KneeRover® Knee Walker Jr.
User Manual

Advertisement

loading

Related Manuals for KneeRover Knee Walker Jr

Summary of Contents for KneeRover Knee Walker Jr

  • Page 1 KneeRover® Knee Walker Jr. User Manual...

  • Page 2: Ongoing Maintenance

    (< 3 mph). Ongoing Maintenance: With routine use, nuts and bolts on the KneeRover® knee walker can become loose. To ensure safe operation of your KneeRover® scooter, it is important to periodically inspect for loose nuts and bolts and re-tighten as appropriate.
  • Page 3 KneeRover® Knee Walker Jr. - Tools & Parts List: The following tools and parts are included with your KneeRover® Knee Walker Jr. Please follow assembly instructions for your specific KneeRover® model, using the tools and parts provided. Assembly videos for your KneeRover® model can also be found at: https://kneerover.com/pages/assembly-video...
  • Page 4 KneeRover® Knee Walker Jr. Set Up Instructions: Please follow the step by step instructions on the following pages to properly assemble your KneeRover® Knee Walker Jr. The diagram below identifies the key components of the scooter to aid with assembly.
  • Page 5 Step 1: Secure the Steering Column Raise the steering column and push the clamp lever to the left to allow security pin to lock into place (Top Left and Right). Raise the clamp lever upward into the “U” slot and tighten by turning it clockwise (Bottom Left). Finally, push clamp lever down firmly to secure the steering column (Bottom Right).
  • Page 6 Step 2: Insert Handle Bar into the steering column and set at the proper height Please make sure the brake line is not twisted and the brake handle is facing forward. Insert the Handle Bar into the steering column (Top). Raise the handle bar to a comfortable position and insert the height adjustment knob into the hole and tighten (Bottom).
  • Page 7 Step 3: Install Knee Platform and Adjust Height The knee platform is designed to be used with either the right or left leg. Insert the knee platform post into the receptacle tube (Top Left). Next, set the knee platform at your desired height for use by inserting the locking pin through the aligned holes (Top Right).
  • Page 8 Step 4: Basket Assembly Locate the basket bracket on the front of the steering column (Top). Place the rear basket holes over the bracket and push down (Middle). Your basket is now installed on the steering column (Bottom). Bracket Place basket on the bracket and push down Properly installed basket...
  • Page 9 Brake and Parking Brake Operation Your KneeRover® Knee Walker Jr. comes equipped with a Brake Lock/Parking Brake. To engage the brake, squeeze the brake lever on the handle bar. To apply the parking brake, squeeze brake handle firmly and while squeezing the brake handle press the silver button to engage the lock.
  • Page 10 (Top). Squeeze the spring together and pull the brake cable down (Bottom Left). While holding the brake cable, retighten the nut (Bottom Right). You may also view the brake adjustment video by visiting https://kneerover. com/pages/kneerover-maintenance-videos. Loosen 10mm nut Squeeze spring together...

  • Page 11: Warranty

    What is Covered? While the frame is covered for the life of the KneeRover®, some parts of the scooter are subject to normal wear and tear and depending on the use, may not last the lifetime of the scooter. The applicable warranty coverage for all parts are listed below.
  • Page 12 KneeRover® Knee Walker Safety Instructions: The following safety instructions and warnings are provided to educate the user on how to safely operate a knee walker. Knee Walkers are mobility devices designed to provide increased mobility during recovery from foot/ankle/lower leg surgery or injury.
  • Page 13 Only use accessories and replacement parts authorized by the KneeRover® brand. Accessories designed by other manufacturers have not been tested by KneeRover® and are not recommended for use with KneeRover® products. As a reminder, this is a mobility / walking aid, not a recreational device.
  • Page 14 SAFETY INSTRUCTIONS FOR OPERATING KNEE WALKER: As with any new physical activity, practice and common sense are necessary for successful use of the knee walker. Before operating the knee walker at normal walking speed, practice maneuvering and making turns at slow rates of speed to get familiar with the knee walker and how to best maintain balance.
  • Page 15 DO NOT operate on inclines above 15 degrees (slight incline). Use Extreme Caution when operating the knee walker on any slopes, as there is risk of losing balance. It is best to avoid slopes. Only mount or dismount your knee walker on a level surface. DO NOT attempt to reach for objects while the knee walker is in motion.
  • Page 16 KneeRover® scooter. We hope we’ve earned a 4 or 5 star review - if not, please give us the opportunity to help you before leaving a review.
