  • Page 1 App manual Wi-Fi measuring socket Item no. 2138451...

  • Page 2: Table Of Contents

    Content Introduction General information Important Information Up-to-date operating instructions Requirements Legal Notice Mobile app Installing the app First start of the app Creating an account Logging in Creating a family Functions on the home page of the app Configuration and operation Adding a new device Operating the Wi-Fi measuring socket Further device settings...

  • Page 3: Introduction

    Introduction The software application (hereinafter - “app”) enables wireless operation of the Wi-Fi measuring socket. This manual serves to explain the app installation, opera- tion and handling. All company and product names are trademarks of their respective owners. All rights reserved. Android is a registered trademark of Google LLC.

  • Page 4: Requirements

    Requirements • Smartphone/tablet with 2.4 GHz Wi-Fi (5 GHz is not supported) • Wi-Fi router or access point with 2.4 GHz Wi-Fi (5 GHz is not supported) • Operating system: Android 4.4.2 or higher; Apple iOS 8.0 or higher Legal Notice This is a publication by Conrad Electronic SE, Klaus-Con- rad-Str.

  • Page 5: Mobile App

    Mobile app These instructions refer to a smartphone. But this always means an Android -smartphone or tablet or iPhone or iPad. Installing the app • Open the respective App Store on your smartphone . If you are using An- droid , open “Google Play”.

  • Page 6: First Start Of The App

    Please note the system requirements in this manual and in the description of the app in the respective store. Please note that the following instructions may change for future app versions. First start of the app • Open the previously installed “Smart Life - Smart Living”...
  • Page 7 • Tap the right button to accept the privacy policy.

  • Page 8: Creating An Account

    Creating an account • To create an account, you can use either an e-mail ad- dress or a mobile number. • If you want to create an account with a mobile number, tap the corresponding button at the top right.
  • Page 9 • Firstly, tap the right arrow (square in the figure) in the following screen and select your country. The country code is then accepted automatically. • Then enter your mobile number in the corresponding field (without country code and without 0 at the begin- ning).
  • Page 10 • To create an account using your e-mail address, tap the corresponding button at the top left. • Enter the e-mail address with which you want to regis- ter. • Tap the button below to confirm the input and request the verification code.
  • Page 11 • Once you have requested the verification code, you will receive either an SMS or an email with the verification code, depending on which registration method you have chosen. • Enter the 6-digit verification code in the field. As soon as the timer at the bottom right has run down, a new code will be sent.
  • Page 12 • Enter a secure password consisting of at least 8 charac- ters. We recommend a password consisting of uppercase and lowercase letters, as well as numbers and special char- acters. • Tap the blue button below to complete the registration.

  • Page 13: Logging In

    Logging in • If you are not automatically logged in after registering, or if you already have an account, you can log in to the app now. • To do this, tap the button below (see arrow in the fig- ure).
  • Page 14 • If you have created your account using your mobile number, first tap the right arrow (square in the figure) and select your country. The country code is then ac- cepted automatically. • Enter either your mobile number or email address in the corresponding field.

  • Page 15: Creating A Family

    Creating a family • On the home page, tap the button in the lower right cor- ner to create a profile.
  • Page 16 • Select the item for family management.
  • Page 17 • Enter the desired family name in the field at the top. • To add a location, tap the right arrow (square in the fig- ure). • Then select one or more rooms, depending on where you have Smarthome devices installed.
  • Page 18 • If you swipe the display all the way down, you can also add rooms yourself (lower arrow in the figure). • Finally, tap the button at the top right to save the set- tings and create the family. You can also edit the family later in the app and, for example, add or remove rooms.
  • Page 19 • Tap the right button (arrow in the figure) in the following screen.
  • Page 20 • You are now on the family management page. If you choose the newly created family, you can edit it and, for example, add new members (with their own account). • To exit the family settings and return to family manage- ment, tap the top left arrow (square in the figure).
  • Page 21 • After exiting family management, you will see the main display of the app.

