  • Page 1 45°+ 45° FENIX wall-mount vanity Installation Guide 45° vanities 45° FENIX vanities FXV1-0700 + FV1D-0700 FXV2-0700 + FV2D-0700 F45V2-0700 F45V1-0700 FXV1-0900 + FV1D-0900 FXV2-0900 + FV2D-0900 F45V1-0900 F45V2-0900 FXV1-1200 + FV1D-1200 FXV2-1200 + FV2D-1200 F45V1-1200 F45V2-1200 FXV1-1400 + FV1D-1400 FXV2-1400 + FV2D-1400...
  • Page 2 Attention — Before Installation Thank you for choosing from among Blu’s quality line of products. We recommend that you carefully read this installation guide to ensure your vanity’s proper operation and reliability for many years to come. NOTE: Adhere to all local building and plumbing codes. The diagrams in this guide are not construction plans. They are visual aids.
  • Page 3 Before Installation the Drawer 1. How to Unlock the Drawer: 45° FENIX Vanity Press the flaps on both sides, while lifting PUSH 2. How o Unlock e Drawer: 45° Vanity 2019-06 1 866 907 0122 blubathworks.com...
  • Page 4 Installation: For both the 45° FENIX + 45° series 2019-06 1 866 907 0122 blubathworks.com...
  • Page 5 How to Hook the Drawer: 45° Vanity + 45° FENIX Vanity A. Pull the drawer glides/sliders B. Place the drawer on the glides/sliders and press the bottom until full closure 2019-06 1 866 907 0122 blubathworks.com...
  • Page 6 Adjust the Front of the Drawer: 45° FENIX Vanity Remove the side plates To move the front to the right or to the left release the bolts on the bottom (X) and turn the screw on the right side of the tray with a screwdriver To move the front up and down turn the rings placed on the two sides of the drawer Version with Glass Sides: 45°...
  • Page 7 Adjust the Drawer/Front Panel: 45° Vanity Adjust the Front of the Drawer: 45° FENIX Vanity Remove the side plates To move the front to the right or to the left release the bolts on the bottom (X) and turn the screw...
  • Page 8 Care and Maintenance Wood finish Clean with a soft cloth or humid non-abrasive sponge using neutral and non-abrasive detergents. Rinse the surface carefully after cleaning. Do not use aggressive chemical solvents, such as acetone and trichloroethylene. In case of persistent stains, use a soft cloth and neutral soap.
