PLAYBACK CENTER CONFIGURATION
In the PC software playback center, Select the type of playback for terminal
acquisition, as shown in the following figure:
①
⑤
⑧
⑥
⑦
1. Task name: User new built playing mission name (Like BGM acquisition) can edit
as you want (must edit).
2. Task priority: Set priority of play mission, user need to choose within (1~70) (The
less data, the low priority).
3. Sound source: Choose terminal acquisition ( Must choose).
4. Acquisition Terminal: Terminal device can just be local audio acquisition terminal,
cannot other device.
5. Terminal name: choose broadcast terminal.
6. Terminal volume: Set terminal volume, user can choose within (1~100).
7. Clear content: If is failed of edit mission, choose "wipe off" button and then edit.
8. Acquisition model: Common, Middle class and high class:
1)Common Acquisition: Based on 100M internet bandwidth, can support only within
300 terminal and can get extremely delay effect of internet audio acquisition.
2)Middle class Acquisition: Based on 100M internet bandwidth, can support only
within 200 terminal and can get low delay effect of internet audio acquisition.
3)High Class Acquisition: Based on 100M internet bandwidth, can support only
within 100 terminal and can get extremely distortion effect of internet audio
acquisition.
After finishing all relate setting and click confirm button to save and enter into status
of playing mission.
② ③
④
