INTRODUCTION
Introduction
WELCOME
Congratulations on your purchase of the Uniden MiniCel
cellular phone. You have chosen to enter the world of
cellular telephone technology with one of the finest portable
cellular phones available today. Now you can place or
receive calls from anywhere there is cellular coverage.
Your MiniCel can go with you anywhere so that you're
never out of touch – in your car, on the beach, at the
golf course or even just for a walk in the woods.
With the roam feature, you can use your phone when
you travel away from your own area. The many standard
features on the MiniCel make calling quick and
convenient. The easy-to-use menu functions help you
customize your MiniCel.
We're confident you will be proud to own the MiniCel. To
make sure you understand all its convenient features,
please take the time to read this owner's manual. It will
help you use the technology and convenience of cellular
communications.
AUTHORIZATION REQUIREMENTS
You must contact your local cellular service company to
obtain authorization and a cellular telephone number
before using your MiniCel. Fees for cellular service vary
from company to company.
FEATURES
•
50 Memory Locations
•
128K Bytes Flash Memory
•
Any Key Answer
•
One-Touch Emergency Dial
•
Speed Redial and Super Speed Redial
•
Programmable 20-Character Greeting
•
Password Protection Auto PIN
•
Battery Alarm
•
Two-Line, 20 Character LCD Display
•
Scratch Pad Memory
•
Speaker and Ringer Volume Control
•
Keyguard
•
Call Timers
•
Tone or Vibrate Alert
3
Advertisement
Table of Contents
Related Manuals for Uniden Mini 200
Summary of Contents for Uniden Mini 200
- Page 1 Default screen Introduction INTRODUCTION WELCOME Congratulations on your purchase of the Uniden MiniCel cellular phone. You have chosen to enter the world of cellular telephone technology with one of the finest portable cellular phones available today. Now you can place or receive calls from anywhere there is cellular coverage.
-
Page 2: Included In Your Package
INCLUDED IN YOUR PACKAGE To get the most from your phone, please read this owner’s manual thoroughly. Also, be sure to complete and mail the Mini 200 AC Adapter and Charger product registration form. WARNING Rechargeable Battery (one of the following:) -
Page 3: Installing The Battery
2) Plug the AC adapter into a standard 120 VAC wall outlet. Use only the Uniden AC adapter supplied with this phone. DO NOT use an outlet controlled by a wall switch. -
Page 4: Battery Low Alarm
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen BATTERY LOW ALARM When the battery is low, shows in the LCD display, the battery icon starts flashing, and the battery low warning tone sounds. ANTENNA Before placing or receiving a call, gently pull the antenna up until it clicks into place. -
Page 5: Receiving A Call
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Calling CALLING RECEIVING A CALL SPEED 1) When someone calls your MiniCel, DIAL the LCD backlight flashes, the alert sounds (see page ) or Press , the two-digit vibrates (see page ) and memory location appears. -
Page 6: Ending A Call
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Redial From Last 10 Completed Calls 1) With no digits in the display, press send HINT You will see the last number dialed. To return to the blank 2) Press to scroll screen, press... - Page 7 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Using the Scratch Pad Use the scratch pad to record a phone number during a call. Then you can dial that number from the scratch pad or enter it into a memory location. 1) During a call, enter the number with the keypad.
-
Page 8: Storing Numbers And Names
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Memor y Programming MEMORY PROGR AMMING STORING NUMBERS AND NAMES The MiniCel has 50 memory locations (01 through 50). You can also store a 10-digit description or name to identify the phone number. -
Page 9: Calling Stored Numbers
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen CALLING STORED NUMBERS Speed Dial Press , the two-digit memory location number (01-50) and send Put the phone numbers Or, press , the one-digit number for 1 through 9; that you call the most in then press send... -
Page 10: The Function Menu Map
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Menus - Customizing Your Phone MENUS THE FUNCTION MENU MAP Quick Menu Access To quickly move through the menu levels, use the keypad. Example: To quickly change the answer option from any key to send only: Press , and... -
Page 11: Sound Menu
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen SOUND MENU Alert Volume and Tone Menu You can change both the volume and tone of the alert. The alert tones come To change the alert volume: from the speaker on the 1) To go to the sound menu from back of the phone. - Page 12 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Earpiece Volume Menu You can adjust the volume from loud to soft. 1) To go to the sound menu from HINT standby, press menu To move to a menu, use either the (up) 2) Press...
