Sandstrom SFML16 Instruction Manual

Full Motion TV Mount
for Large TVs
Instruction Manual
SFML16
Thank you
for purchasing your new product.
Please follow this quick start guide for a successful rst time set up.
Read all the safety instructions carefully before use and keep the quick start guide
for future reference.
This Mount comes with a 3-year guarantee. If the product fails whilst in use for its
intended purpose, please return it, along with your receipt, for a full refund or
replacement. Please follow the instruction manual carefully when installing this device.
Currys Group Limited (co. no. 504877)
Omni Park SC, Santry, Dublin 9, Republic of Ireland
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct to
your door the very next day. Visit www.partmaster.co.uk
or call 0344 800 3456 (UK customers only) Calls charged
at National Rate.
Http://sandstromstyle.com
1 Portal Way, London, W3 6RS, UK
EU Representative
Currys Ireland Limited (259460)
3rd Floor O ce Suite
SAFETY
DISTANCE TO WALL
55 - 680 mm
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by quali ed personnel only. Incorrect assembly can result in severe personal injury and property
damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden columns.
• It is the installers' responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the designated
maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do not over-tighten
screws.
• Keep this instruction manual for future reference.
UNPACKING
IB-SFML16-211129V8
KG
TV SIZE TV LOAD
37" - 75" 40 kg
TILT ANGLE
-12° ~ +8°
× 4 × 4
A1 A2
× 1 × 2
A6 A7
× 4 × 4
B1 B2
Ø5 × 15mm Ø5 × 30mm
× 4 × 4
B5 B6
Ø8 × 20mm Ø8 × 35mm
× 4 × 8
B8 B9 B10
Ø6-Ø8 × 5mm Ø6-Ø8 × 10mm Ø5 / Ø8
VESA COMPLIANCE
200 x 200 – 600 x 400 mm
SWIVEL ANGLE
-90° ~ 90°
× 4 × 1 × 1
A3 A4 A5
× 2
A8
× 4 × 4
B3 B4
Ø6 × 15mm Ø6 × 35mm
× 4
B7
Ø8 × 50mm
× 4
