Setting up your Cololight PLUS
User Guide V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Cololight PLUS

Summary of Contents for Cololight PLUS

  • Page 1 Setting up your Cololight PLUS User Guide V1.0...

  • Page 2: Product Introduction

    PRODUCT INTRODUCTION LifeSmart Cololight PLUS is an ambient light supporting split joint and color changing. It can be placed on the table or installed as background wall, suspended ceiling. Cololight PLUS is HomeKit-enabled, you can use Siri and Home app on iOS devices to control it.

  • Page 3: Installation Instruction

    INSTALLATION INSTRUCTION Reset Control button Reset method: Press and hold the reset hole until the green indicator light on the controller flashes. Release the button and the device will reboot. Wait about 10 seconds for the device to reboot success- fully and complete the reset.
  • Page 4 FEATURES Creative Shape Hexagon design, seamless connection and no dark area on the surface. FUN of DIY various shapes with gorgeous effects to creates joyful atmosphere. Color Changing with Music Dynamic effects & Sound activated. 16 Million Colors 3 color selection modes (Selected, Dynamic & Customized).
  • Page 5 FEATURES App Control Various playing methods, Dimmable function, Auto ON/OFF. Intelligent Scene Linkage Auto lighting up when opening door (Should be used with sensor). Voice Control support Siri & Amazon Alexa & Google Assistant. No Hub Required Directly controlled through App on mobile device.

  • Page 6: Specifications

    SPECIFICATIONS Light size 86x74.5x30.5mm Light weight 52.5g Controller Size 46.5x30.5x28mm Controller weight Power cable length Communication protocol Wi-Fi Operating frequency 2.4GHz (5GHz not supported) Input 5V DC, 2A Operating temperature -5~45°C Operating humidity 5~90% Material ABS/ABS+PC Power consumption Static 0.3W Maximal 5W Control mode App/Voice/Control button...

  • Page 7: App Instruction

    App. http://www.ilifesmart.com/getapp_qlgp.html Visit the iOS App Store or Google Play and search for Cololight. Pair up COLOLIGHT with your mobile device according to the instruction on App. NOTE Please check the FAQ in the Cololight App if you have any...
  • Page 8 INSTALLATION INSTRUCTION Use the CONNECTOR to fix the Controller unit PLUS and the Cololight The second Jack Cololight The first Jack Controller unit PLUS CONNECTOR...
  • Page 9 INSTALLATION INSTRUCTION Use the CONNECTOR to connect the COLOLIGHTs together. One end of the CONNECTOR must connect to the outer slot while other end must connect to the inner slot. FIXATOR CONNECTOR CONNECTOR Inner slot...
  • Page 10 INSTALLATION INSTRUCTION Use FIXATORs to strengthen stability. Notice that FIXATOR must connect to single hole slots between two COLOLIGHTs. It only strengthens the structure without communication function. FIXATOR...
  • Page 11 Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. 3. Home app does not support functions such as single LED edit, playing method create, please turn to Cololight App if required.
  • Page 12 WARNING This product contains small parts that can cause danger if swallowed by children. This product is not suitable for children under the age of 3. Children under the age of 14 must use this product under parental supervision.
  • Page 13 Hazardous Substance Table Grey plastic Part Name Code Label IC Body shell （Cd） （Pb） Harmful （Hg） Substance （Cr） （Br） This table is made according to IEC 62321 test standard. Expresses that this hazardous substance in all homogeneous materials of this part is within limit range. Expresses that this hazardous substance in at least one homogeneous material of this part is above limit.

  • Page 14: Warranty Description

    WARRANTY DESCRIPTION Thank you for purchasing this LifeSmart product. In order to protect your rights, please read the following content carefully: The warranty period of our company's products is one year from the date of purchase or longer if local laws impose a longer minimum term, in which case the minimum term is the warranty period.
  • Page 15 ATTENTION The following conditions are not covered by the warranty: Product failure or damage caused by installation, use, and maintenance that is not in accordance with the product instructions; Products beyond the warranty period; Products that have the barcode tampered with or removed;...
  • Page 16 ATTENTION User-caused damage, such as inappropriate voltage input, high temperature, accidental spillage, physical damage, etc; Product failure or damage caused by force majeure such as earthquakes, fires, or floods; Product failure or damage caused by other problems except the product itself. User support e-mail address support@ilifesmart.com CERTIFICATION...
  • Page 17 DECLARATION LifeSmart is a trademark of Hangzhou LifeSmart Technology Co., Ltd. As for the trademarks, product logos and product names from other companies presented within this manual, they are possessed by their own right holders. Without our written permission, no entity or individual shall extract, copy or disseminate in part or the whole of the manual contents in any form.
  • Page 18 DECLARATION This manual is used only for instructional purposes. We strive to provide accurate information in this manual, but we are not able to ensure that the content of this manual is current. Statements, information and advice in this manual do not constitute any expressed or implied assurance.
  • Page 19 DECLARATION NOTE: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 20 20 cm between the radiator and your body. DECLARATION OF CONFORMITY Hereby, LifeSmart declares that the radio equipment type Cololight is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://global.ilifesmart.com/ce/docs/...
  • Page 21 Manufacturer： Hangzhou LifeSmart Technology Co., Ltd. Address： 10-11th Floor,Building A,SUPCON Information,352 Binkang Road, Binjiang District, Hangzhou, Zhejiang, CHN Copyright © 2020 LifeSmart Inc. All Rights Reserved. P/N: 88.005860 A1...
