- Page 1 New England Slimline Storage Unit Assembly Instructions - please keep for future reference UW524 464/3944 Dimensions Width - 28cm Depth - 14cm Height - 35cm Important – Please read these instructions fully before starting assembly Issue 1 - 16/05/2016...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, recommend the use page 2 this could cause damage. - Page 3 Components - Panels & Fittings Please check you have all the panels listed below Note: may be supplied than are required. 4 X 1 33.8X27.7X1.2CM 33.8X13.3X1.2CM 26X12X0.3CM 28X13.9CM A X8 B X8 C X4 Tools required Phillips screwdriver (medium & large)
- Page 5 Assembly Instructions Step 1 1. Connect 1 x Slim Panel 2 to 2 x Large panels using 4 x Screw A as shown Step 2 1. Slide Base panel 3 into position Step 3 1. Connect 1 x Slim Panel 2 to 2 x Large panels using 4 x Screw A as shown...
- Page 6 Assembly Instructions Step 4 1. Locate Top 4 on to unit Step 5 1. Attach 4 x Portective feet C as shown 2. Cover 8 x Visible Screw heads with screw stickers Assembly Complete...
