- Page 1 OPERATION MANUAL Applicable product model: GL-F-16M www. ae g i s f r id g e . co m...
-
Page 2: Table Of Contents
Content 1. Operation Instruction 2. Safety Notices 3. Precautions for Use 4. Installation 4.1 Installation Environment 4.2 Installation Site 4.3 Preparation Before Using 4.4 Standing 4.5 Power on for the First Time 5. Components and Overview 6. Display Panel Function Description 7. -
Page 3: Operation Instruction
The chapters are clearly marked in the manual's catalog. Glacier is not responsible or liable for any damage to the instrument caused by the user's failure to use the device in accordance with the manufacturer's instructions. -
Page 4: Safety Notices
2. Safety Notices For the first time to use this device, uses must read the meaning of the following warning labels very carefully. Items and procedures are described so that you can use this unit correctly and safely. If the precautions advised are followed, this will prevent possible injury to the user and any other person. - Page 5 Be sure to install the device in a dry dust-free environment to avoid overheating, short circuit and other dangers If there is an unexpected sound, smell, smoke when the power is turned on, unplug the power and contact the manufacturer or supplier.Continuedabnormal operation may cause electric shock or fire. Make sure to put the freezer in a dry and ventilated environment, to ensure that equipment vents and wall surface of the instrument or other items have not been blocked;...
-
Page 6: Precautions For Use
3. Precautions for Use Before you put the items to the medical freezer, please make sure whether the temperature in the refrigerator has ◆ reached the set temperature and then put the items to the refrigerator in batches. No more than 1/3 of the refrigerator rating volume per time, in case the temperature rises too much. -
Page 7: Preparation Before Using
Warning ● Don't through gas pipe, water pipe, line or lightning rod to medical grounding cooler, easy cause electric shock ● After installation, power plug must be within reach, convenient unplug the power cord in time in case of an emergency Any articles shall not cover medical air vents of the medical freezer ●... -
Page 8: Components And Overview
5. Components and Overview Dispaly control panel Cabinet Door handle Door Door lock Door handle Movable casters Adjustable foot 1. Due to the improvement of the product and the different models, the actual product may be different from the diagram. The above figure is only an example of the identification function. 2. -
Page 9: Display Panel Function Description
6. Display panel function description d printer(optional) （1）Control board introduction: a. Both are temperature display windows. In normal operation, the average temperature of the upper and lower chambers of the cabinet is displayed in °C; different prompt characters can be displayed in the setting state (see below for details). b. - Page 10 h. USB data (optional) Automatic export: When the USB flash drive is connected to the USB interface, the buzzer will beep once after the data transfer is completed, the upper room displays "Usb", and the lower room displays "on". The U disk generates the PDF of the current month and the previous month.
- Page 11 0. 0~10.0 Low temperature alarm setting value is set-L, and when L is equal to 0, the alarm is canceled. When the temperature is too low, the low temperature alarm shows L01. Set2 Temperature setting for lower chamber YL:-10~-25 YL:-25 FL:-10~-40 FL:-40 0.
-
Page 12: Defrost ●Unused ● Maintenance
Just to switch on the power supply for medical freezer do not immediately add items, make empty operation after a period of time (about 24 hours), then refrigerated goods into storage box. To add items, if the item is too much water or excessive drying will influence the change of the humidity, the best goods sealed;... -
Page 13: Disposal
Do not place heavy objects on the top of the medical freezer to avoid deformation of the box. At regular intervals, the medical freezers are cleaned and maintained once. (For safety reasons, the power plug must be unplugged before scrubbing.) Wipe the inner and outer surfaces of the freezer with a soft, damp cloth. -
Page 14: After-Sale Service
8. After-sale Ser vice Any product has the possibility of failure. Please observe the operation of the medical freezer in the process of use. If there is any abnormality, please check and compare the errors with the following table.If you can't fix the issue, Please inform our service center in time. -
Page 15: Specifications
9.Specifications Medical freezer/Ultra-low temperature freezer Name GL-F-16M Model PCM color plate Outside cabinet Epoxy polyester powder spray coated steel plate Outside door Wire tube condenser Condenser Evaporator Wire Tube Evaporator Insulation Rigid polyurethane foam filling Compressor Fully enclosed Thermostat Microcomputer control... - Page 16 Annex1： Rechargeable Battery Maintenance,Installation,Replacement and Disposal Long term power failure or in the process of transportation, the main power switch must be turned off. Otherwise, long time discharge will cause battery loss or permanent damage, and it will be abnormal after re-energized. Maintenance of rechargeable batteries: In order to prolong the battery life, please avoid idlingthe product.
-
Page 17: Performance
Model type ture （L） （W*D*H） （Kg） （Hz） (℃) （V～） （A） （mm） Up: -10～-25℃ GL-F-16M 16～32℃ R600a/65g×2 1.55 810×735×1960 Down: -10～-25℃ 10.2 Packing List Defrost shovel Name Operation manual Quantity 10.3 Electrical Diagram If the product is improved, the technical data and circuit diagram shall be subject to the final product...
