Accessory Installation Manual
No.
Part Name
Warm Air Self-supported Duct
Ceiling Tile
Ceiling Tile Kit
Warm Air Flexible Duct
Condenser Air Plenum
Application
All models listed in this manual have the same installation procedure.
Disconnect power before installation. Beware that some residual voltage may remain in the unit
after the power is disconnected. There is a risk of electric shock.
B
A
Climate Pro X14/20/26
Climate Pro K12/18/24
481744-0062
LA146373-8280
484490-1030
LAY45771-0060
484350-1160 (X14/20)
484350-1160 (K12/18)
484350-1180 (X26)
WARNING
1
C
D
Climate Pro D12/18
481744-0062
LA146373-8280
484490-1030
LAY45771-0060
484350-1340 (D12)
484350-1170 (K24)
484350-1350 (D18)
Required Accessories
484007-5020
E
481744-0062
LA146373-8280
484490-1030
LAY45771-0060
Page No.
2
2
3 - 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 481744-0062 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Movincool 481744-0062

  • Page 1 Accessory Installation Manual 484007-5020 Part Name Climate Pro X14/20/26 Climate Pro K12/18/24 Climate Pro D12/18 Warm Air Self-supported Duct 481744-0062 481744-0062 481744-0062 Ceiling Tile LA146373-8280 LA146373-8280 LA146373-8280 Ceiling Tile Kit 484490-1030 484490-1030 484490-1030 Warm Air Flexible Duct LAY45771-0060 LAY45771-0060 LAY45771-0060...
  • Page 2 ATTACHMENT OF WARM AIR SELF-SUPPORTED DUCT 1. Remove the original ceiling tile and install the accessory ceiling tile. 2. Hold the warm air self-supported duct approximately 1 foot away from the end and decrease its diameter as shown until it can be passed through the hole in the ceiling tile.
  • Page 3 ATTACHMENT OF CONDENSER AIR PLENUM 1. Separate the frame and plenum by removing the four (4) bolts. 2. Remove the side filter panel. 3. Attach the frame to the side of the unit by placing the tabs to the edge of the lower opening and secure the frame with the two (2) bolts supplied with the plenum.
  • Page 4 4. Insert the four (4) brackets of the plenum into the slots of the frame and secure the plenum to the frame with the four (4) bolts, which were removed in step 1 on page 3. 5. Remove the two (2) knob bolts and remove the plate from the plenum by lifting upward. 6.