  • Page 22: Functions On The Home Page Of The App

    Functions on the home page of the app Here is a brief overview of the controls on the home page of the app.
  • Page 23 Opens a small menu, from which you can open di- rectly family management Switches to the display of the respective room Switches to the display of all devices Adds a new device; identical with A14 Switches to the home page of the app (this display) Switches to scenes and automation Switches to your profile and settings Directly opens room management...

  • Page 24: Configuration And Operation

    Configuration and operation Adding a new device • To add a new device, on the home page of the app tap either “+” in the upper right corner or the corresponding blue button at the bottom.
  • Page 25 • For the Wi-Fi measuring socket, on the next page first select the uppermost item in the menu on the left and then the Socket (Wi-Fi) icon on the right-hand side.
  • Page 26 • Before you continue, connect the Wi-Fi measuring sock- et to the power supply, if you have not already done so, and wait until the start process is complete. • Now press and hold down the button on the Wi-Fi measuring socket for approx.
  • Page 27 • If your Wi-Fi network has not been accepted automati- cally, first select it and then enter the Wi-Fi password below. • Tap the bottom blue button to save the selection and continue. Please note that only 2.4 GHz Wi-Fi networks are supported.
  • Page 28 • The app will now search for the device and connect to • Then the Wi-Fi settings will be transferred.
  • Page 29 • The connection has been successfully established. To assign the newly added device to a room, tap the de- sired room under the name of the device so that it is highlighted with a dark background. • Tap the pencil icon to assign an individual name to the new device.
  • Page 30 • Now you can see the main operating page of the Wi-Fi measuring socket. The operation is explained in the fol- lowing chapter. • To return to the home page of the app, tap the arrow in the upper left corner.
  • Page 31 • On the home page you will now see the newly added device.

  • Page 32: Operating The Wi-Fi Measuring Socket

    Operating the Wi-Fi measuring socket On the home page of the app, you can select the respec- tive device for operation. The figure shows the “All devices” display. If you tap to switch to a room, you will only see the devices that are linked to that room.
  • Page 33 • To turn on/off, tap either the large on/off button in the middle of the figure or the bottom left function button. • Currently the switch is disabled. On the one hand, it can be recognised by the dark background, and, on the oth- er hand, the current status is displayed below the large on/off button (see arrow in the figure).
  • Page 34 • The background will thus become light and the status display will also change. • To programme a timer, tap the corresponding function button in the bottom row.
  • Page 35 • To add a new timer, tap the bottom button.
  • Page 36 • Swipe up and down to set the hours and then the min- utes of the desired time. • If you want the timer to run more than once, tap the re- peat button (square in the figure).
  • Page 37 • Select the desired days by tapping. • Then tap the arrow at the top left.
  • Page 38 • Select what should happen at the selected time. • To do this, tap the respective button (small square in the figure).
  • Page 39 • In this case, select either “ON” or “OFF” and use the bottom right button to save the selection.
  • Page 40 • On the timer overview page, you can turn all timers on or off (just tap the switch), whichever one you need. • To delete the timer, tap it a little longer and then confirm the deletion. • To exit this display, tap the arrow at the top left. •...
  • Page 41 • To programme a countdown timer, tap the correspond- ing function button in the bottom row. •...
  • Page 42 • Use the green switch to select whether the device should turn on or off after the countdown timer expires. • Set the desired countdown time (hours and minutes). To do this, swipe up or down. • Confirm the setting by tapping “OK”.
  • Page 43 • The status field now shows the current status, as well as the countdown time and what will happen at the end of the countdown. In this case, the Wi-Fi measuring socket will turn on at the end of the countdown. •...
  • Page 44 • To display measurement readings, tap the correspond- ing function button in the bottom row.
  • Page 45 • The upper half of the display shows the current day en- ergy consumption in large figures. • The following readings appear in the line below: present current consumption (mA) / current power consump- tion (W) / mains voltage (V) / total energy consumption (kWh) •...

  • Page 46: Further Device Settings

    Further device settings • To open further device settings, tap the pencil icon at the top right in the device display.
  • Page 48 Use the arrow to go back to the device display. Here you can change the name of the device. Here you can adjust the location of the device, pro- vided you have selected or created multiple rooms. Use this function to check the network connection to the device.

