Summary of Contents for Smeg SWC120X
- Page 1 � � � � � � and operating technology with style instructions SWC120X wine cabinet...
- Page 2 IMPORTANT SAFEGUARDS Read all instructions before using this appliance. When using this appliance, always exercise basic safety precautions, including the following: 1. Use this appliance only for its intended purpose as described in this instruction manual. 2. This Beverage Cooler must be properly grounded in accordance with the installation instructions before it is used.
- Page 3 11.If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer...
- Page 4 Technical Specifications Model Number SWC120X-1 Climate Class Electrical input 220V-240V/50HZ Current Rating 1.8A Unit Dimensions (HxWxD mm) 845x600x560 Unit Weight 57kg Refrigerant R134A 105g Compartment 2℃-18℃(both zones) Temperature Range Location of Parts Control panels Interior light ( on ceiling of...
- Page 5 Control Panel Energy-Saving Tips Do not place your cooler next to a heating vent, a range or in direct sunlight. Keep the door closed as much as possible, especially in hot, humid weather. Cover foods to reduce moisture build up inside the appliance. Installation 1.
- Page 6 5. In order for the appliance to release heat quickly and to have sufficient ventilation, there should be enough space around the appliance. The appliance should be placed in a position with a minimum space of 100mm on all sides. 6.
- Page 7 6. If a leakage occurs from the gas pipes, you must exhaust the inflammable gases around the appliance. Never pull out the power plug from the socket or switch off the thermostat, as can be a possibility of an explosive ignition caused by electric sparks. 7.
- Page 8 OPERATING INSTRUCTIONS Turning the Unit On The unit turns on automatically when it is plugged in. If you want to use the Automatic Temperature (default) setting, do nothing further. The unit will automatically set the temperature in the wine compartment at 13 degrees Celsius and the beverage compartment at 5 degrees Celsius.
- Page 9 Your unit has been designed to ”remember” the last run mode to which it was set. If you have a power outage or any other power cut off, the unit will automatically return to the previous temperature settings after the power is switched on again.
- Page 10 Warning: To avoid an electric shock, unplug the unit when replacing the energy-saving lamp. The lamp base is E27; the rated power of the lamp is 11W. Use a lamp of the same rating and size when replacing an energy-saving lamp. Remove the screw at the back of the lamp cover, then, to release the cover, push it firmly backward and then carefully pull down.
- Page 11 Cleaning the Inside Unplug the unit and remove all contents. Rinse the inside surface with plain water and dry the chrome shelves. Troubleshooting Unit does not turn on - First check to see if the unit is plugged in. A fuse could be blown or circuit breaker tripped. Noise or vibration Check that unit is level.
- Page 12 indicates that the actual temperature is much higher than your set temperature. Possible causes are: . The door might not be fully closed . The refrigerant may have leaked. . The magnet valve may not be functioning properly and should be replaced.
