Current Tools
for 2½" to 4" hydraulic bender shoes, follow bars and saddles
This manual is free of charge. All personnel who assemble, operate or service this equipment should have a copy of this manual
and read and understand its contents. To request a copy, call or write to the address below. All information, specifications and
product designs may change due to design improvements or updates and are subject to change without notice. Current Tools
does not assume any liability for damages resulting from misuse or incorrect application of its products.
CURRENT TOOLS • P. O. BOX 17026 GREENVILLE, SC 29606
800.230.5421 or 864.721.4230 • FAX 864.721.4232
Model 282 Transfer Cart
™
Assembly, Operating, Safety
and Parts Manual
Read and understand this material before assembling,
operating or servicing the 282 Transfer Cart. Failure to
understand how to safely assemble and operate this
equpment may result in serious injury or death.
www.currenttools.com
Patent Pending
01/2022
Advertisement
Related Manuals for Current Tools 282
Summary of Contents for Current Tools 282
- Page 1 To request a copy, call or write to the address below. All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Current Tools does not assume any liability for damages resulting from misuse or incorrect application of its products.
- Page 2 TABLE OF CONTENTS — 282 TRANSFER CART Safety Alerts ....................2 Important Safety Information ..............3 Specifications and Features ................4 Assembly and Operating Instructions ..........5-11 Exploded View and Parts List ..............12 RETAIN SAFETY INFORMATION Safety Alert Symbol This manual should be read and understood by all personnel who assemble, operate or service this Transfer Cart.
- Page 3 ALWAYS keep children away. All visitors should remain a safe distance from work area. WARNING CAUTION NEVER sit, ride or stand on the transfer cart. CAUTION ONLY use with shoe group components from the Current Tools Model #254 Hydraulic Bender OR Greenlee ® Model #881 CamTrack ® Hydraulic Bender* ®...
-
Page 4: Specifications
(shoe, follow bar, saddle). Greenlee Model #881 CamTrack ® ® shoe group components will fit the Transfer Cart as well. • Standard legs provide correct height for use with Current Tools Model #281 Bending Table or Greenlee Model #1813 Bending Table ® ®... - Page 5 Cart Base (All 4 Corners) Figure 5 PARTS LIST – CASTERS AND HARDWARE ITEM # PART # DESCRIPTION QTY. 282-001 SWIVEL LOCK 503-32 BOLT – HEX HEAD CAP GR5 ZINC (3/8-16 × 5/8) 513-001 CASTER 452-27 3/8 LOCK WASHER 452-28...
- Page 6 ASSEMBLY AND OPERATING INSTRUCTIONS — CONTINUED 5. The gates on the roller bed are installed at the factory. Ensure that all eight gates (two per row) are in place and operable. To open, lift the gate from the spring side and rotate towards the front of the cart.
- Page 7 ASSEMBLY AND OPERATING INSTRUCTIONS — CONTINUED 2. Decals indicate correct placement for all components. To load the shoes and follow bars onto the cart, start with the 3 ½" and 4" inner rows of the cart. (See Figure 7). 3" Row 2½"...
- Page 8 1. Release the brakes on all the casters and roll the cart to your bender. 2. Line up the row with the follow bar and shoe you will be using with the Current Tools Model #254 Hydraulic Bender mounted on the #281 Bending Table. (See Figure 8).
- Page 9 ASSEMBLY AND OPERATING INSTRUCTIONS — CONTINUED OPERATING CART — continued 4. Load your follow bar, shoe and saddle by following the steps outlined below. NOTE: For illustration purposes, only the 4" shoe and follow bar are being shown. A. Open the gate on the front of the cart and slide the follow bar between the frame sides on the bender, leaving approximately half of the follow bar on the transfer cart as shown in Figure 9A.
- Page 10 ASSEMBLY AND OPERATING INSTRUCTIONS — CONTINUED OPERATING CART — continued C. Align the shoe and follow bar as shown in Figure 10A. Figure 10A D. Rotate the shoe onto the follow bar as shown in Figure 10B. Figure 10B E. Slide the shoe along the follow bar until the clevis mounting holes are located underneath the clevis as shown in Figure 10C.
- Page 11 ASSEMBLY AND OPERATING INSTRUCTIONS — CONTINUED OPERATING CART — continued F. Advance the hydraulic cylinder and align the clevis with the correct hole on the shoe for the type conduit you will be bending (Rigid/IMC or EMT). Insert the clevis pin and secure with a spring clip.
-
Page 12: Exploded View
PART # DESCRIPTION QTY. 88-2 PIN – COTTER (1/8 × 1/2) 100-011 SPRING — GATE 254-006 SPRING CLIP 282-001 SWIVEL LOCK 282-002 CONVEYOR ROLLER — 7 9/16" LONG 282-003 CONVEYOR ROLLER — 8 9/16" LONG 282-106 ROLLER BED 282-116 GATE, OUTER...
