- Page 1 INSTALLATION MANUAL NRS-1 Point-of-Use Nitrate Reduction System Franklin Electric Co., Inc. 12630 US 33 N. Churubusco, IN 46723 Ph. (260) 693-1972 Fax (260) 693-0602 NRS-1 Manual 211215...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: SECTION I. INTRODUCTION AND LIABILITY..........3 SECTION II. SPECIFICATIONS..............3 SECTION III: PREPARATION.................4 Major System Components......................4 B. Tools Recommended for Installation..................4 C. Determine System Location......................4 D. Prepare the Area for Installation....................5 E. Prepare the Appliance for Installation..................5 SECTION IV. INSTALLATION STEPS............5 A. -
Page 3: Introduction And Liability
Must be potable** NOTE: The NRS-1 may be installed on waters containing nitrate; however the total nitrate concentration of the incoming water supply should be less than 21.0 ppm. Water containing nitrate concentration greater than 20.0 ppm will greatly reduce the cartridge capacity and leave potential for harmful levels of nitrate bleed through. -
Page 4: Preparation
C. Determine System Location SECTION III: PREPARATION The NRS-1 system can be located under a sink or A. Major System Components in a basement depending on space availability and the customer’s preference. If a basement The following components comprise the NRS-1... -
Page 5: Prepare The Area For Installation
If the sink already has a hole provided that can size. accommodate the NRS-1 faucet, then no drilling is d) Clean up sharp edges with a file if required and you can proceed to the section on necessary. -
Page 6: Mount The Faucet
or non-air gap faucet) black plastic washer, star washer and hex • Plumber’s putty nut on threaded nipple and tighten by hand. After rechecking faucet orientation, tighten hex nut (9/16" wrench or deep socket) until It is important to understand what is involved in this faucet feels secure. -
Page 7: Automatic Water Meter
When routing tubing meter is facing the front of the NRS-1 housing between components, several guidelines should be assembly. This will allow for ease of setting the observed. -
Page 8: Start Up The System
SECTION V. OPERATION & page 3. MAINTENANCE A. Changing Filter NOTE: THIS NRS-1 SYSTEM CONTAINS A FILTER WHICH MUST BE REPLACED AT REGULAR INTERVALS TO MAINTAIN PROPER PERFORMANCE. USE ONLY FACTORY APPROVED FILTERS. Please see Page 3 for the recommended interval for changing the filters. -
Page 9: Diagram And Parts List
B. Diagram and Parts List Part Number Description Feed Water Valve, 3/8"Mx1/2"Fx RO-FWV 1/4"Tube, w/1/2"Mx3/8"F Adapt. BV-101 Ball valve, ¼” tube X ¼” tube 4SE4 Stem elbow, ¼” tube X ¼” stem Male connector, ¼” tube X ¼” MNPT ½” white housing & cap, 10” with USH10 bracket &... -
Page 10: Quick Connect Fittings
TO ATTACH TUBING... C. Quick Connect Fittings Your new NRS-1 Drinking Water Appliance is outfitted with new generation of user-friendly quick connect push-in fittings. Proper use of the fittings is shown in the diagrams. It is important that the tubing selected for use with these connectors be of high quality exact size and roundness, and with no surface nicks or scratches. -
Page 11: Section Vi: Troubleshooting Guide
SECTION VI. TROUBLE SHOOTING GUIDE Problem Possible Cause Solution Low quantity of Product Feed Water Valve is plugged or Open Valve or unclog. Water from Treatment closed. System or Low Pressure Clogged filter. Replace filter. at the Dispensing Faucet Low water pressure Feed Water pressure must be above 30 psig. -
Page 12: Leak Stop Valve Compressed Pellet Replacement
Leak Stop Valve – Compressed Pellet Replacement 1) Pull the upper cover upward and separate it from the lower body. 2) Remove the expanded pellet from the retainer. 3) Replace the expanded pellet with the spare compressed pellet. 4) Seat the compressed pellet and retainer into the lower body. 5) Push the upper cover down until it snaps securely in place. -
Page 13: Limited Warranty
NITRATE DRINKING WATER SYSTEM LIMITED WARRANTY What Does This Warranty Cover? This warranty covers any defects in materials and workmanship of the Nitrate Drinking Water System when installed and operated within recommended parameters, with the exceptions stated below. How Long Does The Coverage Last? The manufacturer will warrant its Nitrate Drinking Water System, for a period of one year from the date of purchase.
