CARE AND MAINTENANCE
To extend the life of your Rise reel, always protect the outer
frame and spool. We also recommend the following easy
maintenence tips:
To clean the reel, first rinse off any dirt or grit in cool
fresh water.
Use a cloth or toothbrush to carefully remove all sand
and grit from the reel with warm soapy water and rinse
again.
Separate the spool from the frame and dry thoroughly.
Once dry, reduce the drag pressure to the lowest setting
and store in the reel case.
Always store reel away from extreme heat.
After using in saltwater, always take the time to clean
your reel. Saltwater can leave a residue that will harden
over time if not properly cleaned and dried.
Rise_Reel_Owners_Manualv2.indd 1
RETRIEVAL CONVERSION
Remove the spool from the frame by squeezing the hub
1
release lever and lifting the spool free.
Remove the pentagon shaped wire retainer with your
2
finger nail or a small screwdriver.
Turn the spool over and tap out the one-way bearing.
3
Replace the one way bearing in the frame with the
4
metal housing facing up for right hand retrieve.
Snap the wire retainer back in the groove, and confirm
5
it is properly seated.
Place the spool back in the frame.
6
Assure correct retrieve direction and smooth operation.
7
WARRANTY INFORMATION
Each new Redington Rise fly reel purchased from
an authorized dealer is covered by our lifetime
original owner guarantee.
All repairs require the reel be sent to the Redington
Warranty Department for service. Questions and
inquiries regarding warranty and repair service
should be directed to 1-866-498-7243. You may also
view warranty details on our website or send an email to
warranty@redington.com with any questions
that may arise.
4/21/10 3:01 PM
