Summary of Contents for GOEBEL GO - LB1
- Page 1 GO - LB1 Cordless Lockbolt Battery Tool User Manual User Manual...
-
Page 2: Table Of Contents
11 - 12 4. Charger & Batteries 4.1 Technical parameters 4.2 Using the charger 4.3 Using the battery 5. FAQ (Questions / Answers) 6. Troubleshooting 6.1 Malfunctions 6.2 Possible causes 6.3 Corrective measures 7. Protection conditions & CE certification www.goebel-group.com... -
Page 3: Safety Measures
Please keep the packaging box and accessories and handle them with care. • The tool and accessories should be placed in the plastic case, stored in a dry place and out of the reach of children. www.goebel-group.com... - Page 4 • Maintenance personnel must have professional skills; only qualified professionals can carry out repairs. If in doubt, please return the tool to the authorised dealer or manufacturer for repair. • Original spare parts must be used during maintenance. www.goebel-group.com...
-
Page 5: Daily Maintenance & Environmental Protection
• If your country or region has regulations, please be sure to take the old battery to a professional company for disposal. • Do not throw old batteries into the rubbish, fire or water! 1. Tool overview Name of the component Screw Cap Tool Housing Mouthpiece Battery LED Light Charger Trigger Collector www.goebel-group.com... -
Page 6: Capacity
Conventional setting mode Traction Power 23000N Stroke 16 mm Net weight (incl. battery) 1,5Kg Capacity ø 4,8 to 6,4 mm Material specification All materials and specifications of extensive grip range lockbolts and the 6-groove lockbolts 1.2 Configuration / Accessories (Fig. A) www.goebel-group.com... - Page 7 2277012410 Battery Charger 2277012510 * General configuration Very important note! This product is supplied with the factory default configuration. If users have other special requirements or wish to customise the configuration, please contact the dealer or manufacturer in advance. www.goebel-group.com...
-
Page 8: Parts List (See Fig. B)
2 | Deutsch 7 | English 1.3 Parts list (Fig. B) Abb. B www.goebel-group.com... -
Page 9: Tool Parts List Of The Go-Lb1
Mouthpiece Ø 6,4 mm Magna 2277061810 Trigger Spring 2277049511 Clamping Sleeve Ø 6,4 mm Magna 2277011810 Trigger 2277049411 3-Jaw Set Ø 6,4 mm Magna * Important note: Serial numbers 2-4, 15-17, 21-26 (shaded part with *) are optional accessories! www.goebel-group.com... -
Page 10: Preparing The Tool
Now you can replace the screw cap, the mouthpiece, the jaw sleeve and the 3-jaws according to ③ Once the process is complete, screw the screw cap back on according to ④ using the wrench. Now you can reinsert the battery. www.goebel-group.com... -
Page 11: Checking The Battery
You save energy with the automatic sleep mode, no operation within one minute and the white illumination light LED goes out automatically. Thus, the tool goes into auto- matic sleep mode. When you pull the trigger again, the power supply is restored. www.goebel-group.com... -
Page 12: Tool Operation
Therefore, a pre-installation (trial setting) is required, before the official setting process. We recommend that you use GOEBEL lockbolts for optimum processing. 3.2 Instructions for the setting process ➁... - Page 13 DWG No. GO-LB1_Bedieungsanleitung Rev. Date of issue Sheet process is completely finished. ⑥ ⑥ An installation of GOEBEL lockbolts can cover different clamping ranges with one dimension - preferably the G-GRIP® lockbolt made of stainless steel is suitable here. www.goebel-group.com...
-
Page 14: Charger & Batteries
• The battery has deep discharge protection (ECP) and can be recharged about 1000 times. • Do not use the charger until the battery has cooled down sufficiently. • If the battery's operating time is significantly reduced during normal use, this indicates that the battery should be replaced. www.goebel-group.com... -
Page 15: Faq (Questions / Answers)
5. FAQ English | 14 Questions Answers ▶ ▶ Battery Is it okay not to use them for a long time? Charge the battery at least every 6 months, otherwise it may deteriorate in performance after 6 months. ▶ ▶ Does charging after each use affect battery Suggestion: When the remaining battery time is only 25% (a light on the display) or when the life? -
Page 16: Protection Conditions & Ce Certification
15 | English 7. Protection conditions & CE certification Warranty period & maintenance protection Our products have a lifetime after-sales service. If a quality problem is found in use, we will provide warranty. The warranty period for this tool is 1 year and the start date is based on the sales invoice.
