Elite XL Sheet Feeder Installation Guide
Elite XL Sheet Feeder
Contents
................................................................................................. 2
250-sheet feeder accessories
................................................................................. 2
............................................................................ 2
................................................................................. 3
................................................................................. 10
................................................................... 11
................................................................... 11
G
CC
T
ECHNOLOGIES
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GCC Technologies Elite XL-1208
Summary of Contents for GCC Technologies Elite XL-1208
-
Page 1: Table Of Contents
Elite XL Sheet Feeder Installation Guide Elite XL Sheet Feeder Contents Introduction ... 2 Installation guidelines ... 2 Sheet feeder kit contents ... 2 Installation procedure ... 3 Removal procedure ... 10 500-sheet feeder accessories 250-sheet feeder accessories ... 11 ... -
Page 2: Introduction
Note: Steps marked 16ppm are only applicable to users of 16 page-per-minute models of the Elite XL who are attaching two lower sheet feeders to the printer. To add a lower sheet feeder(s) to the Elite XL: Switch the printer off and unplug the power cord from the wall outlet. -
Page 3: Installation Procedure
3. Remove any paper tray(s) from the printer. 16ppm 4. If there is a 500-sheet feeder attached to the printer, you must remove it before attaching the 250-sheet feeder. (See “Removal Procedure” on page 10). Reminder: You may not attach two 500-sheet feeders to the printer. - Page 4 Elite XL Sheet Feeder Installation Guide 6. Attach the sheet feeder(s) to the printer. Slowly lower the printer onto the sheet feeder(s). The sheet feeder has four pins that fit into the base of the printer enabling proper alignment. 7. Attach four retaining clips.
- Page 5 Elite XL Sheet Feeder Installation Guide Use the four plastic retaining clips to lock the Elite XL printer and sheet feeder(s) together. The clips fit into slots located at the four inside corners where the sheet feeders mate. 8. Remove the sheet feeder control cable cover.
- Page 6 To remove the cover, grasp the cover’s handle, push it up, then pull it out. With the cover removed, the control cable will be visible. 16ppm Note: If you are attaching two sheet feeders, remove the control cable cover from each one. 9. Remove the printer’s control cable cover.
- Page 7 Elite XL Sheet Feeder Installation Guide The control cable cover is located at the lower left corner of the back of the printer. To remove the cover, grasp the cover’s handle, push it up, then pull it out. 10. Connect the sheet feeder control cable to the printer.
- Page 8 If you are attaching two feeders, use the cable from the upper sheet feeder. Orient the cable’s connector so that the two “tabs” are facing to the right and plug the cable into the connector in the printer. Elite XL...
- Page 9 11. Replace all of the control cable covers. Insert the top edge of the cover first and then pivot the bottom half down and into place. 12. Reconnect the interface cables and the power cord to the printer.
-
Page 10: Removal Procedure
Removal Procedure To remove a sheet feeder from the Elite XL printer: 1. Switch off the printer and unplug the power cord from the AC outlet. 2. Disconnect the power cord and all interface cables from the back of the printer. -
Page 11: 500-Sheet Feeder Accessories
12. Switch on the printer. For information on ordering consumable items and accessories for the Elite XL, please call GCC Sales at (800) 422-7777 (U.S. and Canada only). Outside the U.S. and Canada, call your local GCC dealer. 500-Sheet Feeder Accessories 500-sheet Letter Cassette ... - Page 12 WARRANTY GCC Technologies Inc. (“GCC”) warrants, for the limited period of one year from the date of original purchase, the Elite XL Sheet Feeder sold by GCC is recorded (the “product”) to be free from defects in materials and workmanship. During the warranty period, GCC or its authorized representative will, at its option, repair, replace or refund the purchase price of any defective product at no additional cost, provided you return it during the warranty period, transportation charges prepaid, to GCC or an authorized GCC dealer or representative.
