Rotary Laser Level
Art. No 40-7530
Please read the entire instruction manual before using the product and save it for future reference. We reserve the right for any errors in text or images
and any necessary changes made to technical data. If you have any questions regarding technical problems please contact Customer Services.
1. Safety
•
Keep the product's warning labels in readable condition.
•
Never point the laser towards people or animals and never
look into the laser yourself. Even low intensity lasers can
cause permanent eye damage.
•
This product contains no parts that you can repair yourself. This
product must not be dismantled, opened or modified in any way.
•
The laser may not be used for other purposes other than to
project laser lines for the purposes of measuring.
•
This measuring instrument emits a Class 2 laser beam
according to the IEC 60825-1 standard. There is a possible
risk that this laser if used improperly could cause blindness
in humans and animals.
•
The laser viewing glasses must not be used as safety glasses.
The laser viewing glasses improve the visibility of the laser
beam but do not protect eyes from laser radiation.
•
Laser viewing glasses must not be used as normal sunglasses
or in street traffic.
•
Laser viewing glasses do not provide complete UV protection
and reduce colour perception.
•
Only let qualified tradesmen repair this instrument
and only using original parts.
•
Never point the laser onto reflective material.
•
This product is not a toy. Never let children use the laser level
without supervision. There is a possible risk of inadvertently
blinding someone.
•
Never position the laser level in such a way that the beam
projects at eye level and could shine into someone's eyes.
•
Never leave the laser switched on unattended. Always turn
it off after completing a measurement. There is a possible
risk that someone could be blinded by the laser beam.
Extra safety regulations particularly for lasers
Warning! Laser emissions.
Laser class II, 635 nm.
Never look directly into the laser beam.
Do not look at the laser beam through an optical instrument.
2. Description
•
This laser generates a reference line, which when
used indoors or in indirect sunlight provides a visible
reference line on the surface it is pointed at.
•
Ideal for hanging wallpaper borders and trim.
•
Intended for indoor use.
•
Laser glasses, tripod, batteries and case included.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk
and click on customer service.
Model RL13BMC
Contents
•
Rotary laser level
•
Tripod, max height: 120 cm
•
Laser viewing glasses
•
Target plate
•
4 x AAA/LR03 batteries
•
Instruction manual
•
Case
3. Buttons and functions
1
2
3
4
7
1. Laser window
2. Bubble vials
3. Adjusting screws
4. On/off switch, rotation speed control
5. Hanging slot
6. Battery cover
7. Target plate
5
6
