassCondor ELITE in its soft pouch when not in use. Operating temperature ranges from – 5°C to 40°. Please store it in a dry environment. Avoid high pressure, mechanical damage, high humidity, and solar radiation.
  • Page 18 Tips & Warnings 4. Use during strong light It could be used during the day or at night. If the light is too strong during the day, it will get a better visual e ect when the objective lens shelter is on, and at night, the objective lens shelter must be removed for better observation.
  • Page 19 8. One can use the GlassCondor ELITE in 100% darkness, low light, daytime. During the day, please keep the IR CAP on the lens. During the night, please...
  • Page 20: Warranty

    Warranty Your CREATIVE XP product is warranted to be free of defects in materials and workmanship for one (1) year after the date of purchase. These warranties do not cover consumer caused damages such as misuse, abuse or repairs attempted by the consumer.
  • Page 21 CREATIVE XP product must be delivered in either its original carton or a similar package a ording an equal degree of protection. CREATIVE XP will not be responsible for any loss or damage incurred in connection with the return of this product. If defective, the product will be repaired or replaced at CREATIVE XP’s option, at no...
  • Page 22: Complete Hunter Kit

    THE COMPLETE HUNTER KIT...
