Redington Delta Owner's Manual

CARE AND MAINTENANCE

To extend the life of your Delta reel, always protect the
outer frame and spool. We also recommend the following
easy maintenence tips:
To clean the reel, first rinse off any dirt or grit in cool
fresh water.
Use a cloth or toothbrush to carefully remove all sand
and grit from the reel with warm soapy water and rinse
again.
Separate the spool from the frame and dry thoroughly.
Once dry, reduce the drag pressure to the lowest setting
and store in the reel case.
Always store reel away from extreme heat.
After using in saltwater, always take the time to clean
your reel. Saltwater can leave a residue that will harden
over time if not properly cleaned and dried.

RETRIEVAL CONVERSION

Remove the spool from the frame by sqeezing the hub
1
release lever and lifting the spool free.
Unscrew the clutch bearing cap on the spool hub
2
located opposite of the handle side.
Turn the spool over and tap out the one-way bearing.
3
Replace the one way bearing in the frame with the
4
metal housing facing up for right hand retrieve.
Screw the cap back into position covering and securing
5
the clutch bearing in place. Ensure that the cap is tight
and properly seated.
Place the spool back in the frame.
6
Assure correct retrieve direction and smooth operation.
7
pursuetheoutdoors.com/schematics

WARRANTY INFORMATION

Each new Redington Delta fly reel purchased from
an authorized dealer is covered by our lifetime
original owner guarantee.
All repairs require the reel be sent to the Redington
Warranty Department for service. Questions and
inquiries regarding warranty and repair service
should be directed to 1-866-498-7243. You may also
view warranty details on our website or send an email to
warranty@redington.com with any questions
that may arise.
