Next 134233 Assembly Instructions Manual

Slide white carcass

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this
product or require any replacement
fittings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• We recommend the use of the wall attachment bracket for safety reasons.
PRODUCT INFORMATION
Made in Poland.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
134233 SLIDE WHITE CARCASS
ASSEMBLY INSTRUCTIONS.
1 of 14
1/14 P4RU73 K2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 134233 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 134233

  • Page 1 134233 SLIDE WHITE CARCASS ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction FLOOR AREA 3.0 M x 3,0 M 1.5 hrs 2 PERSON ASSEMBLY APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY SPACE REQUIRED ASSEMBLY TOOLS ASSEMBLED DIMENSIONS 611 mm 2 of 14 2/14 P4RU73 K2...
  • Page 3: Parts List

    DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction PARTS LIST NO PART LIST (1) BOTTOM PANEL (2) PLINTH (3) LEFT SIDE PANEL (4) LEFT BACK PANEL (5) RIGHT BACK PANEL (6) HORIZONTAL FRAME (7) VERTICAL DIVIDER (8) TOP PANEL (9) HORIZONTAL SLAT...
  • Page 4: Hardware List

    DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES 3,5x13mm 8x28mm Ø5x39mm Ø15x12mm FEET SCREW DOWEL CAM BOLT GLUE CAM LOCK BAG 8 BAG 8 BAG 1 BAG 1 BAG 8 BAG 1...
  • Page 5 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES Ø10mm Ø10mm 3,5x13mm Ø15mm L=1969mm COVER ALLAN WRENCH UPPER RUNNER SCREW CAM COVER BAG 8 BAG 8 BAG 1 BAG 8 WHEN CARCASS IS ASSEMBLED PLEASE REFER TO FURTHER...
  • Page 6 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction Top Tips before you start! Please check that all parts are present before you start the assembly of your furniture, as once assembled, the furniture is exempt from our home approval policy. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
  • Page 7: Locked Position

    DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES.
  • Page 8 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction 8/14 P4RU73 K2 8 of 14...
  • Page 9 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction 9/14 P4RU73 K2 9 of 14...
  • Page 10 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction 1/2 TURN CLOCKWISE. 10 of 14 10/14 P4RU73 K2...
  • Page 11 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction PLEASE MAKE SURE THAT THE HOLES IN PART 9 ARE FACING TO THE FRONT OF THE ROBE SO THEY CAN NEST THE RUNNER’S BOLT 1/2 TURN CLOCKWISE. 11/14 P4RU73 K2 11 of 14...
  • Page 12 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction 1/2 TURN CLOCKWISE. 12/14 P4RU73 K2 12 of 14...
  • Page 13 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction L=1969mm 13/14 P4RU73 K2 13 of 14...
  • Page 14 DESCRIPTION: Assembly 134233 SLIDE WHITE CARCASS Instruction WHEN CARCASS IS ASSEMBLED PLEASE REFER TO FURTHER INSTRUCTIONS INCLUDED WITH THE DOORS 14/14 P4RU73 K2 14 of 14 NEXT Retail Ltd, Desford Road, Enderby Leicester, LE19 4AT...
