ROLL 'N' GO MANUAL SHEETING SYSTEM
INSTALLATION MANUAL
&
OPERATORS MANUAL
This manual incorporates instructions & parts information
This manual is supplied as a fitting guideline and is subject to change without prior notice.
Uncontrolled when printed – Version 2
Advertisement
Related Manuals for Harsh ROLL 'N' GO
Summary of Contents for Harsh ROLL 'N' GO
- Page 1 ROLL ‘N’ GO MANUAL SHEETING SYSTEM INSTALLATION MANUAL & OPERATORS MANUAL This manual incorporates instructions & parts information This manual is supplied as a fitting guideline and is subject to change without prior notice. Uncontrolled when printed – Version 2...
- Page 2 ROLL ‘N’ GO FITTING GUIDELINES Packing List When you receive your Roll ‘N’ Go kit from Harsh please check to see all the essential items listed below are present and correct. Item Quantity Apex/Dome* Centre Pole* Side Pole* 50mm Ratchet...
- Page 3 2. Next, you should rivet the pole into the centre pocket of the sheet from underneath, riveting through the line of black PVC tape into the Centre Pole. Rivets should be fitted at even intervals keeping to a rough guide of 30cm / 1 foot per rivet. Place a final rivet on the very end of the centre pole pocket on the top of the sheet through the black PVC tape.
- Page 4 Step By Step Guide – Full Installation First you should measure the roll over sheet in length. ENSURE TO PLACE THE SHEET ON A CLEAN SMOOTH SURFACE OR PROTECTIVE SHEET. Place the front and rear domes on the vehicle body (flush to both front and back) to correspond with the roll over sheet length.
- Page 5 Rivet the pole into the centre pocket of the sheet from underneath, riveting through the line of black PVC tape into the Centre Pole. Place a final rivet on the very end of the centre pole pocket on the TOP of the sheet through the black PVC tape.
- Page 6 Fix the ratchet buckles at the front and rear of the vehicle using bolts. Fit them as near to the front and rear as possible. To accommodate the webbing retaining straps around the side pole, cut three holes in the side pocket. One above each of the ratchet buckle positions and one centrally.
-
Page 7: Maintenance
4) Regularly clean and lubricate the universal joint on the winding handle. WARNING: This is a warning about dangerous misuse of the harsh Roll ‘N’ Go sheeting system. The misuse is moving the vehicle while the sheet is in the open position. Even if the rolled sheet is tied down it is dangerous to all concerned.
