Endon 68835 Instruction Manual

Safety Warnings

• These products are only suitable for connection to a 240V~50Hz supply in accordance with current IEE
wiring Regulations and should be installed in accordance with local Building Regulations and are for
Domestic ceiling use only. They are not suitable for a Bathroom location.
• Before installing your light fitting always switch off the mains supply and remove the appropriate fuse or
switch off the appropriate circuit breaker before commencing installation.
• This is a Class II, Double Insulated product
must not be connected to Earth. The terminal blocks are supplied according to requirements of the fitting.
• Never fit bulbs of a higher wattage than those specified, as these may cause overheating and damage the
fitting.
• If you are in any doubt about your competence please consult a qualified electrician.
• If any modification is made it will invalidate the warranty and may render the product unsafe.

Care Information

Allow 10 minutes to cool before replacing, adjusting or cleaning.
Clean with a dry cloth only. Do not use liquid or abrasive cleaners on this product.

Assembly/ User Instructions

Please read these instructions carefully before fitting and retain for reference. Check the packaging and make
sure that you have all the required parts. Follow each assembly step in order to prevent incorrect assembly.
Ensure that the product is fully assembled as illustrated before use.
The Light pack contains:
Light fitting.
Terminal connection block(s).
Fixing pack.
These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.
1. Decide on the position of the light fitting, or remove existing light fitting. Take a note of the position of the
electrical connections. Ensure there is a solid mounting surface, preferably a wooden joist or joist bridge to
support the weight of the light fitting.
2. If you want to reduce the overall length of the fitting it is essential that this is done before the fitting is mounted
to the ceiling and/or connected to the mains supply. We recommend the chain not be made shorter than
15cm. Remove the chain links until the desired length is reached. The cable must now be shortened and
the excess cable cut and re-connected to the terminal block. Feed the cable up through the plastic bush and
form a loop above the ceiling cup, moving the figure of 8 cable restraint down the exposed cable. NOTE: The
electric cable must always be longer than the chain to prevent strain being placed on the cable. If you
are unsure about your ability to do this, we recommend you contact a qualified electrician.
3. Remove the two side screws (4) and retain the screws for re-use. Use the fixing bracket (1) as a template to
mark the screw holes, and secure to the ceiling with appropriate screw fixings (2).
4. Support your fitting and connect the house wiring to the terminal block (3) – see expanded wiring details
below. NOTE: This is a Class II fitting and must not be earthed. Any loose terminal blocks – not secured
to ceiling cup – should always be covered with 2 layers of good quality insulation tape.
5. Secure the ceiling cup over the bracket by using the screws (4) removed in Point 2.
Endon Lighting, LS9 0SE
Cable Set Light Fitting
INSTRUCTION MANUAL
This Fitting does not require an Earth, and Live or Neutral
Before you start
The following tools may be required:
Selection of cross and flat head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
68833_68834_68835_68836-Cable_Set-P 20160104