  • Page 49: Creating A Group

    Creating a group • To create a group, open the devices display and then tap the pencil icon at the top right.
  • Page 50 • In the device settings, tap the button to create a group.
  • Page 51 • Now select the devices you would like to have in the group. To do this, check the box of each device that you want to add to the group. Of course, a group with only one device, as in our example, makes little sense.
  • Page 52 • Enter a name for the group and save it.
  • Page 53 • The devices display is no longer shown, rather the groups display for the previously created group. • Go back to the home page (top left arrow).
  • Page 54 • The main display now shows the device (lower button) and the newly created group (upper button). • To display the devices or the groups display, press the respective button. • To open the groups display again, tap the group.
  • Page 55 • To open the groups settings, tap the pencil icon in the upper right corner.
  • Page 56 The group settings enable you to adjust all settings for the group: • Change the group’s name • Move the group to another room • Add and remove devices • Share the group • View FAQs and give feedback on problems to the de- veloper •...

  • Page 57: Creating A Scene

    Creating a scene • To create a scene, tap the sun icon at the bottom centre in the main display of the app.
  • Page 58 • Tap “+” in the upper right corner or the blue button in the middle.
  • Page 59 • Tap the background image to select another. • Then tap the small “+”.
  • Page 60 • In our example, we are creating a scene with delay. To do this, tap the corresponding button in the middle. Since a delay always requires a device to be defined, we will first create the delay and then add the device. •...
  • Page 61 • The delay has been added to the scene. • To add the device, tap the small “+” again.
  • Page 62 • Now tap the “Device” button. • Select the desired device and tap it.
  • Page 63 • In our case it is a switching function. Tap the corresponding button.
  • Page 64 • Now select whether the switch should be disabled or enabled after the delay. In our case, the switch should be enabled. • Tap the bottom right button to save the selection.
  • Page 65 • The desired function is now displayed behind the switch. • Tap the top right button to continue.
  • Page 66 • In addition to the delay, the switch is now also displayed in the scene. • Choose below whether the scene should appear in the main display of the app. If the switch is in the position as shown in the figure be- low, the scene will appear in the main display.
  • Page 67 • Enter a name for the scene and save again.
  • Page 68 • The scene now appears in the scene display. • To execute the scene, tap the corresponding button (ar- row in the figure).
  • Page 69 • A pop-up will appear. You can either close it or leave it open. The switch will turn on after the delay.
  • Page 70 • If you have previously selected that the scene should also appear in the main display, you can also execute it from here. • To do this, simply tap the corresponding scene.
  • Page 71 • A pop-up will appear again and the scene will be exe- cuted.
  • Page 72 • To delete a scene, go back to the scene display and se- lect the desired scene. • Swipe all the way down and tap the lowest button. • Then confirm the deletion process.
  • Page 73 Similar to a scene, you can also create an automation. The difference is that you have to set a condition, an action and finally an effect. To do this, switch the tab at the top to “Automation” after tapping the sun icon in the main display of the app.

  • Page 74: Profile And Settings Page Of The App

    Profile and settings page of the app Here is a brief overview of the functions of the profile and settings page. • To go to the page, tap the bottom right profile button on the home page of the app.
  • Page 75 Opens the profile of the current user; see D1 to D5 Opens family management; see E1 to E6 Opens the message centre; here you can view and edit all notifications Opens the help centre with some questions and an- swers Here you can select a service you would like to use to link the app with and need help with that.

  • Page 76: Profile Of The Current User (C1)

    Profile of the current user (C1) Here you can set a profile image. This item enables you to add a nickname for your profile. Here you can view and change all settings related to your account. Here you can select the temperature unit. Here you can set your time zone.

  • Page 77: Family Management (C2)

    Family management (C2) • Firstly, select the family you want to edit. Here you can change the family name. This item opens room management, where you can, for example, add new rooms or delete old ones. Here you can set the family location. Here you can manage the individual family mem- bers.

  • Page 78: Settings (C6)

    Settings (C6) Here you can turn the app sound on and off. This item opens the notification settings. This item displays all information about the app. Here you can perform a network diagnosis. This item enables you to delete the cached data of the app.
