akira MC-6320V Service Manual

Vcd micro system
Hide thumbs

Advertisement

Quick Links

Download this manual
VCD MICRO SYSTEM
Service Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MC-6320V and is the answer not in the manual?

Questions and answers

Related Manuals for akira MC-6320V

Summary of Contents for akira MC-6320V

  • Page 1 VCD MICRO SYSTEM Service Manual...
  • Page 2 MODEL: MC-6320V Model No.: MC-6320V Version: 1.0...

  • Page 3: Table Of Contents

    CONTENTS SPECIFICATIONS........................... 4 ALIGNMENT INSTRUCTIONS......................5 CIRCUIT DIAGRAM ..........................5 EXPLODED VIEW..........................5 PART LIST ............................... 5 Model No.: MC-6320V Version: 1.0...

  • Page 4: Specifications

    Single cassette system (Auto stop system) 2 bands (AM /MW /SW) radio, analogue tuning Automatic level control (ALD) for recording Built-In condenser Mic X-bass On /Off Full function remote control 573(W) x 315(D) x 535(H)mm Model No.: MC-6320V Version: 1.0...

  • Page 5: Alignment Instructions

    Connect the VTVM, oscilloscope and 4 ohm dummy load to the Speaker terminal. Set the Volume Control to max. Position. Set the Signal Frequency as listed in FM Alignment Chart and maintain a sufficient output level to provide an obvious reading. Model No.: MC-6320V Version: 1.0...
  • Page 6 " repeat steps 2 and 3 as required " FM-RF Tune to signal Adjust for max. 90MHz (90MHz) Indication Tune to signal Adjust for max. 106MHz Trimmer of pvc (106MHz) Indication " repeat steps 5 and 6 as required " Model No.: MC-6320V Version: 1.0...
  • Page 7 Tuning Gang max. Adjust for max. 3.1MHz capacity Indication Tuning gang min. Adjust for max. 12.25MHz capacity Indication " repeat steps 2 and 3 as required " Tune to signal Adjust for max. 3.5MHz (3.5MHz) Indication Model No.: MC-6320V Version: 1.0...
  • Page 8 Playback track 1 and set volume position to obtain 1V ( 0 dB ) output from the speaker terminal. Playback track 6 and track 18 to read the output level which must within specification – 6dB. Model No.: MC-6320V Version: 1.0...

  • Page 9: Circuit Diagram

    CIRCUIT DIAGRAM Model No.: MC-6320V Version: 1.0...

  • Page 10: Exploded View

    EXPLODED VIEW Model No.: MC-6320V Version: 1.0...

  • Page 11: Part List

    Power SW Screw (TPS 3x10) Volume knob Damping gear Bass HNOB Volume PCB assy Screw (TWS 3x10) Cassette key 1 set Cass key clip Cass deck Dial bracket TS28EQ bkt Dial bracket Tuning bracket Dial drum Model No.: MC-6320V Version: 1.0...
  • Page 12 600 plate VCD output PCB assy Phone PCB bkt CD dust cover CD deck CD rubber Screw (PWB 2x16) CD (VCD) PCB E-ring Dial pully Tuning shaft Slide knob (R) Slide knob (L) Control PCB Model No.: MC-6320V Version: 1.0...
  • Page 13 PART NAME Sensor PCB Function knob 1 set Tuning knob Display lens plate Display lens Control lens plate Control lens VCD output PVC plate Model No.: MC-6320V Version: 1.0...
