System Installation Manual
： ： ： ：
. ..................................................................................................................... 3
1. SYSTEM SUMMARY .............................................................................................................. 4
2. HARDWARE CONFIGURATION ........................................................................................... 5
2.2 ELECTRICAL SPECIFICATIONS........................................................................................ 6
3. EQUIPMENT REQUIREMENT:............................................................................................ 11
: ...................................................................................................................... 11
: ............................................................................................................................... 11
4. DV-28 PCB AND CABINET LAYOUT ................................................................................. 12
4.1 DV-28 SYSTEM DIAGRAM ............................................................................................ 12
（
（
4.8 D4SLCC (SLT S
（
（
V
5
I NSTALLATION AND WIRING ........................................................................................... 23
、 、 、 、
5.1 D4PWUA POWER UNIT INSTALLATION ........................................................................ 23
：
12
Arista Systems Corporation
.................................................................................................. 4
................................................................................................................ 4
............................................................................................................. 4
........................................................................................................ 5
................................................................................................ 7
.......................................................................................................... 8
......................................................................................................... 9
: ............................................................................................. 11
：
...................................................................................................... 11
) ...................................................................................... 14
)...................................................................................................... 15
)...................................................................................................... 16
）
. ...................................................................................... 17
）
. ...................................................................................... 18
C
) ............................................................................................ 19
TATION
ARD
）
. ................................................................................. 20
）
. ................................................................................. 21
F
C
) ............................................................................... 22
ULTI
UNCTION
ARD
5.2 D5MBUA - CO TRUNK AND KEY-PHONE
.......................................................................... 13
DV
28
Digital Key Telephone System
1
Advertisement
Table of Contents
Related Manuals for Aristel DV-28
Summary of Contents for Aristel DV-28
-
Page 1: Table Of Contents
3.3 C ： ...................... 11 ABLE EQUIREMENT 3.4 N : ..........................11 OTICE 4. DV-28 PCB AND CABINET LAYOUT ................. 12 4.1 DV-28 SYSTEM DIAGRAM .................... 12 4.2 D4PWUA – F ................13 ANGE OWER DAPTOR 4.3 D5MBUA (M ) ..................14... - Page 2 System Installation Manual Digital Key Telephone System EXTENSION INSTALLATION ....................23 5.2 D5MBUA - CO TRUNK AND KEY-PHONE EXTENSION INSTALLATION ....24 5.3 D5EXPA S BOARD INSTALLATION ............25 ONTROL 5.4 D5DLUA STATION CARDS INSTALLATION..............26 5.5 D5TKUA (T )....................27 RUNK 5.6 D ....................
