3+DMX512 Controller Operation Manual
System features:
1.The controller has 8 output ports, each port can carry up to 170/512/768 pixels(Different pixels for different
chips).
2. The controller port output two kinds of signal protocol: ①DMX512/1990 international standard protocol and
DMX512 extended protocol; ②SPI/TTL serial protocol.
3. The controller output port provides three protections to ensure that the controller output port is not burn out in
the case of short circuit or reverse connection in the controlled lamp.
4. Controller ID automatic/manual numbering function, which can be numbered together with multiple controllers,
or individual controller numbers.
5. The controller comes with built-in effects to test on-load luminaires (all supported by RGB/RGBW luminaires).
6. The controller has DMX512 write function and address test. The single port or all ports carry the DMX512 IC
write address and perform address test on the luminaire.
7. The communication between the controllers adopts the international standard TCP/IP network protocol. The
optional transmission rate supports 100M/Gigabit adaptation, and the transmission speed is more stable and
fast. The maximum transmission distance between each two controllers can reach 100 meters. More than this
distance can increase the switch or use fiber for long-distance transmission.
8. The controller provides an LCD screen display that shows the model, ID, and operating status of the controller.
9. When connected with our online video software LedPlayer for computer control, the connection status of the
controller is monitored in real time on the computer. Using the online video software LedPlayer for computer
control can realize: program timing playback, program segment selection, effect brightness adjustment, white
balance online adjustment, program playback speed adjustment, display text, picture loop playback, etc., which
greatly satisfy the customer's application and Multiple needs in debugging.
10. The online video software LedPlayer comes with Gamma correction, which makes the color display more
delicate and vivid.
11. When the controller is connected to the computer, the IP address is set. The controller supports online and
offline integrated control. The online priority is the highest. When there is no online signal, it automatically
switches to the offline effect.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DMX512 and is the answer not in the manual?

Questions and answers

Related Manuals for Triple Plus DMX512

Summary of Contents for Triple Plus DMX512

  • Page 1 5. The controller comes with built-in effects to test on-load luminaires (all supported by RGB/RGBW luminaires). 6. The controller has DMX512 write function and address test. The single port or all ports carry the DMX512 IC write address and perform address test on the luminaire.

  • Page 2: Product Picture

    Note 2: The controller supports rack-mounting. If necessary, please contact the relevant business personnel before placing an order. Support chips：（Software select 3+DMX512） Max. support Support chips Reamrks light International standard DMX512（like: UCS512, SM512, TM512, Suggest to carry 2400 4096 pixels GS512 etc） pixels UCS19**，ucs29**，ucs89**，ucs1603，ucs5603 Suggest to carry 4096...
  • Page 3 Signal type Signal output ---- CLK clock GND(Negative） DAT data OUT1--OU （TTL/SPI Signal） Signal output A/DAT+ B/DAT- ADDR Signal address （DMX512 signal） GND(Negative） Signal negative writing positive Button function MODE SPEED+ SPEED- Play/Regular mode Numbering mode Numbering start Number up...

  • Page 4: Display Definition

    5. Display definition: Display Definition ID: 001（ number is 1） Playback PLAY >>> online/ master control mode playback STOP >>> Online/master control- pause ID: 001( number is 1) Regular A/C: Automatic/manual coding mode T-800K controller model Numbering ID：*** Starting number mode Build-in CHIP: chip...
  • Page 5 ①. ②.DMX512 differential signal wiring diagram Regular laight wiring diagram ③. DMX512 single signal line wiring diagram ④. DMX512 differential signal wiring diagram (AB wire to write address) 4. Controller--Online mode--Computer IP address setting 1. Turn on the computer --- network and sharing center;...
  • Page 6 5. Change IP IP：192.168.60.2 Subnet mask：255.255.255.0 6. Click OK to complete the IP address setting. Note: This IP setting is applicable to regular online/Madrix software control. Numbering function operate Numbering has two methods: 1. Controller (master control operation) numbering function The main control and sub-control (T-780K) are connected through the network cable (using the international standard TCP/IP network protocol, and the network cable is 568B through).
  • Page 7 568B straight) 2.1. The first 3+DMX512 controller, press and hold the “SPEED-” button, the controller will be powered on and enter the manual coding mode. The display shows: “ID: 0001” as shown in the figure, ie the current number of the controller is No.
  • Page 8 Note: When the controller is numbered, the cascaded networking ports must be connected in strict accordance with the controller silkscreen prompt (INPUT/OUTPUT). 3+DMX512 Parameter setting and function operation Press the “SET” button, and the controller will start up and enter the parameter setting and other function interfaces.
  • Page 9 7 frame 12 frame 20 frame 30 frame 1.7. After completing the built-in effect playback, shut down and restart to return to normal mode. -255） ③. IC : Chip model （Rfer to DMX512 IC list） ④. PORT NUM: Address port...
  • Page 10 3+DMX512 Controller ---MADRIX SETTING Press “SET”, and power on the controlller at the same time, enter MADRIX setting interface, as shown below: ○ SET MADRIX Turn on/off MADRIX software ○ SET Univ Set support lights quantity ○ 3 SET IC...
  • Page 11 6. Select to complete the selection, press the “SET” button to exit, and return to the MADRIX setting interface. 1.3. Support IC selection（ UCSS1903/ DMX512） Press the “SET” button, and the controller will start up and enter the MADRIX set parameter interface.

  • Page 12: Physical Parameter

    6. Select to complete the selection, press the “SET” button to exit, return to the MADRIX setting interface, restart the controller to complete the settings. Physical parameter Working temperature: -20 ° C - 85 ° C Working power supply: AC 100-240V input Power consumption: 5W Weight: 1.8Kg Output type: 4pin terminal block...
