Summary of Contents for Platinum Health Tranquilo Premium
-
Page 2: Table Of Contents
Table of contents Product description....................3 Scope........................3 Components and parts....................4 Precautions......................5 Warnings........................5 The Charger......................6 Charging Instructions....................6 Instructions.......................7 Preparations before use...................7 Handset........................8 To use........................8 Emergency stop.......................9 Maintenance......................9 Technical Data bath lift...................10 Warranty....................... 11 Troubleshooting......................12... -
Page 3: Product Description
hygiene. These aids compensate, in Product description： whole or in part, for restricted or lost physical functions. The goal of using such aids is to enable their users to be independent of help and to give them EURUNI is grateful that you decided more privacy. -
Page 4: Components And Parts
Components and parts Linear actuator Back rest Safety pin Chair seat Side flaps Scissor rods Base Suction cups 10. Slides 11. Locking parts 12. Handle 13. Charger Please confirm all the above parts are included when you unpack the bath lift. Contact your supplier promptly for assistance it there are any parts missing. -
Page 5: Precautions
Precautions Warnings 1. Before your first use, carefully Do NOT overload; read and follow the instructions Do NOT stand on the bath lift; for an ideal user experience; Do NOT face back rest when using; Store the user instructions in a Do NOT install on a steeper surface safe, convenient and easily... -
Page 6: The Charger
The Charger Only use the included charger or the replacement charger provided by your dealer; Do not charge near water, heat or any other source that could harm the battery; Charge immediately when the LED low battery light is on; The charging LED indicator is red while charging and green when the battery is fully charged. -
Page 7: Instructions
INSTRUCTIONS Preparations before use: 1. Please confirm there are no parts damaged or lost before using; Ensure the six suction cups are secured to the bath lift; Ensure there obstructions that prevents the bath lift to execute full operation such as a shower head; Confirm the bathtub meets the relevant standards;... -
Page 8: Handset
Handset With one hand hold the back rest at the grip and with your other hand tilt the back rest until it rests 1. Check handset LED before each use; against the base plate. 2. If the handset indicator lights, Insert the integrated drive unit at please charge it immediately;... -
Page 9: Emergency Stop
Bath Lift Lowered Position Maintenance 1. After each use, rinse with warm water. Use wash cloth or brush to remove excessive dirt or grime. Do NOT use detergents on or soak handset or linear actuator in water. 3. Only clean handset while connected to the bath lift NOT... -
Page 10: Technical Data Bath Lift
Overall length(with backrest in a reclined 985mm(38.8in) position) Overall width(seat incl. side flaps) 725mm(28.5in) Width of seat 400mm(15.7in) Depth of seat 500mm(16.7in) Overall length of seat 590mm(23.2in) Sitting height min 80mm(3.1in) Sitting height max 487mm(19.2in) Height of backrest 650mm(25.6in) Width of backrest 350-360mm(13.8in-14.2in) 5°-max45°... -
Page 11: Warranty
Warranty Our warranty for the EURUNI Bath Lift will be in accordance with legal stipulations and/or regulations valid in the different countries. The warranty applies to Commercial and Domestic applications, subject to the conditions stated here. In the event of any part/product developing a manufacturing fault or design fault within the warranty period, replacement parts will be supplied free of charge. -
Page 12: Troubleshooting
●Troubleshooting Error Possible cause Remedy – Charge battery Lift does not move ·Battery is flat – Unplug hand control; wipe contacts with a ·Contacts on hand control are contaminated dry cloth and plug hand control in again ·Hand control is not connected properly –...