-
Page 3: Introduction
The manual will provide you with the details instructions or procedures for the installation of ARISTEL DV-28 SOHO system so that it can serve you with the communication needs and custom-design services. Please read this entire section before proceeding with the actual installation. -
Page 4: System Summary
System Installation Manual Digital Key Telephone System 1. System Summary 1.1 Hardware Configuration System capacity 4 08~820 ： System Control S tored Program Control (SPC) ： 。 SMT interface agglutinate technology Stationary trough interface installation, Main systematic and Internal/External Lines independent of each 1.2 System Software Built-in programming... -
Page 5: Hardware Configuration
System Installation Manual Digital Key Telephone System 2. Hardware Configuration 2.1 System Specifications The system use fixed slot design, all expansion card have to connected to designated slot Expansion DV-28 Basic Capacity MAX. Capacity Capacity CO Line Key Telephone 6 / 8 / 12... -
Page 6: Electrical Specifications
System Installation Manual Digital Key Telephone System 2.2 ELECTRICAL SPECIFICATIONS Input AC Voltage AC110~240V Key Telephone 1~2 W Power Door Phone 0.5 W Consumption Maximum 40 W System Power Back-Up Battery 4 Hour (24 V 7AH) CO Line 1.5K Ω max. Loop Key Telephone 40 Ω... -
Page 7: System Model Description
System Installation Manual Digital Key Telephone System 2.3 System Model Description Model No. Description MAIN SERVICE UNIT, consisting of (Plastic Cabinet + D5MBUA + D4PWUA + D5EXPA + D5-408K D1CIDC ) D4PWUA POWER UNIT, Input 110~240VAC Full range, Output 28Vdc/1.8A MOTHER BOARD UNIT, consisting of (4 CO Lines + 8 Digital Key Stations Ports), with quick D5MBUA Connectors... -
Page 8: System Features List
System Installation Manual Digital Key Telephone System 2.4 System Features List 2 Pages of DSS Key Message Waiting 5 Different Trunk Access Codes Name Speed Dialing (Phone Book) 9 Different Incoming Ringing Frequencies One Touch Operation Account Code Power Failure Telephone Auto Attendant Private Line Auto Accessing Trunk... -
Page 9: Station Features List
System Installation Manual Digital Key Telephone System 2.5 Station Features List Handsfree Conversation 16×2 Dot-Matrix LCD Display Hold/Exclusive Hold 5 Different Numbers Auto Redial Last Outgoing Redial 9 Different Ringing Frequencies on Key Station Macro Key Setting Adjustable LCD Angle Message Text Built-In Calculator Function (25 Buttons LCD Monitor... -
Page 11: Equipment Requirement
System Installation Manual Digital Key Telephone System 3. Equipment Requirement: 3.1 Preparation: Survey the capacity of system and telephone. Survey the wiring and tool. Carefully study and follow this manual before installation. 3.2 Environment Requirement: Input Voltage A C110~240V ： System Power Back-up Battery C onnect with DC24V power source to the battery ：... -
Page 12: Pcb And Cabinet Layout
System Installation Manual Digital Key Telephone System 4. DV-28 PCB AND CABINET LAYOUT 4.1 DV-28 SYSTEM DIAGRAM Figure 1: DV-28 Diagram 1. System Dimension 3 06 x 205 x 70mm ： 2. System AC Input 1 10~240VAC ： 3. DC Output for Battery backup: 28VDC... -
Page 13: D4Pwua - Full Range Power Adaptor
System Installation Manual Digital Key Telephone System 4.2 D4PWUA – Full Range Power Adaptor Figure 2: DV-28 power adaptor D4PWUA front view 1. AC Input 1 10~240VAC Full range ： 2. DC Output 2 8VDC/1.8A ： Arista Systems Corporation... -
Page 14: D5Mbua (Mother Board Unit)
System Installation Manual Digital Key Telephone System 4.3 D5MBUA (Mother Board Unit) Figure 3: DV-28 Mother board Unit (D5MBUA) 1. U4 - D5CNFC Conference Chip 2. U2 - System Software EEPROM 3. J3 – Jumper selection for system RAM programming backup switch BAT –... -
Page 15: D5Tkua (Trunk Unit)