- Page 13 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Keypad Volume Menu When you press the keys, a tone sounds. You can adjust the volume from loud to no sound. 1) To go to the sound menu from standby, press menu The keypad tones comes...
- Page 14 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Speaker Volume Menu You can adjust the volume from loud to no sound. 1) To go to the sound menu from standby, press menu The alert tones comes from the speaker on the 2) Press back of the phone.
- Page 15 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Minute Minder Menu 1) To go to the sound menu from standby, press menu 2) Press 3) Press menu HINT 4) Press four times to get to the minute minder menu.
-
Page 16: Phone Settings Menu
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen PHONE SETTINGS MENU Vibrate Menu You can choose between “ring” or vibrate to alert you to an incoming call. 1) To go to the phone settings menu from standby, press menu 2) Press... - Page 17 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Answer Option Menu You can choose whether you want to answer a call by pressing any key on the keypad (other than ) or HINT by pressing send 1) To go to the phone settings To move to a menu,...
- Page 18 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Light Menu You can choose how long you want the backlight to light. 1) To go to the phone settings HINT menu from standby, press menu To move to a menu, use either the (up) 2) Press...
- Page 19 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Change Greeting Menu The first message that appears when your phone is turned on is the greeting. HINT 1) To go to the phone settings menu from standby, To move to a menu, press menu...
- Page 20 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Enable Keyguard Menu You can protect your phone from accidental key stroke by disabling the keypad until there is an incoming call. 1) To go to the phone settings menu from standby, press menu...
- Page 21 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Headset Menu For hands-free calling, you can add an optional headset. The headset menu has two settings: alert repeat or HINT auto-answer. 1) To go to the phone settings To move to a menu, menu from standby, use either the...
- Page 22 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Contrast Menu You can choose how much contrast you want in the backlight display. High increases the contrast (darker HINT pixels) and low decreases the contrast (lighter pixels). 1) To go to the phone settings To move to a menu, menu from standby,...
-
Page 23: Security Menu
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen SECURITY MENU Change Password Menu HINT 1) To go to the security menu from standby, press menu To move to a menu, use either the (up) (down) key. 2) Press three times. - Page 24 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen PIN Calling Menu To change the PIN: 1) To go to the security menu from HINT standby, press menu To move to a menu, use either the (up) 2) Press three times.
-
Page 25: Call Timers Menu
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen CALL TIMERS MENU Call timers keeps count of the time (hours, minutes and seconds) that you have used the phone. Reset when you HINT want. Can be for one call, totals calls on line 1 and/or line 2. - Page 26 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Show Last Call Time Menu 1) To go to the call timers menu from standby, press menu HINT To move to a menu, 2) Press four times. use either the (up) (down) key.
- Page 27 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen All Calls Menu 1) To go to the call timers menu from standby, press menu HINT To move to a menu, 2) Press four times. use either the (up) (down) key.
-
Page 28: Service Settings Menu
All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen SERVICE SETTINGS MENU Phone Line Menu 1) To go to the service settings menu from standby, press menu HINT To move to a menu, 2) Press five times. use either the (up) (down) key. - Page 29 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Network Menu 1) To go to the service settings menu from standby, press menu HINT To move to a menu, 2) Press five times. use either the (up) (down) key.
- Page 30 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Specifications SPECIFICATIONS Channels: Frequency Range: Transmit: 824.04 to 848.97 MHz Receive: 869.04 to 893.97 MHz Channel Spacing: 30 kHz Duplex spacing: 45 MHz Frequency Stability: +/- 2.5 ppm Receiver Sensitivity: -116 dBm at -4°F (-20°C) to +122°F (50°C) 3.7V +/- 10%...
- Page 31 All manuals and user guides at all-guides.com Color profile: Disabled Composite Default screen Optional Accessories ACCESSORIES Car Power Adapter Hands-free Headset Pack MC2004 MC2006 Rechargeable Battery Rechargeable Battery 580 mAH nickel metal 580 mAH Lithium-ion hydride (MC580N) (MC580L) Extended Life Wrist Strap Rechargeable Battery MC2007...
