Goodmans AllPlay MODULE User Manual page 5

2.3 Rear view
C DC IN
Connect to supplied Power Adaptor
Important: Only use the supplied adaptor!
D ANALOG AUDIO OUTPUT
3.5mm Stereo Jack to connect to your audio system.
E WLAN
For easy connection to your home Wi-Fi network. Press this key and the WPS key
of the router simultaneously for automatic Wi-Fi pairing.
F DIR MODE/RESET
Long press (5 seconds): Factory Reset
Short press (1 second): DIRECT MODE
This mode enables direct connection to your AllPlay Jukebox enabled
Smartphone/Tablet without the need of a home Wi-Fi Network.
G OPTICAL OUT
Optical Output to connect to audio system with optical input connection.
D
C
G
E F
MODULE
