- Page 1 E+ SERIES - INSTALLATION AND OPERATORS MANUAL (v2011-1) CAN’T SEE IT? CAN’T STEAL IT!
- Page 2 IMPORTANT Please read this manual before commencing installation © Concept Smoke Screen Limited, 1-2 North End, Swineshead, Lincolnshire PE20 3LR Tel: +44 (01205) 821111 • Email: info@smoke-screen.co.uk • www.smoke-screen.co.uk...
-
Page 3: Rugged Design
THE E-SERIES MORE SECURITY FOG OVER A LONGER PERIOD THAN ANY OTHER SYSTEM Fills large spaces in seconds Smallest, lightest, most powerful model Easy, seamless installation NO residue DIGITAL INTERFACE The E-Series is the most flexible range, offering control over all parameters. - Page 4 INSTALLATION AND OPERATING INSTRUCTIONS DEFAULT SETTINGS On delivery, the E+ will have the following defaults Clock and Date: pre-set. Smoke Burst Time: 2 min of smoke production. Auxiliary Timed Relay: 59 min from smoke on. H/O Alarm: enabled. H/O Retrigger: enabled.
-
Page 5: Smoke Test
SIGNALLING RELAYS Relay terminology refers to the relay condition in the de-energised state, i.e. if a relay is Normally Open (NO) the wiring across Common and NO will be open when not energised and closed when energised. All signalling relays have changeover contacts for flexible configuration. -
Page 6: Parameter Adjustments
An alternative UPS (Uninterrupted Power Supply), or maintained, supply can be incorporated into an installation if required by connecting the IEC panel plug on the case. When the mains supply fails this will provide power to the controls and the pump/solenoid output but the fluid heater control is disabled. A “MAINS FAIL” message also alternates with the normal status in the display. - Page 7 16 character display Comment Default Level 1 15 sec increments (0 - 600) 120 secs 5 mins 2 hrs Period power supplied to 59 mins aux connections. 1 min increments (0 – 59 min) Press ! and ▲ to move up a level or press ▼...
-
Page 8: Temperature Indication
16 character display Comment LED Beeps Trigger’ contact open Hold-off contact open * Smoke Screen ‘Not Ready’ m m S Alarm ‘Set’ m m U Alarm ‘Unset’ If any of the following conditions exist the display will alternate between the ‘Ready/Smoke’ display and the ‘Conditions’... - Page 9 The first four characters show the event code, followed by the event time and date in seconds, minutes, hours, day and month. The Event Code meanings are: Mains supply ‘On’ Mains supply ‘Off’ UPS supply ‘On’ UPS supply ‘Off’ Smoke (Pump/Valve) Output ‘On’ Smoke (Pump/Valve) Output ‘Off’...
- Page 10 PROGRAMMING E+ (FRONT PANEL) - ENGINEER SETTINGS AEROSOL AND FLUID BOTTLE VERSION Connect all test connectors. • Ensure Trigger / Set switch is closed. • Ensure HO (Hold-off) switch is closed. Power up E+. Enter the parameter adjustment mode and check the following settings are correct: Level 1 Smoke On Time : 120 seconds.
-
Page 11: Additional Information
CONNECTIONS Connections for Hold Off detector. Note 1 If a Hold Off detector is not used, turn off “HO Alarm” in level 2 Parameters. Note 2 12vDC power supply of 250mA is available. Alarm contact (volt free) opening in alarm. If connected as shown the unit will stop producing smoke when Alarm contact closes. -
Page 12: Example Wiring Diagram
EXAMPLE WIRING DIAGRAM E+ with PIR, Exagon and IAS Trigger Trigger Tamper Tamper E+ Unit 8 Xt Tam Exagon 7 Xt Tam 6 Hold Off Spare 5 Hold Off Spare Trigger 4 Trigger Trigger 3 Trigger 2 Set 1 Set Ready Ready Aux n/c... - Page 13 INSTALLATION GUIDE OVERVIEW Carry handle and suspension bracket fitting Mains cable Cable entry Wall mounting slot LED Display Fluid bottle hold off PIR Door lock hold-off (optional) Interface (optional) Intruder alarm panel...
-
Page 14: Step 2 - Wall Mounting
STEP 1 - PREPARING FOR INSTALLATION Remove side panel Remove screws from side panel and then slide panel out. Then determine whether the unit will be positioned on a wall or in the ceiling. If the unit is to be mounted on the wall - proceed to step 2 If the unit is to be mounted in the ceiling - proceed to step 3... -
Page 15: Step 3 - Ceiling Mounting
STEP 3 - CEILING MOUNTING Mounting the threaded bars ceiling Fix the unistrut to the ceiling and connect ceiling threaded bars using spring fastenings above the ceiling false roof. Fix nuts and washers to the threaded bar to ‘lock-off’ onto the unistrut. Put two nuts and washers on each bar, leaving enough space in between for the units mounting bracket. - Page 16 STEP 4 - WIRING Feed wires through the grips on the top of the Tamper (PIR) unit. Remove butterfly nut and wiring case to expose a bank of connector blocks. Tamper (PIR) 12-Volt (PIR/I’face) Carefully connect the wires to the 0-Volt (PIR/I’face) corresponding connector block.
-
Page 17: Mounting Options
Mounting Options M8 studding How to use the suspension kit M8 nut M8 washer Unistrut Zebedee mounting fl ange M8 large washer M8 large washer M8 nut M8 studding Wall mounted E-Series E-Series suspension kit (aerosol) Ducting bracket 30 deg wall bracket ELM/HP bracket... -
Page 18: Mounting Examples
Mounting Examples...
