Cimarron 50x12x10 Stand-Alone Batting Cage Frame Instructions For Assembling

Instructions for Assembling the 50x12x10 Cimarron Stand-Alone Batting Cage
Frame The following parts are included for your frame. Please review the
PART
A 3-WAY CORNERS
B 4-WAY CORNERS
C 16" PIPE WITH REDUCED END
D 28" PIPE WITH REDUCED END
E 52" PIPE WITH REDUCED END
F 64" PIPE WITH REDUCED END
G 60" PIPE
H NET HANGERS
I PIPE END CAPS
J SELF-DRILLING
K 18' TIE DOWN ROPES
L ROPE STAKES
CL 10' LENGTHS OF EMT
If you did not purchase a complete frame, you will need to purchase 23 ea. 10' lengths of 1-1/4" thin-walled EMT from
Lowes, Home Depot or some other hardware store. Lowes SKU #72717 – Home Depot SKU #580023

CONSTRUCTING YOUR FRAME

1. Lay out two of the 3-way corners (A) 12' apart where you want one end of the frame to be.
2. Measure 50' and lay out the other two 3-way corners (A) at the other end of the frame 12' apart.
3. Lay out the 4-way corners inside of the frame (between the 3-way corners at each end of the frame) so that
they are about 12.5' apart going length ways and 12' apart in width.
4. Assemble the five arch tops by attaching one of the 10' lengths of EMT (CL) to a 16" pipe (C) and insert a self-
drilling screw (J) at the joint.
5. The runners are the pipes that attach the arches together along the top of both sides of the frame. For runners
#1 and #4, attach one 10' length of EMT (CL) to one 28" length of pipe (D). For runners #2 and #3, attach one
10' length of EMT (CL) to a 28" pipe (D) and then add a 16" pipe (C). Runners #1 and #4 are for the end
arches and runners #2 and #3 are for the inside arches. Insert a self drilling screw (J) at all joints.
6. Attach the 11' arch tops to the 3-way corners (A), (at each end of the frame) so that one of the 4" lengths face
across to the other side of the frame and the other 4" length faces toward the 3-way (A) corner at the other
end of the frame.
7. Attach the 11' arch tops to the 4-way corners (B) so that one of the 4" lengths faces across the frame and the
other 4" length connects to the runners.
8. The arch legs are each one 10' length of the EMT (CL).
9. Complete assembling the arches by attaching the legs (CL) to the top corners (A) and (B).
10. Tighten the bolts on the corners.
11. Stand up one end arch and the second arch and attach two runners between them and then tighten the bolts
on the corners.
12. Stand up the remaining arches (one at a time), and insert the runners between them and tighten the bolts on
the corners.
13. Your frame should be a little over 50'.
081820
following parts to be sure that you have all the parts listed.
QTY
4
6
YOU WILL NEED AN AREA ABOUT 53' LONG AND 17' WIDE.
9
8
N/A
N/A
IT IS RECOMMENDED THAT YOU MARK OFF THIS AREA BEFORE
STARTING.
N/A
39
10
NUT SETTER INCLUDED
17
4
4
23
1 of 2
