HYDROSCAND PowerCut 5-85ot User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

PowerCut 5-85ot
UseR MAnUAL edition II
2017-09-08
serial number: _________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerCut 5-85ot and is the answer not in the manual?

Questions and answers

Related Manuals for HYDROSCAND PowerCut 5-85ot

Summary of Contents for HYDROSCAND PowerCut 5-85ot

  • Page 1 PowerCut 5-85ot UseR MAnUAL edition II 2017-09-08 serial number: _________________...

  • Page 2: Table Of Contents

    PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Contents 1. INTRODUCTION ........3 2. GENERAL PRECAUTIONS ......4 3. EqUIPMENT ..........5 3.1 WARRANTY ........5 3.2 IMPORTANT ........5 4. MAChINE ........... 6 - 8 4.1 IDENTIfICATION ....... 6 4.2 DESCRIPTION ......6 - 8 5.

  • Page 3: Introduction

    MUst read the following instructions before operating. hydroscand Machine Ab declines any responsability for damage to persons, things or to the machine itself, arising fromits incorrect use, neglience and superficial interpretations of safety concepts in this manual.

  • Page 4: General Precautions

    Technical Service. The use of spares that do not respond to the specifications listed below, changes or manipulations - however slight- shall exempt hydroscand Machine Ab from any responsability regarding the proper use and functioning of the cutting machine and safety of people and/or property.

  • Page 5: Equipment

    The manufacturer recommends a lockable main switch between the machine and the mains. PowerCut 5-85OT is prepared with a smoke evacuation connection and if a smoke evacuation is connected the manufacturer recommends to install a spark filter to prevent hazards.

  • Page 6: Machine

    The hose cutting machine must only be used for hydraulic hoses compatible with the specifications below. Follow the environmental conditions and limitations recommended by hydroscand Machine Ab and current health and safety regulations. note ! The descriptions includes the use for which the machine has been designed, built and protected.
  • Page 7 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 7...
  • Page 8 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 1. Foot pedal 2. Waste box 3. Adjustable feet 4. Motor 5. Bend support 6. the Hold counter button 7. the emergency stop push button 8. the on/off button 9. Counter with reset button 10.

  • Page 9: Starting Up

    Do ONLY use the machine to cut hydraulic hoses. When the machine is intended for cutting other kinds of hoses do ALWAYS contact hydroscand Mach- ine Ab for consultation in the matter. Ensure that every possible safety precaution is taken before starting up the machine.

  • Page 10: Maintenance

    PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 6. Maintenance WARnInG! When doing maintenance on the machine do always make sure that the machine is unplugged from the electrical net, pneumatic and do always press down the emergency switch. Taking these safety measurements ensures that no electrical tension is supplied to the machine that could make it start.

  • Page 11: After Each Working Shift

    PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 6.2 After each working shift • Press the emergency stop button • Remove cutting residue • Reset the counter 6.3 Regular maintenance • • Check the cutting blade for errors and that it is securely tightened.

  • Page 12: Technical Data

    THE INFORMATION CONTAINED IN THIS DRAWING IS is: ra 3,2 MACHINE AB. ANY REPRODUCTION IN PART OR AS Sharp edges broken. PERMISSION OF HYDROSCAND MACHINE AB IS PRO Pungmakarbovägen 1, 783 90, Säter Phone: +46-(0)225-573 30 fax: +46-(0)225-501 08 info@hydroscand-machine.se www.hydroscand-machine.se...

  • Page 13: Technical Draws

    PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 8.1 A1- Wiring diagram Y/D starter Page 13...
  • Page 14 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 14...
  • Page 15 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 15...
  • Page 16 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 16...
  • Page 17 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 17...
  • Page 18 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 18...
  • Page 19 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 19...
  • Page 20 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 20...

  • Page 21: Wiring Diagram Soft Starter

    PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 8.2 A2 - Wiring diagram soft starter Page 21...
  • Page 22 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 22...
  • Page 23 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 23...
  • Page 24 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 24...
  • Page 25 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 25...
  • Page 26 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 26...
  • Page 27 PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 27...

  • Page 28: Pneumatic Diagram

    8. 3 Pneumatic diagram PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 28...

  • Page 29: Technical Drawings

    8. 4 technical drawings PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 29...
  • Page 30 8. 4 technical drawings PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 30...
  • Page 31 8. 4 technical drawings PowerCut 5-85OT USER MANUAL EDITION II 2017-09-08 Page 31...
