Summary of Contents for Sencor SCR 4400
- Page 1 SCR 4400 ■ User Manual 4K CAMERA ■ Návod k obsluze 4K KAMERA ■ Návod na obsluhu 4K KAMERA ■ Használati utasítás 4K KAMERA ■ Instrukcja obsługi 4K KAMERA...
- Page 2 Table of contents Important safety instructions ..........................3 2. Description and control of the unit .......................4 3. Troubleshooting ..............................12 4. Technical specifications ..........................13 2 EN Copyright © 2021, Fast ČR, a. s. Revision 05/2021...
-
Page 3: Important Safety Instructions
1. Important safety instructions Carefully read this manual before using the device. It contains important information about safe use, operation and possible troubleshooting. Keep the user's manual in a safe place for possible future reference. If you are planning to sell or hand the unit over to another person, please include also the user’s manual so that the new owner can also get acquainted to the unit. -
Page 4: Description And Control Of The Unit
2. Description and control of the unit 1) MicroSD memory card slot Inserting the card: insert the card carefully into the unit while it’s POWERED OFF in the correct direction as shown on the unit (with the label facing the screen, the gold-plated contact areas pointing forward and inside the unit, and the card body recession pointing downward). - Page 5 Notes: a) for recording it is necessary to use a quality card with fast writing, at least class 10 and a suitable size. Try the size of the card for your use in advance, a small card can soon be filled with regular recording and locked files. We recommend to use at least 16GB, but no more than 64GB.
- Page 6 2.1. Glass mount Insert the unit carefully with this groove (“rail”) all the way into the mount on car glass or other suitable smooth surface. Installing the mount on the car glass (if soft transparent foil is attached to the piston, remove the foil before installation): Release the mount’s soft piston (move the lift lever away from the piston).
- Page 7 When connected to the car ignition key, the unit turns on and starts recording when the key is turned to the “Accessories” position, and stops recording and turns off when the ignition key is turned off. When the battery is charged and only the unit operation is active, the red charging indicator will go out.
- Page 8 2. Press MODE to switch among video recording mode (camera), taking photos (Photo) and previously taken recordings. The operating icons are shown in the top left corner of the screen. Recording and setup While the unit is in the camera mode ( icon), press REC/OK to start recording.
- Page 9 • Motion detection on/off - recording will start automatically only if there is a big motion in the scene being shot (car movement) and stops automatically after about 15 seconds. • Audio recording: Off/On - The cab sound is only recorded by the built-in microphone if Audio is on here.
- Page 10 Parking mode This is a special mode for creating a short 15s video recording in the event of hitting your stationary car in order to capture the perpetrator. With the camera powered off. Active parking mode is indicated by the camera icon at the top right of the screen. To enable the parking mode, proceed as follows: 1) In the unit menu, select On (OK).
- Page 11 Viewing and setup When the unit is in the View mode (press MODE twice), the last executed file (recording or photo) is first prepared for viewing. You can scroll through the files with the UP / DOWN buttons and select by pressing OK. Press OK to stop the recording playback.
-
Page 12: Troubleshooting
3. Troubleshooting Please read this before reaching out to your dealer or service. • Photos or recordings cannot be taken. Check if the inserted card is functional, contains enough free space and is not write-protected. • The recording stops spontaneously. Check the inserted card for integrity, format it in the unit or use another, faster card if possible. -
Page 13: Technical Specifications
4. Technical specifications LCD screen 3", HD, LCD Lens Wide-angle, high resolution Video size 4K/2.7K/1080P/720P Video format/codec H.264 MOV, High Compression Photo resolution 14M/12M/10M/8M Photo format Memory cards MicroSD, max. 128GB, min Class 10 Microphone/Speaker Embedded Line frequency 50Hz/60Hz USB port USB 2.0 Power source 5V, 1A... - Page 14 INSTRUCTIONS AND INFORMATION ON DISPOSING OF USED PACKAGING MATERIALS Dispose of used packaging material at a site designated for waste in your municipality. DISPOSING OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal waste.
- Page 15 Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized service centers Visit www.sencor. for detailed information about authorized service centers. EN 15 Copyright © 2021, Fast ČR, a. s.
- Page 16 16 EN Copyright © 2021, Fast ČR, a. s. Revision 05/2021...
- Page 17 FAST ČR, a. s. U Sanitasu 1621 Říčany CZ 251 01...
