Maintenance And Cleaning; Technical Specifications - Pro-Ject Audio Systems A1 Instructions For Use Manual

5. Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic
cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover (i) before cleaning or maintenance is carried out to avoid
damage.
Always disconnect the record player from the mains power supply as a precaution before maintenance!
Technical specifications Pro-Ject A1
Nominal speeds
Speed variance
Wow and flutter
Signal to noise
Effective tonearm mass
Effective tonearm length
Overhang
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight
Technical specifications MM-Cartridge Ortofon OM10
Frequency range
Channel separation
Output voltage
Recommended load impedance
Compliance/stylus type
Recommended tracking force
Weight
Technical specifications MM phono pre-amplifier
Gain
Output voltage typically
Input impedance
Noise floor
RIAA-equalisation curve accuracy
33/45 RPM
33: ±0.75% 45: ±0.65%
33: ±0.27% 45: ±0.25%
-65dB
ULM (ultra light mass) design principle
8.3" (211 mm)
19,5mm
1,5W
15V/800mA DC, suitable for your country's mains supply
430 x 130 x 365mm
5,6 kg
20-22.000Hz
22dB/1kHz
4mV
47kohms/amplifier connection – MM-input
25µm/mN – elliptical
15mN
5g
34dB
200mV/1kHz at 5mV/1kHz input
47kohms/100pF
-68dB
20Hz-20kHz / max. 0,5dB
© Pro-Ject Audio Systems · Pro-Ject A1 · Revision 2022.01.05
7