System Installation Manual Digital Key Telephone System 4.4 D5TKUA (Trunk Unit) Figure 4: DV-28 CO Trunk Card Unit (D4TKUB) 1. For D5MBUA connection. 2. Terminal-Block Connector for the CO Line Connection NOTE D 5TKUA C O Trunk CARD c onsisting of 4 CO Lines ：... -
Page 16: D4Tkub (Trunk Unit)
System Installation Manual Digital Key Telephone System 4.5 D4TKUB (Trunk Unit) Figure 5: DV-28 CO Trunk Card Unit (D4TKUB) 3. For D5MBUA connection. 4. Terminal-Block Connector for the CO Line Connection NOTE D 4TKUB C O Trunk CARD c onsisting of 3 CO Lines ：... -
Page 17: D5Dlua Key Station Card
Digital Key Telephone System 4.6 D5DLUA （ （ （ （ K ey Station Card ） ） ） ） Figure6: DV-28 Key Station Card Unit (D5DLUA) 1. For D5MBUA connection. 2. Quick-Connector Module for Key phone connection, U se 2-wire T/R , including 4 （... -
Page 18: D4Dlub Key Station Card
4.7 D4DLUB （ （ （ （ K ey Station Card ） ） ） ） Figure 7: DV-28 Key Station Card Unit (D4DLUB) 3. For D5MBUA connection. 4. Quick-Connector Module for Key phone connection, U se 2-wire T/R , including 4 （... -
Page 19: D4Slcc
System Installation Manual Digital Key Telephone System 4.8 D4SLCC (SLT Station Card) Figure 8: DV-28 SLT Station Card Unit (D4SLCC) 1. For D5MBUA connection. 2. Quick-Connector Module for Single Line phone connection U se 2-wire T/R （ （ （ （... -
Page 20: D4Hyub Hybrid Station Unit
System Installation Manual Digital Key Telephone System 4.9 D4HYUB （ （ （ （ H ybrid Station Unit ） ） ） ） Figure 9 D V-28 Hybrid Station Unit ： 1. For D5MBUA connection. 2. Quick-Connector Module for Key Station Wiring, or Single Line Telephone U se （... -
Page 21: D4Vsca Voice Service Card
4.10 D4VSCA （ （ （ （ V oice Service Card ） ） ） ） Figure 10: DV-28 Voice Service Card (D4VSCA/B) 1. For D5MBUA connection. 2. LED ： T o indicate the channel 1 is working when LED is blinking. -
Page 22: D4Mfca/B
System Installation Manual Digital Key Telephone System 4.11 D4MFCA/B (Multi Function Card) Figure 11 D V-28 Multi Function Card (D4MFCA/B) ： 1. For D5MBUA connection. 2. A-B: Terminal-Block Connector, for the Relay Connection. 3. DOOR: Terminal-Block Connector, for the Door Phone Connection. 4. -
Page 23: I Nstallation And Wiring
System Installation Manual Digital Key Telephone System 5、 、 、 、 INSTALLATION AND WIRING 5.1 D4PWUA POWER UNIT INSTALLATION Figure 12 ： ： ： ： D V-28 Power Installation Arista Systems Corporation... -
Page 24: D5Mbua - Co Trunk And Key-Phone Extension Installation
System Installation Manual Digital Key Telephone System 5.2 D5MBUA - CO TRUNK AND KEY-PHONE EXTENSION INSTALLATION Figure 13: CO line and key-phone Extension installation Arista Systems Corporation... -
Page 25: D5Expa Sub-Control Board Installation
System Installation Manual Digital Key Telephone System 5.3 D5EXPA Sub-Control BOARD INSTALLATION Fit the D5IPXA card upon EXP_1 and EXP_2 - Pin connectors of D5MBUA Board. Figure 14: CO line and key-phone Extension installation Arista Systems Corporation... -
Page 26: D5Dlua Station Cards Installation
System Installation Manual Digital Key Telephone System 5.4 D5DLUA STATION CARDS INSTALLATION Figure15: DV-28 Key Station Card Unit (D5DLUA) Arista Systems Corporation... -
Page 27: D5Tkua (Trunk Unit)
System Installation Manual Digital Key Telephone System 5.5 D5TKUA (Trunk Unit) Figure 16: DV-28 Trunk Card Unit (D5TKUA) Arista Systems Corporation... -
Page 28: Door Phone Connection
System Installation Manual Digital Key Telephone System 5.6 Door phone connection Figure 17: Door phone installation Arista Systems Corporation... -
Page 29: Sensor Installation
System Installation Manual Digital Key Telephone System 5.7 sensor installation Figure 18: Sensor installation Arista Systems Corporation... -
Page 30: Door Switch Installation
System Installation Manual Digital Key Telephone System 5.8 Door switch installation Connect to Door Switch Power Figure 19: Door switch installation Arista Systems Corporation... -
Page 31: External Musice Installation
System Installation Manual Digital Key Telephone System 5.9 External musice installation Figure 20: External music installation Arista Systems Corporation...
