- Page 1 TEC 2602 (ver:AMOSTEC2602SM20140309) Slide Dryer Service Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140 www.amos-scientific.com...
- Page 3 TEC 2602 Slide Drier Service Manual 1、 General Provisions The Service Manual of the instrument is compiled according to its structure and characteristic. 2、 Configuration Power supply of the instrument is AC110V/220V. Slide Drier can heat up and control temperature.
- Page 4 C、There is continuous ring in buzzer(the interval is 10 seconds) It means that the digital sensor is broken, and need to replace the digital sensor. TEC 2602 Slide Dryer AMOSTEC2602SM20140309 ---2---...
- Page 5 Maintain：use the Philip screwdriver to loosen the six screws in the base-board, take down the base-board and you will see the solid state relay as it showed in the picture. Take down the damaged SSR and replace a new SSR. TEC 2602 Slide Dryer AMOSTEC2602SM20140309 ---3---...
- Page 6 Wiring Diagram 4、 J-Heat 220V/110V P=330W Heater 110V/220V---5A TEC 2602 Slide Dryer AMOSTEC2602SM20140309 ---4---...
- Page 7 Schematic Diagram 5、 TEC 2602 Slide Dryer AMOSTEC2602SM20140309 ---5---...
- Page 8 Published by: AMOS SCIENTIFIC PTY.LTD 37/632 CLAYTON ROAD , CLAYTON SOUTH VIC 3169 , AUSTRALIA Tel: +61-3-95518850 Fax: +61-3-95516885 ABN 37 159 778 140 www.amos-scientific.com...
